LCC, TLCC
Vishay Thin Film
Hermetic, 50 mil Pitch,
Leadless Chip Resistor, Surface Mount Network
FEATURES
• High purity alumina substrate for high power
dissipation
• Leach resistant terminations with nickel barrier
• 16, 20, 24 terminal gold plated wraparound
true hermetic packaging
• Military/aerospace
• Hermetically sealed
• Isolated/bussed circuits
• Ideal for military/aerospace applications
• Compliant to RoHS directive 2002/95/EC
Actual Size
Vishay Thin Film offers a wide resistance range in 16, 20,
and 24 terminal hermetic leadless chip carriers. The
standard circuits in the ohmic ranges listed below will utilize
the outstanding wraparound terminations developed for
chip resistors. Should one of the standards not fit your
application, consult the applications engineering group as
we may be able to meet your requirements.
TYPICAL PERFORMANCE
ABSOLUTE
TCR
25
ABSOLUTE
TOL.
0.1
TRACKING
5
RATIO
NA
Note
• Resistance range: Noted on schematics
SCHEMATIC
TLCC 16 A01
1 kΩ to 100 kΩ
10 9 8 7
TLCC 20 A01
10 kΩ to 200 kΩ
13 12 11 10 9
TLCC 24 A01
1 kΩ to 100 kΩ
151413121110
LCC 20A
(10 Isolated Resistors)
10
Ω
to 250 kΩ
13 12 11 10 9
9
8
7
6
5
4
14
15
16
17
18
8
7
6
5
4
11
12
13
14
6
5
4
3
14
15
16
17
18
19 20 1 2 3
8
7
6
5
4
16
17
18
19
20
21
15 16 1 2
22 23 24 1 2 3
TLCC 16 A03
100
Ω
to 100 kΩ
10 9 8 7
TLCC 20 A03
10
Ω
to 120 kΩ
13 12 11 10 9
TLCC 24 A03
1 kΩ to 100 kΩ
1514 13 12 1110
19 20 1 2 3
LCC 20B
9
8
7
6
5
4
(19 Resistors + 1 Common Point)
10
Ω
to 200 kΩ
11
12
13
14
15 16 1
2
6
5
4
3
14
15
16
17
18
19 20 1 2 3
8
7
6
5
4
16
17
18
19
20
21
13 12 11 10 9
14
15
16
17
18
8
7
6
5
4
22 23 24 1 2 3
TLCC 16 A06
100
Ω
to 100 kΩ
10 9 8 7
TLCC 20 A06
1 kΩ to 110 kΩ
13 12 11 10 9
TLCC 24 A06
1 kΩ to 100 kΩ
151413121110
19 20 1 2 3
9
8
7
6
5
4
11
12
13
14
15 16
1
2
6
5
4
3
14
15
16
17
18
19 20 1 2 3
8
7
6
5
4
16
17
18
19
20
21
22 23 24 1 2 3
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 60012
Revision: 22-Dec-09
For technical questions, contact:
thinfilm@vishay.com
www.vishay.com
37
LCC, TLCC
Vishay Thin Film
Hermetic, 50 mil Pitch,
Leadless Chip Resistor, Surface Mount Network
STANDARD ELECTRICAL SPECIFICATIONS
TEST
Material
Pin/Lead Number
Resistance Range
TCR: Absolute
TCR: Tracking
Tolerance: Absolute
Tolerance: Ratio
Power Rating: Resistor
Power Rating: Package
Stability: Absolute
Stability: Ratio
Voltage Coefficient
Working Voltage
Operating Temperature Range
Storage Temperature Range
Noise
Thermal EMF
Shelf Life Stability: Absolute
Shelf Life Stability: Ratio
Note
• Tantalum nitride film is custom, consult factory
SPECIFICATIONS
Passivated nichrome
16, 20, 24
10
Ω
to 250 kΩ per resistor
± 25 ppm/°C to ± 300 ppm/°C
± 5 ppm/°C
± 0.1 % to ± 1.0 %
N/a
50 mW max. = common circuits
100 mW max. = isolated circuits
500 mW
ΔR
± 0.05 %
-
< 5 ppm/V (typical)
100 V max. not to exceed
- 55 °C to + 125 °C
- 55 °C to + 150 °C
< - 30 dB
0.008 μV/°C
ΔR
± 0.01 %
-
P
x
R
CONDITIONS
-
-
-
- 55 °C to + 125 °C
- 55 °C to + 125 °C
+ 25 °C
-
Maximum at + 70 °C
Maximum at + 70 °C
2000 h at + 70 °C
-
-
-
-
-
-
-
1 year at + 25 °C
-
DIMENSIONS
in inches and millimeters
B
D
max.
G
typ.
Terminal 1
C
Terminal 1
Indicator
A
typ.
F
E
Typ.
H
Index
Corner
0.008"
(0.203)
R Typ.
DIMENSION
A
B
C
D
E
F
G
H
16 PINS
INCHES
0.050
0.300
0.300
0.077
0.025
0.050
0.040
0.020
MILLIMETERS
1.27
7.26
7.26
1.96
0.635
1.27
1.02
0.508
INCHES
0.050
0.350
0.350
0.077
0.025
0.050
0.040
0.020
20 PINS
MILLIMETERS
1.27
8.89
8.89
1.96
0.635
1.27
1.02
0.508
INCHES
0.050
0.400
0.400
0.077
0.025
0.050
0.040
0.020
24 PINS
MILLIMETERS
1.27
10.16
10.16
1.96
0.635
1.27
1.02
0.508
www.vishay.com
38
For technical questions, contact:
thinfilm@vishay.com
Document Number: 60012
Revision: 22-Dec-09
LCC, TLCC
Hermetic, 50 mil Pitch,
Leadless Chip Resistor, Surface Mount Network
MECHANICAL SPECIFICATIONS
Resistive Element
Substrate Material
Body
Terminals
Marking Resistance to Solvents
Tin Lead Option
Lead (Pb)-free Option
Tin Lead and Lead (Pb)-free
Passivated nichrome
Alumina
Ceramic
Gold over nickel
Per MIL-PRF-83401
Sn63
96.5 % Sn, 3.0 % Ag, 0.5 % Cu
Hot solder dip
Vishay Thin Film
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: TLCC20AE1002BUF
T
T
L
L
C
C
C
C
T
2
1
0
6
A
A
0
1
E
K
1
1
0
0
0
0
2
3
B
K
U
U
F
F
GLOBAL
MODEL
(4 or 5 digits)
LCC
(Tin lead)
LCCT
(Tin lead)
TLCC
(Lead
(Pb)-free)
TLCCT
(Lead
(Pb)-free)
(e1)
TERMINAL
COUNT
(1)
20
20
16
20
24
16
20
24
SCHEMATICS
(4 or 5 digits)
A
= Isolated
resistors
B
= Resistor to
common bus
A01
= Resistor to
common
bus
A03
= Isolated
parallel
resistor
A06
= Isolated
adjacent
resistor
TCR
CHARACTERISTICS
E
= 25 ppm/°C
H
= 50 ppm/°C
K
= 100 ppm/°C
M
= 300 ppm/°C
RESISTANCE
First 3 digits are
significant figures
and
the
last
digit specifies the
number of zeros
to follow.
Example:
10R0 = 10
Ω
12R5 = 12.5
Ω
1000 = 100
Ω
1001 = 1000
Ω
TOLERANCE
B
= 0.1 %
D
= 0.5 %
F
=1%
G
=2%
J
=5%
K
= 10 %
S
= Special
PACKAGING
TAPE AND REEL
T0
= 100 min., 100 mult
T1
= 1000 min., 1000 mult
T3
= 300 min., 300 mult
T5
= 500 min., 500 mult
TF
= Full reel 2000
TS
= 100 min., 1 mult
UF
= TUBED
Historical Part Number example: LC20BK1003J (for reference purposes only)
LC
SERIES
20
PINS
B
SCHEMATIC
K
TCR
CHARACTERISTIC
1003
RESISTANCE
J
TOLERANCE
Note
(1)
LCC or LCCT only available in 20 pin size
Document Number: 60012
Revision: 22-Dec-09
For technical questions, contact:
thinfilm@vishay.com
www.vishay.com
39
