BCM5700
PRODUCT
®
Brief
O F
B E N E F I T S
BCM5700 PCI-X 10/100/1000BASE-T CONTROLLER
B C M 5 7 0 0
F E AT U R E S
S U M M A R Y
•
10/100/1000 Mbps tri-speed media access controller (MAC)
with wire speed performance at all rates
•
Support for PCI v2.2, 32/64-bit, 33/66 MHz, and PCI-X v1.0
32/64-bit, 66/133-MHz bus interfaces
•
96 KB ultra-deep packet buffer with support for up to 16 MB
externally
•
Support for IEEE 802.3, 802.3u, 802.3z, and 802.3ab
standards
•
MII/GMII and TBI (SerDes style) transceiver interfaces
features include: TCP/UDP/IP
•
Advanced CPU offload segmentation, 9 KB jumbo frame
checksum offload, TCP
•
Dual high-speed CPUs
PC99 compliant: support for ACPI ver
•
MicrosoftPXE version 2.0, and statistics for SNMP 1.1a, Wake
on LAN,
MIB II,
®
•
Features wire speed operation at all speeds.
ideal for new high-speed network interface
•
The BCM5700 is LAN on Motherboard (LOM) applications,
cards (NIC) and
the
and PCI-X
enables
•
Support for both run PCI 2.2PCI-based orstandardsystems.
the BCM5700 to
in any
PCI-X
packet buffer allows the
•
The ultra-deep on-chipand receive at high speedsBCM5700 to
continuously transmit
in systems
while maintaining backward compatibility with today’s
networks.
•
On-chip CPUs perform advanced functions and allow the
BCM5700 to evolve with new standards. The CPUs also
features promote
•
Advanced offloadCPU utilization. high throughput, while
minimizing host
•
Combined with the BCM5401 and newer BroadcomACPI-
10/100/1000BASE-T PHYs, the BCM5700 supports
compliant Wake on LAN implementations.
provide advanced packet parsing capabilities, making the
BCM5700 an OSI L4 protocol aware device, providing many
advanced features and offloads.
where the PCI/PCI-X bus is shared with other devices.
•
Layer 2 priority encoding (802.3p) (up to 16 priority queues)
•
VLAN tagging (IEEE 802.3q)
•
Flow control (IEEE 802.3x)
•
Link aggregation (IEEE802.3ad)
•
Multiple power modes with programmable low power
operation
•
Low power design – 3.3 V/1.8 V, 0.18 µm CMOS
•
5V tolerant PCI I/Os
•
388-pin PBGA package
Ethernet-like MIB, and Ethernet MIB (802.3z, Clause 30)
manageability features enable NIC
•
Additionalcomply with relevant manageability and LOM for
designs to
standards
power operation—0.18 µm advanced
•
Provides lowcombined with programmable power process
technology,
management.
server and desktop applications.
BCM5700 10/100/1000 PCI-X NIC Reference Design
B C M 5 7 0 0
O V E R V I E W
Receive
GMII
Receive
MAC
128
FIFO
Rule
Check
96 KB
Packet Buffer
Memory
Queue Memory
Registers
Statistics
Frame Buffer
Manager
Transmit
GMII
Transmit
MAC
128
FIFO
Memory
Arbiter
Receive DMA
ScratchPad
Memory
Boot
Processor
Transmit DMA
Boot ROM
TX
Processor
Ring Controllers
Host Coalescing
Queue Mangement
SSRAM Control
EEPROM Control
Send BD RING
Receive BD RING
DMA Descriptor
Config
512
FIFO
PCI/
PCI-X
512
FIFO
PCI/PCI-X
Bus
ScratchPad
Memory
PLL
LED Control
125 MHz Clock
LED Signals
SSRAM Interface
EEPROM Interface
The
BCM5700
is a high-performance 10/100/1000BASE-T
Ethernet LAN controller optimized for NIC and LOM
applications. The
BCM5700
is a highly-integrated solution
combining 10/100/1000BASE-T IEEE 802.3 compliant media
access controller (MAC), PCI and PCI-X bus interfaces, and
on-chip buffer memory in a single device. The
BCM5700
is
fabricated in a low voltage 1.8V CMOS process, providing a
low-power system solution. Combine the
BCM5700
with the
BCM5401 (or later) single-chip Gigabit Ethernet transceiver to
achieve a complete NIC or LOM solution for
10/100/1000BASE-T Ethernet.
The
BCM5700
includes a 10/100/1000 Mbps Ethernet MAC with
full/half-duplex capability at all speeds. The MAC interacts with
the external transciever via the GMII in 1000BASE-T mode, the
MII in 10/100BASE-T mode, and the TBI serial interface in
1000BASE-SX/1000BASE-FX mode. Support for the following
802.3 packet tagging functions is featured in the MAC: VLAN
tagging, layer 2 priority encoding, link aggregation, and full-duplex
flow control.
The device provides both PCI v2.2, 32/64-bit, 33/66-MHz and
PCI-X v1.0, 133-MHz, host interfaces. The
BCM5700
includes
a 96 KB on-chip buffer memory for stand-alone operation, and
Broadcom
®
, the pulse logo and
Connecting everything
®
are trademarks of
Broadcom Corporation and/or its subsidiaries in the United States and certain other countries.
All other trademarks are the property of their respective owners.
optionally supports up to 16 MB of external memory. Dual on-
chip high-performance processors enable many custom frame
processing features, including TCP segmentation.
Target Applications of the BCM5700
Network Interface Card (NIC) designs
Single Port
10/100/1000
BASE_T
1000
BASE_SX
1000
BASE_LX
PCI 2.2 Adapters
PCI-X v1.0 Adapters
PCI 2.2 Adapters
PCI-X v1.0 Adapters
PCI 2.2 Adapters
PCI-X v1.0 Adapters
PCI 2.2 Adapters
PCI-X v1.0 Adapters
LAN on Motherboard (LOM) designs
Single Port
10/100/1000
BASE_T
10/100/1000
BASE_T
PCI 2.2 LOM
PCI-X v1.0 LOM
PCI 2.2 LOM
PCI-X v1.0 LOM
Dual Port
Dual Port
10/100/1000
BASE_T
BCM5700 Operating System
• Microsoft
®
Windows
®
NT
®
4.0
• Microsoft Windows 2000
• Linux
TM
2.2
• NetWare
®
4.11, 4.2 and 5.x
• Novell
®
®
BROADCOM CORPORATION
16215 Alton Parkway, P.O. Box 57013
Irvine, California 92619-7013
© 2003 by BROADCOM CORPORATION. All rights reserved.
5700-PB06-R 06.25.03
Phone: 949-450-8700
FAX: 949-450-8710
Email: info@broadcom.com
Web: www.broadcom.com
