BCM5705
®
10/100/1000BASE-T CONTROLLER WITH INTEGRATED TRANSCEIVER
FEATURES
•
Single chip device for desktop LAN on Motherboard (LOM) or
Network Interface Card (NIC) applications
•
Integrated 10/100/1000BASE-T transceiver
•
10/100/1000BASE-T triple-speed MAC
•
PCI v2.2, 32-bit/33-MHz host interface
•
High-speed RISC core with 24-KB caches
•
SMBus 2.0 controller
•
On-chip power circuit controller and Wake-on LAN power
switching circuit
•
Advanced power management—ACPI compliance
SUMMARY OF BENEFITS
•
Ultra-low power for small form factor PCs
•
0.13µ CMOS design allows industry’s lowest power
•
Advanced power management
Enables desktop PC products for all segments—Allows one
board layout for both Gigabit and Fast Ethernet applications
Completely backward compatible, with existing:
•
10/100 network infrastructure
•
PCI-based desktop and mobile platforms
Future-proof with flexible firmware architecture
•
Flexible firmware adapts to changing standards
•
Wirespeed custom packet filtering via on-board CPUs
Power optimized through reduced CPU utilization
•
Adaptive interrupts minimizes calls to the PC’s CPU
•
TCP/IP offloads reduce CPU burden significantly
•
Reduces power consumption of PC processor
•
Allows use of lower power/performance PC processor
Cable analyzer tests for network cable issues
•
Customers can field-test using self-diagnostics
•
Dramatically reduces customer calls, returns, and costs
Robust and highly manageable
•
PXE 2.0, ACPI 1.1, Wake-on LAN
•
Integrated cable testing—Link quality, length, pair skew, pair
polarity, and pair swap
•
Flexible ASF 1.0
Space savings for LOM
•
196-pin HBGA package
•
No external memory
•
Integrated power circuitry reduces BOM costs
•
•
•
•
Performance features
•
TCP, IP, and UDP checksum
•
Microsoft
®
Large Send
•
TCP segmentation
•
CPU task offload
•
Adaptive interrupts
•
Robust manageability
•
Wake-on LAN
•
Out-of-Box mode Wake-on LAN
•
PXE 2.0 remote boot
•
Alert Specification Forum (ASF) 1.0 support
•
Statistic Gathering (SNMP MIB II, Ethernet-like MIB, and
Ethernet MIB [802.3x, clause 30])
•
Comprehensive diagnostic and configuration software suite
•
ACPI 1.1a complaint—multiple power modes
•
Advanced network features
•
Virtual LANs—802.1q VLAN tagging that supports 64 VLANs
•
802.3x flow control
•
Cable analyzer features detect cabling problems
•
3.3V I/Os (5V tolerant)
•
•
•
•
•
JTAG
•
Industry’s smallest 10/100/1000 MAC+PHY solution
•
Optimized for desktop LOM and NIC applications
•
Enables small form factor PCs
OVERVIEW
RX
10/100/1000
PHY
TX
10/100/1000
MAC
Buffer
Memory
Memory
Controller
Processor
PCI
25 MHz
PLL
Memory
PCI
Bus
LED Control
SMBus
EEPROM
Control
PLL
PCI
Clk
LED Signals
SMB Interface EEPROM Interface
The
BCM5705
is a fully integrated 10/100/1000BASE-T Gigabit
Ethernet Media Access Control and Physical Layer Transceiver solution
for high-performance network applications. The
BCM5705
combines a
triple-speed, IEEE 802.3 compliant media access controller (MAC), a
PCI bus interface, an on-chip buffer memory, and an integrated physical
layer transceiver in a single device. The
BCM5705
is fabricated in a low-
voltage 0.13µ CMOS process, providing an ultra-low power solution. By
itself, the
BCM5705
provides a complete single-chip Gigabit Ethernet
NIC or LOM solution.
The
BCM5705
includes a 10/100/1000-Mbps Ethernet MAC with full/
half-duplex capability at all speeds. Support for the following 802.3
functions is featured in the MAC:
•
VLAN tagging
•
Layer 2 priority encoding
•
Link aggregation
•
Full-duplex flow control
The device provides a PCI v2.2 bus interface and integrated on-chip
buffer memory for a stand-alone operation. An embedded high-
performance processor enables custom frame processing features,
including TCP segmentation.
The transceiver is fully compatible with the IEEE 802.3 standard for
auto-negotiation of speed. Additionally, several Plug and Play
enhancements are included to make the device even more user-friendly.
A unique integrated Cable Analyzer feature allows a user to self-
diagnose any issues with the network cabling that could affect the host
machine. A link quality indicator LED and a GUI application give
installers an instant visual indication of problems. This includes physical
wiring defects or channel conditions, such as excessive cable length,
return loss, crosstalk, echo, and noise. Broadcom’s remote cable
management and diagnostics software can be used with the device to
provide remote management of the cable and a first level of diagnostics
and fault isolation. The
BCM5705
continually monitors various channel
conditions. The optional wire-speed capability allows the
BCM5705
to
force auto-negotiation to be automatically limited by the speed that the
channel can reliably support rather than the performance of the end
equipment.
Target Applications of the BCM5705
•
Desktop PC NIC
•
Desktop PC LOM
Software Drivers Available
•
Windows 98, NT, 2000, XP
•
Linux 2.2, 2.4
Broadcom
®
, the pulse logo, and
Connecting everything
®
are trademarks of Broadcom Corporation and/
or its subsidiaries in the United States and certain other countries. All other trademarks mentioned are the
property of their respective owners.
®
BROADCOM CORPORATION
16215 Alton Parkway, P.O. Box 57013
Irvine, California 92619-7013
© 2003 by BROADCOM CORPORATION. All rights reserved.
5705-PB04-R
10/02/03
Phone: 949-450-8700
Fax: 949-450-8710
E-mail: info@broadcom.com
Web: www.broadcom.com
