ATE-3204I

Description
T1/E1/CEPT/ISDN Quad Port Transformer
File Size313KB,1 Pages
ManufacturerALLIED [Allied Electronics]
Download Datasheet View All

ATE-3204I Overview

T1/E1/CEPT/ISDN Quad Port Transformer

RoHS
T1/E1/CEPT/ISDN Quad Port Transformer
ATE-3204I
Designed for T1/E1/CEPT Line Interface
Operating Temperature Range: -40ºC to +85ºC
Reflow Condition: Maximum reflow temp is
250ºC/-5ºC, time is 20~40 sec.
(Refer to IPC/ JEDEC J-STD-020C Standard)
Electrical Specifications @ 25°C
Part
Part
Number
Number
ATE-3204I
Turn Ratio
(±2%)
PRI
1:2
SEC
1.20
0.60
30
1-2 , 3-4 , 5-6 , 7-8 , 9-10
1500V
, 11-12 , 13-14 , 15-16
All specifications subject to change without notice.
OCL
(mH min)
L
L
(uH Max)
CWW
(pF Max)
Primary Pins
HI-POT
(Vrms)
MECHANICAL
Marking
ALLIED
ATE-3204I
YYWW-###
Remark:
YY WW
-###DATE CODE , YY=YEAR
、WW=WEEK
###=Control Code
UNIT :m m/inch
SCHEMATICS
SEC
PRI
714-665-1140
ALLIED COMPONENTS INTERNATIONAL
07/26/12
15
www.alliedcomponents.com
