Corcom Product Guide
Catalog: 1654001
Issue Date: 06.2011
Multi-purpose Medical Filter for Power Line Noise Protection
MV Series
UL Recognized
CSA Certified
VDE Approved
MV Series
• Multi-purpose medical filter
• Improved Line to Ground performance
• A good solution to emission or immunity problems
• Meets leakage current requirements of UL2601 for
health care equipment
Specifications
Maximum leakage current each Line to Ground:
@ 120 VAC 60 Hz:
.07 mA
@250 VAC 50 Hz:
.13 mA
Hipot rating (one minute):
Line to Ground:
Line to Line:
Rated Voltage (max):
Operating Frequency:
Rated Current:
2250 VDC
1450 VDC
250 VAC
50/60 Hz
3 to 20A
Operating Ambient Temperature Range
(at rated current Ir):
-10°C to +40°C
In an ambient temperature (Ta) higher than +40°C
the maximum operating current (Io) is calculated as
follows: Io = Ir
(85-Ta)/45
Ordering Information
6 MV 1
Input / Output Style
1 – .250 [6.3] spade terminals
MV Series
Current Rating
3, 6, 10 or 20A
Electrical Schematic
LINE
LOAD
Available Part Numbers
3MV1
10MV1
6MV1
20MV1
54
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
For email, phone or live chat, please go to
te.com/help
corcom.com
Corcom Product Guide
Catalog: 1654001
Issue Date: 06.2011
Multi-purpose Medical Filter for Power Line Noise Protection
(continued)
MV Series
Case Styles
MV1
(3, 6, 10A)
Performance Data
Typical Insertion Loss
Measured in closed 50 Ohm system
3MV
db
100
6MV
db
100
90
80
1
RFI Power Line Filters
1
10
30
Frequency in MHz
B
90
80
70
60
50
70
60
50
40
30
20
10
0.1
1
10
30
Frequency in MHz
0
0.1
C
D
E
A
40
30
20
10
0
½
½½
10MV
db
100
90
80
70
60
20MV
db
100
90
80
70
60
50
40
30
20
10
20MV1
50
40
30
20
10
0
0.1
1
10
30
Frequency in MHz
0
0.1
1
10
30
Frequency in MHz
E
D B
Common Mode / Asymmetrical (L-G)
Differential Mode / Symmetrical (L-L)
Minimum Insertion Loss
Measured in closed 50 Ohm system
2.00
50.8
Common Mode / Asymmetrical (Line to Ground)
C
½
½½
A
Case Dimensions
Part No.
3MV1
6MV1
10MV1
20MV1
A
B
C
D
E
Differential Mode / Symmetrical (Line to Line)
55
Dimensions are in inches and millimeters unless otherwise specified. Values in italics
are metric equivalents. Dimensions are shown for reference purposes only.
Specifications subject to change.
