05325
Only One Name Means ProTek’Tion™
PSR3.3
ultRa low caPacitance SteeRing diode/tvS aRRay
deScRiPtion
The PSR3.3 is an ultra low capacitance (typically 1.5pF), transient voltage/steering diode suppressor array. This device
provides circuit protection for interfaces and high-speed data line applications in handheld electronics. The PSR3.3
has a working voltage of 3.3V and offers protection in a SOT-143 package.
This device meets the requirements of IEC 61000-4-2 (ESD), IEC 61000-4-4 (EFT) and IEC 61000-4-5 (Surge). The
PSR3.3 offers a ultra low capacitance solution for applications with higher operating frequencies or faster edge rates
where insertion loss and signal integrity are a serious concern.
Sot-143 Package
FeatuReS
•
•
•
•
•
•
•
•
•
Compatible with IEC 61000-4-2 (ESD)
Compatible with IEC 61000-4-4 (EFT)
Compatible with IEC 61000-4-5 (Surge)
Low Operating Voltage: 3.3V
Low Leakage Current < 1.0µA
Provides 2 Lines of Protection
Ultra Low Capacitance < 1.5pF (Typical, I/O to I/O)
RoHS Compliant
REACH Compliant
aPPlicationS
•
•
•
•
General Purpose High-Speed Data Line ESD Protection
FireWire & USB Interfaces
Handheld Electronics
Display Ports: DVI, HDMI, LCD
Mechanical chaRacteRiSticS
•
•
•
•
Molded JEDEC SOT-143 Package
Approximate Weight: 9 milligrams
Lead-Free Pure-Tin Plating (Annealed)
Solder Reflow Temperature:
Pure-Tin - Sn, 100: 260-270°C
• 8mm Tape and Reel Per EIA Standard 481
• Flammability Rating UL 94V-0
Pin conFiguRation
GND 1
4 REF
I/O 2
3 I/O
05325.R0 9/10
Page 1
www.protekdevices.com
05325
Only One Name Means ProTek’Tion™
PSR3.3
tyPical device chaRacteRiSticS
MaXiMuM RatingS
@ 25°c unless otherwise Specified
PaRaMeteR
Operating Temperature
Storage Temperature
Peak Pulse Power (tp = 8/20µs) - See Figure 1
Peak Pulse Current (tp = 8/20µs)
SyMBol
T
L
T
STG
P
PP
I
PP
value
-55 to 150
-55 to 150
150
10
unitS
°C
°C
Watts
Amps
electRical chaRacteRiSticS PeR line
@ 25°c unless otherwise Specified
PaRt
nuMBeR
device
MaRking
Rated
Stand-oFF
voltage
(note 1)
v
wM
voltS
PSR3.3
noteS
3P
3.3
MaXiMuM
claMPing
voltage
(Fig. 2)
(note 1)
@ i
P
= 1a
v
c
voltS
7.0
MaXiMuM
claMPing
voltage
(See Fig. 2)
(note 1)
@ 8/20µS
v
c
voltS
15V @ 10A
MaXiMuM
leakage
cuRRent
(note 1)
@v
wM
i
d
µa
1
tyPical
caPacitance
@0v, 1Mhz
(note 2)
c
j(Sd)
pF
0.6
1. From pin 4 to 1.
2. From pin 1 to 3, 1 to 2, 3 to 4, and 2 to 4.
05325.R0 9/10
Page 2
www.protekdevices.com
05325
Only One Name Means ProTek’Tion™
PSR3.3
tyPical device chaRacteRiSticS
FiguRe 1
Peak PulSe PoweR vS PulSe tiMe
10,000
P
PP
- Peak Pulse Power - watts
1,000
150W, 8/20µs Waveform
100
10
0.1
1
10
100
t
d
- Pulse duration - µs
1,000
10,000
120
i
PP
- Peak Pulse current - % of i
PP
FiguRe 2
PulSe wave FoRM
t
f
Peak Value I
PP
TEST
WAVEFORM
PARAMETERS
t
f
= 8µs
t
d
= 20µs
100
80
% of Rated Power
FiguRe 3
PoweR deRating cuRve
Peak Pulse Power
8/20µs
100
80
60
40
20
0
0
5
e
-t
60
40
20
0
Average Power
t
d
= t/(I
PP
/2)
10
15
t - time - µs
20
25
30
0
25
50
75 100 125
t
a
- ambient temperature - °c
150
05325.R0 9/10
Page 3
www.protekdevices.com
05325
Only One Name Means ProTek’Tion™
PSR3.3
Sot-143 Package inFoRMation
outline diMenSionS
diM
A
B
C
D
F
G
J
K
L
L1
R
S
noteS
A
G
L
MilliMeteRS
Min
2.80
1.20
0.84
0.39
0.79
1.78
0.08
0.46
0.445
0.40
0.72
2.11
incheS
Min
0.110
0.047
0.033
0.015
0.031
0.070
0.003
0.018
0.0175
0.016
0.028
0.083
MaX
3.04
1.39
1.14
0.50
0.93
2.03
0.15
0.60
0.60
0.60
0.83
2.48
MaX
0.120
0.055
0.045
0.020
0.037
0.080
0.006
0.024
0.024
0.024
0.033
0.098
H
C
F
D
B S
L1
K
J
R
1. Dimensioning and tolerances per ANSI Y14.M, 1985.
2. Controlling dimension: inches.
3. Dimensions are exclusive of mold flash and metal burrs.
Pad layout diMenSionS
diM
A
B
C
D
E
F
noteS
C
A
MilliMeteRS
Min
1.88
1.80
0.71
0.76
1.07
0.71
incheS
Min
0.074
0.071
0.028
0.030
0.042
0.028
MaX
2.13
2.06
0.97
1.02
1.32
0.97
MaX
0.084
0.081
0.038
0.040
0.052
0.038
E
F
D
B
1. Controlling dimension: inches.
05325.R0 9/10
Page 4
www.protekdevices.com
05325
Only One Name Means ProTek’Tion™
PSR3.3
taPe and Reel
P0
t
D
P2
10 Pitches Cumulative
Tolerance on Tape. ± 0.2
E
Top Cover Tape
A0
K0
Pin 1
F
W
B0
P
User Direction of Feed
SPeciFicationS
Reel dia.
178mm (7”)
1.
2.
3.
4.
5.
taPe
width
8mm
a0
B0
k0
d
e
F
w
P0
P2
P
tmax
0.25
3.10 ± 0.10 2.70 ± 0.10 1.35 ± 0.10 1.50 ± 0.10 1.75 ± 0.10 3.50 ± 0.05 8.00 ± 0.30 4.00 ± 0.10 2.00 ± 0.05 4.00 ± 0.10
noteS
Dimensions are in millimeters.
Surface mount product is taped and reeled in accordance with EIA-481.
Suffix - T7 = 7” Reel - 3,000 pieces per 8mm tape.
Suffix - T13 = 13” Reel - 10,000 pieces per 8mm tape.
Marking on Part - marking code (see page 2) and date code.
Package outline, pad layout and tape specifications per document number 06011.R4 8/10.
oRdeRing inFoRMation
BaSe PaRt nuMBeR
PSR3.3
PSR3.3
leadFRee SuFFiX
n/a
n/a
taPe SuFFiX
-T7
-T13
Qty/Reel
3000
10,000
Reel SiZe
7”
13”
tuBe Qty
n/a
n/a
05325.R0 9/10
Page 5
www.protekdevices.com
