Advance Info
TF2104M
Half-Bridge Gate Driver
Features
Floating high-side driver in bootstrap operation to 600V
Drives two N-channel MOSFETs or IGBTs in a half bridge
configuration
Designed for enhanced performance in noisy motor
applications
290mA source/600mA sink output current capability
Outputs tolerant to negative transients
Internal dead time to protect MOSFETs
Wide low side gate driver supply voltage: 10V to 20V
Logic input (IN and SD*) 3.3V capability
Schmitt triggered logic inputs
Undervoltage lockout for V
CC
(logic and low side supply)
Extended temperature range: -40°C to +125°C
Description
The TF2104M is a high voltage, high speed gate driver
capable of driving N-channel MOSFETs and IGBTs in a
half bridge configuration. TF Semi’s high voltage process
enables the TF2104M’s high side to switch to 600V in a
bootstrap operation.
The TF2104M logic inputs are compatible with standard
TTL and CMOS levels (down to 3.3V) to interface easily
with controlling devices. The driver outputs feature high
pulse current buffers designed for minimum driver cross
conduction.
The TF2104M is offered in PDIP-8 and SOIC-8(N) packages
and operate over an extended -40 °C to +125 °C temperature
range.
SOIC-8(N)
Applications
Motor Controls
DC-DC Converters
AC-DC Inverters
Motor Drives
PDIP-8
Ordering Information
PART NUMBER PACKAGE
TF2104M-3AS
PDIP-8
SOIC-8(N)
SOIC-8(N)
PACK / Qty
Tube / 50
Tube / 100
T&R / 2500
Y
ear
Y
ear
W
eek
W
eek
MARK
YYWW
TF2104M
Lot ID
YYWW
TF2104M
Lot ID
Typical Application
Up to 600V
TF2104M-TAU
TF2104M-TAH
V
CC
IN
SD*
R4
V
CC
IN
SD*
COM
V
B
HO
TO
LOAD
TF2104M
V
S
LO
www.tfsemi.com
Rev. 1.3
Jul
2019
1
Advance Info
TF2104M
Pin Diagrams
V
CC
IN
SD*
COM
1
2
3
4
8
7
6
5
V
B
HO
V
S
LO
Half-Bridge Gate Driver
Top View:
PDIP-8, SOIC-8
Pin Descriptions
PIN NAME
V
CC
IN
SD*
COM
LO
V
S
HO
V
B
PIN NUMBER
1
2
3
4
5
6
7
8
PIN DESCRIPTION
TF2104M
Logic and low side supply
Logic input for high-side and low-side gate driver outputs (HO and LO), in phase with HO
Logic input for shutdown, enabled low
Low-side and logic return
Low-side gate drive output
High-side floating supply return
High-side gate drive output
High-side floating supply
Functional Block Diagram
V
CC
TF2104M
UV
Detect
HV Level
Shift/
Pulse
Filter
UV
Detect
R
R
S
Q
V
B
Vcc
IN
Pulse
Gen
Dead
time
HO
Vs
High Voltage Well
V
CC
SD*
Delay
LO
COM
Jul
2019
2
Advance Info
TF2104M
Absolute Maximum Ratings
(NOTE1)
V
B
- High side floating supply voltage......................-0.3V to +624V
V
S
- High side floating supply offset voltage....V
B
-24V to V
B
+0.3V
V
HO
- High side floating output voltage...................V
S
-0.3V to V
B
+0.3V
dV
S
/ dt - Offset supply voltage transient...................................50 V/ns
V
CC
- Low-side fixed supply voltage...............................-0.3V to +24V
V
LO
- Low-side output voltage....................................-0.3V to V
CC
+0.3V
V
IN
- Logic input voltage (IN and SD*)..................-0.3V to V
CC
+0.3V
NOTE1
Stresses beyond those listed under “Absolute Maximum Ratings” may cause
permanent damage to the device. These are stress ratings only, and functional operation
of the device at these or any other conditions beyond those indicated in the operational
sections of the specifications is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect device reliability.
A
Half-Bridge Gate Driver
P
D
- Package power dissipation at T
A
≤ 25 °C
SOIC-8.............................................................................................0.625W
PDIP-8...................................................................................................1.0W
SOIC-8(N) Thermal Resistance
(NOTE2)
q
JA
...............................................................................................200 °C/W
PDIP-8 Thermal Resistance
(NOTE2)
q
JA
................................................................................................125 °C/W
T
J
- Junction operating temperature........................................+150 °C
T
L
- Lead Temperature (soldering, 10 seconds).......................+300 °C
T
stg
- Storage temerature ......................................................-55 to 150 °C
NOTE2
Thermal resistance and power dissipation ratings are measured under board
mounted and still air conditions.
Recommended Operating Conditions
Symbol
V
B
V
S
V
HO
V
CC
V
LO
V
IN
T
A
Parameter
High side floating supply absolute voltage
High side floating supply offset voltage
High side floating output voltage
Low side fixed supply voltage
Low side output voltage
Logic input voltage (IN and SD*)
Ambient temperature
MIN
V
S
+ 10
NOTE3
V
S
10
0
0
-40
MAX
V
S
+ 20
600
V
B
20
V
CC
5
125
Unit
V
V
V
V
V
V
°C
NOTE3
Logic operational for V
S
of -5V to +600V. Logic state held for V
S
of -5V to -V
BS
Jul
2019
3
Advance Info
TF2104M
DC Electrical Characteristics
(NOTE4)
V
BIAS
(V
CC
, V
BS
) = 15V, T
A
= 25 °C , unless otherwise specified.
Symbol
V
IH
V
IL
V
OH
V
OL
I
LK
I
BSQ
I
CCQ1
I
CCQ2
I
IN+
I
IN-
V
CCUV+
V
CCUV-
V
BSUV+
V
BSUV-
I
O+
I
O-
Parameter
Logic “1” (IN) & Logic “0” (SD*) input voltage
Logic “0” (IN) & Logic “1” (SD*) input voltage
High level output voltage, V
BIAS
- V
O
Low level output voltage, V
O
Offset supply leakage current
Quiescent V
BS
supply current
Quiescent V
CC
supply current
Quiescent V
CC
supply current in shutdown
Logic “1” input bias current
Logic “0” input bias current
V
CC
supply under-voltage positive going
threshold
V
CC
supply under-voltage negative going
threshold
V
BS
supply under-voltage positive going
threshold
V
BS
supply under-voltage negative going
threshold
Output high short circuit pulsed current
Output low short circuit pulsed current
V
O
= 0V, PW ≤ 10
ms
V
O
= 15V, PW ≤ 10
ms
Conditions
V
CC
= 10V to 20V
NOTE
5
Half-Bridge Gate Driver
MIN
2.5
TYP
MAX
Unit
0.8
0.05
0.02
0.2
0.1
50
60
350
590
3
100
500
750
10
5
8.0
7.4
4.5
4.2
130
270
8.9
8.2
5.5
5.2
290
600
9.8
9.0
6.5
6.2
V
I
O
= 2mA
I
O
= 2mA
VB = VS = 600V
V
IN
= 0V or 5V
IN =0V or 5V, SD*=5V
IN=0V or 5V, SD*=0V
IN = 5V, SD* = 0V
IN = 0V, SD* = 5V
mA
V
V
V
mA
NOTE4
The V
IN
, V
TH
, and I
IN
parameters are applicable to the two logic input pins: IN and SD*. The V
O
and I
O
parameters are applicable to the respective output pins: HO and LO
NOTE
5
For optimal operation, it is recommended that the input pulse (to IN and SD*) should have an amplitude of 2.5V minimum with a pulse
width of 840ns minimum
Jul
2019
4
Advance Info
TF2104M
AC Electrical Characteristics
Symbol
t
on
t
off
t
SD
t
DM
t
r
t
f
t
DT
Parameter
Turn-on propagation delay
Turn-off propagation delay
Shutdown propagation delay
Delay matching, HS & LS turn-on/turn-off
Turn-on rise time
Turn-off fall time
Deadtime: t
DT LO-HO
& t
DT HO-LO
V
S
= 0V
300
70
35
420
Half-Bridge Gate Driver
Conditions
V
S
= 0V
V
S
= 600V
MIN
TYP
680
150
160
MAX
820
220
220
60
170
90
650
ns
Unit
V
BIAS
(V
CC
, V
BS
) = 15V, C
L
= 1000pF, and T
A
= 25 °C , unless otherwise specified.
Jul
2019
5
