1U DUAL-SOCKET
POWER-EFFICIENT
SERVER
PLATFORM
B8226G24W4H (BTO)
B8226G24V4H
GT24-B8226
GOLD
Front View
Best 1U dual-socket SMP server
implementation with high power-efficiency
and overall performance
Dual C32 sockets support up to (2) AMD Opteron™ 4100/4200
series processors (Lisbon/Valencia)
Support (2) HyperTransport™ 3.0 link, max. bandwidth up to 25.6
GB/s @ 6.4GT/s per link
AMD SR5690 + SP5100
(12) 240-pin DDR3 DIMM slots support up to 96GB R-DDR3
1333/1066/800MHz w/ ECC memory
(1) FH/HL PCI-E (Gen.2) x16 slot
(1) FH/HL PCI-E (Gen.2) x16 slot
(3) GbE LAN
(4) Hot-swap 3.5" SAS 6G HDDs w/ RAID 0, 1, 1E, 10 support
(B8226G24W4H)
(4) Hot-swap 3.5" SATA-II HDDs w/ RAID 0, 1, 10, 5 support
(B8226G24V4H)
Onboard BMC w/ IPMI and iKVM support
(1) EPS1U high-efficiency (80-PLUS Gold) 500W PSU w/ PFC
Back View
Specifications are subject to change without notice. Items pictured may only be representative.
GT24-B8226
B8226G24W4H (BTO) / B8226G24V4H
Slim-type DVD-ROM Drive
(Opt.)
Hot-swap System FANs
(6) 4028
M1008
Front Panel Board
Specifications
S8226(W)GM3NR
(2) C32 (LGA1207) sockets
(6+6) R-DDR3 1333/1066/800MHz
Max.96GB, (3) GbEports
M2091
Provide (1) full-height
PCI-E (Gen. 2) x16 slotSlim
M2201-L16-2F
(1) FH/FL PCI-E G2 x16 slot (x16/x8)
+ (1) FH/FL PCI-E G2 x8 slot (x0/x8)
M1235
Integrated FAN board &
4-port SAS 6G/SATA-II
HDD backplane board
EPS1U 500W PSU,
80-PLUS Gold
GOLD
Form Factor
Chassis Name
System
1U Rackmount
GT24
S8226GM3NR (B8226G24V4H)
S8226WGM3NR (B8226G24W4H)
16 kg
(1) PWR (w/ LED) / (1) RST / (1) NMI / (1) ID
(1) ID / (1) Warning / (1) Reserved
(3) LAN
(2) USB ports
3.5" Hot-Swap / (4)
SATA-II 3.0Gb/s (B8226G24V4H)
SAS 6.0Gb/s (B8226G24W4H)
(5) 4cm fans
EPS1U
Full-range AC(100-240V)
47 - 63 Hertz
500 Watts
PFC / 80-PLUS Gold
Graphic
Storage
Dimension (H x W x D)
1.72" x 17.2" x 25.4" (43.6 x 436 x 645mm)
Motherboard
Gross Weight
Buttons
SAS
(opt.)
Controller
Speed
RAID
Controller
Speed
RAID
LSI SAS2008 (B8226G24W4H only)
6.0 Gb/s
RAID 0/1/1E/10 (LSI Integrated RAID)
AMD SP5100
3.0 Gb/s
RAID 0/1/10/5 (Promise RAID stack)
D-Sub 15-pin
1600x1200@60Hz
Aspeed AST2050
(5) USB2.0 ports (2 at rear, 2 at front, 1 type
A onboard)
(1) DB-9 port
(1) D-Sub 15-pin VGA port
(3) GbE ports
Winbond W83795G
Monitors voltage for CPU, memory, chipset &
power supply
Monitors temperature for CPU & system
environment
Fan fail LED indicator
Over temperature warning indicator
Watchdog timer support
Onboard Aspeed AST2050
SATA
Connector type
Resolution
Chipset
USB
Front Panel
LEDs
I/O Ports
External Drive
Bay
Type / Q'ty
Supported HDD
Interface
Input / Output
COM
VGA
RJ-45
Chipset
Voltage
System Cooling
FAN
Configuration
Type
Input Range
Power Supply
Frequency
Output Watts
Efficiency
System
Monitoring
Temperature
LED (On system front
panel)
Others
Onboard Chipset
AMD Opteron™ 4100/4200 series
Supported CPU Series
processors
Socket Type / Q'ty
Processor
Average CPU Power
(ACP) wattage
System Bus
Chipset
Chipset
Super I/O
Supported DIMM Qty
DIMM Type / Speed
Memory
Capacity
Memory channel
Memory voltage
PCI-E
Expansion Slots
Pre-installed TYAN
Riser Card
Port Q'ty
LAN
Controller
C32 / (2)
Up to 75W
Support (2) HyperTransport™ 3.0 link, max.
bandwidth up to 25.6GB/s @ 6.4GT/s per
link
AMD SR5690 + SP5100
Winbond W83627DHG-P
(6+6) DIMM slots
DDR3 1333/1066/800 RDIMM
Up to 96GB RDIMM
4 Channels (2 Channels per CPU)
1.5V/ 1.35V
(1) FH/HL PCI-E Gen.2 x16 slot
(1) FH/HL PCI-E Gen.2 x16 slot
M2091, PCI-E x16 1U riser card (left)
M2091-R, PCI-E x16 1U riser card (right)
(3)
Intel 82576EB
Intel 82574L
Operating
Environment
RoHS
BIOS
Server
Management
IPMI 2.0 compliant baseboard management
controller (BMC)
AST2050 IPMI Feature
BIOS update
USB 2.0 virtual hub
AST2050 iKVM Feature
Brand / ROM size
24-bit high quality video compression
Dual 10/100 Mb/s MAC interfaces
AMI / 4MB
Plug and Play (PnP)
PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot
ACPI 2.0 power management
Power on mode after power recovery
User-configurable H/W monitoring
Auto-configurable of hard disk types
Multiple boot options
Please refer to our OS supported list.
Class A
Yes
10° C ~ 35° C (50° F~ 95° F)
- 40° C ~ 70° C (-40° F ~ 158° F)
Feature
Operating System
OS supported list
Regulation
FCC (DoC)
CE (DoC)
Operating Temp.
Non-operating Temp.
In/Non-operating
MITAC INTERNATIONAL CORP.
TYAN Business Unit
USA
Tel: +1-510-651-8868
Fax: +1-510-651-7688
Taiwan
Tel: +886-2-2652-5888
Fax: +886-2-2652-5805
Japan
Tel: +81-3-3769-8311
Fax: +81-3-3769-8328
(Specifications are subject to change without
90%, non-condensing
may only be
notice. Items pictured
at 35° C
Humidity
representative.)
RoHS 6/6 Complaint
