4U WITH 9 NODES
HIGH DENSITY
SERVER
PLATFORM
FS65-B5521-X9
B5521F65X9-090PV6R / B5521F65X9-160PV6R
Front View
High Density Single-Socket Xeon Server
Platform for CDN/Web access/Web
hosting/Low-end web server applications
Each node has Single socket supports Intel® Sandy/Ivy Bridge (1)
E3-1200/i3-2100 series processors
Each node has Intel® C204 PCH
Each node has (4) 240-pin DDR3 DIMM slots support up to 32GB VLP
U-DDR3 1333/1066 memory
Each node has (3) GbE LAN
Each node has (6) 2.5" SATA HDDs
Onboard BMC w/ IPMI and iKVM support
(2+1) ERP1U high-efficiency ,80-PLUS Platinum 900W
(B5521F65X9-090PV6R SKU) or 1600W (B5521F65X9-160PV6R SKU)
PSU
Back View
Specifications are subject to change without notice. Items pictured may only be representative.
FS65-B5521-X9
B5521F65X9-090PV6R / B5521F65X9-160PV6R
Node TOP View
Specifications
Computing node
Form Factor
Chassis Name
System
Dimension (D x W x H)
Motherboard
Gross Weight
Buttons
LEDs
Front Panel
(Per Blade)
4U Rackmount Frame w/ 9x Blades
FS65
25.6" x 17.32" x 7.17" (650 x 440 x
175.7mm)
S5521GM3N
55 Kg
(1) PWR
(1) ID / (1) HDD
(2) USB ports / (1) D-Sub 15 pin port / (1) RJ-
45 port from Pass through module / (1) RJ45
LAN / (1) RJ-45 port consolidated, dedicate
IPMI LAN
(2) 2.5"
fixed
(height: 9mm) + (4) 2.5"
fixed
(height:
15mm) (B5521F65X9-090PV6R SKU) or
(2) 2.5"
fixed
(height: 15mm) +(4) 2.5"
fixed
(height:
15mm) (B5521F65X9-160PV6R SKU)
Storage node
LAN
(Per Blade)
Storage
(Per Blade)
Graphic
(Per Blade)
Port Q'ty
Controller
SATA
Controller
Speed
(3)
Intel 82574L / Intel I350-AM2
Intel® C204
(2) 6.0Gb/s (4) 3.0 Gb/s
D-Sub 15-pin
1600x1200 @60Hz
Aspeed AST2150
(2) USB2.0 ports
(1) D-sub 15-pin port
(1) port, from Pass through module / (1)
port, from blade
Winbond W83793G
Monitors temperature for CPU & system
environment
Fan fail LED indicator / Over temperature
warning indicator
Onboard Aspeed AST2150
IPMI 2.0 compliant baseboard management
controller (BMC) / USB 2.0 virtual hub / BIOS
update
24-bit high quality video compression / Dual
10/100 Mb/s MAC interfaces
AMI / 8MB
Multiple boot options / Plug and Play (PnP)
/PCI2.3 /WfM2.0 /SMBIOS2.3 /PXE boot /
ACPI 2.0 power management /Power on mode
after power recovery / User-configurable H/W
monitoring / Auto-configurable of hard disk
types
Please refer to our Intel OS supported list.
Class A
Yes
10° C ~ 35° C (50° F~ 95° F)
- 40° C ~ 70° C (-40° F ~ 158° F)
90%, non-condensing at 35° C
Yes
Connector type
Resolution
Chipset
USB
VGA
RJ-45
Chipset
I/O Ports
Input /Output
(Per Blade)
Internal Drive
Bay
(Per Blade)
Type / Q'ty
System
Monitoring
(Per Blade)
Temperature
LED
Onboard Chipset
Supported HDD Interface
SATA-III 6.0Gb/s + SATA-II 3.0Gb/s
System Cooling
Configuration
(Per Blade)
FAN
Type
Input Range
(8) 8cm hot-swap fans
ERP1U
100-127V/8A
200-240V/4A
47 - 63 Hertz
450 Watts(B5521F65X9-090PV6R SKU) or
800 Watts (B5521F65X9-160PV6R SKU)
80 plus Platinum
(2+1)
Intel Xeon E3-1200, i3-2100 (32nm / 22nm)
series processors
LGA 1155 / (1)
Max Up to 45W (B5521F65X9-090PV6R SKU) or
Max Up to 69W (B5521F65X9-160PV6R SKU)
Server
Management
(Per Blade)
AST2150 IPMI Feature
AST2150 iKVM Feature
Brand / ROM size
Power Supply
(Per Blade)
Frequency
Output Watts
Efficiency
Redundancy
Supported CPU Series
BIOS
(Per Blade)
Feature
Processor
(Per Blade)
Socket Type / Q'ty
Thermal Design Power
(TDP) wattage
Chipset
Supported DIMM Qty
Operating
System
Regulation
OS supported list
FCC (DoC)
CE (DoC)
Operating Temp.
Non-operating Temp.
In/Non-operating
Humidity
RoHS 6/6 Complaint
Chipset
(Per Blade)
INTEL C204
(4) DIMM slots
DDR3 VLP ECC 1066/1333 UDIMM / DDR3
VLP ECC 1066/1333/1600 UDIMM
Up to 32GB
2 Channels per CPU
1.5V
Operating
Environment
RoHS
Memory
(Per Blade)
DIMM Type / Speed
Capacity
Memory channel
Memory voltage
(Specifications are subject to change without notice. Items pictured may only be representative.)
