PERFORMANCE SPECIFICATION
Lower Frequency:
Upper Frequency:
Tuning Voltage:
Supply Voltage:
Output Power:
Supply Current:
Harmonic Suppression (2 Harmonic):
Pushing:
Pulling, all Phases:
Tuning Sensitivity:
Phase Noise @ 10kHz offset:
Phase Noise @ 100kHz offset:
Load Impedance:
Input Capacitance:
Operating Temperature Range:
Storage Temperature Range:
-40
-45
nd
MIN
220
0
2.85
-3.0
TYP
MAX
165
3.0
UNITS
MHz
MHz
VDC
VDC
dBm
mA
dBc
MHz/V
MHz pk-pk
MHz/V
dBc/Hz
dBc/Hz
3.0
0
10
-10
0.5
1.0
36
-109
-129
50
3.15
+3.0
15
500
+85
+90
pF
°C
°C
Phase Noise (1 Hz BW, Typical)
Tuning Curve (Typical)
Page 1 of 2
CRYSTEK
CORPORATION
12730 Commonwealth Drive • Fort Myers, Florida 33913
Phone: 239-561-3311 • 800-237-3061
Fax: 239-561-1025 • www.crystek.com
M I C
of Crystek Corporation
ROWAVE
A Division
Gold Finish
BOTTOM VIEW
[RF]
Solder Mask
0.020
(0.51)
SIDE VIEW
0.080
(2.03)
0.015
(0.38)
[Vcc]
0.079
(2.01)
0.025 0.050
(0.64) (1.27)
0.030
(0.76)
0.015
(0.38)
0.030
(0.76)
[Vt]
0.060
(1.52)
0.120
0.180
8
BOTTOM ORIENTATION MARK
TOP VIEW
0.300
(7.62)
9
0.240
7
6
5
0.240
0.180
10
11
PAD LOCATION
0.240
0.180
0.120
Pad
1
8
11
Others
Connection
Vt
RF-OUTPUT
Vcc
GROUND
CRYSTEK
CVCO33CL
0165-0220
YYWW
0.120
12
4
0.300
(7.62)
0
0
1
2
3
0.120
0.180
0.240
TOP ORIENTATION MARK
Unless otherwise specified,
Dimensions are in: IN
(mm)
Pad Location
Dimensions are in: Inches
TAPE AND REEL
0.059 Ø TYP
(1.50 Ø) TYP
0.157±0.004
(4.00±0.10)
0.630±0.012
(16.00±0.30)
DIRECTION OF FEED
0.472
(12.00)
Drawing not to scale
Product Control:
Crystek Part Number:
Revision Level:
CVCO33CL-0165-0220
D
Release Date:
Responsible:
23-Apr-12
C. Vales
Specification is subject to change without notice
Page 2 of 2
CRYSTEK
CORPORATION
12730 Commonwealth Drive • Fort Myers, Florida 33913
Phone: 239-561-3311 • 800-237-3061
Fax: 239-561-1025 • www.crystek.com
