RAVF164D1.61%R: DescriptionArray/Network Resistor, Isolated, Metal Glaze/thick Film, 0.5W, 50V, 1% +/-Tol, 200ppm/Cel, Surface Mount, CHIP, ROHS COMPLIANT; CategoryPassive components The resistor; File Size212KB，2 Pages; ManufacturerSEI(Stackpole Electronics Inc.); Websitehttps://www.seielect.com/; Environmental Compliance

Download Datasheet Parametric View All

RAVF164D1.61%R Overview

Array/Network Resistor, Isolated, Metal Glaze/thick Film, 0.5W, 50V, 1% +/-Tol, 200ppm/Cel, Surface Mount, CHIP, ROHS COMPLIANT

RAVF164D1.61%R Parametric

Parameter Name	Attribute value
Is it Rohs certified?	conform to
Maker	SEI(Stackpole Electronics Inc.)
package instruction	,
Reach Compliance Code	compli
ECCN code	EAR99
Component power consumption	0.063 W
The first element resistor	1.6 Ω
JESD-609 code	e3
Manufacturer's serial number	RAV
Installation features	SURFACE MOUNT
Network Type	ISOLATED
Number of components	1
Number of functions	4
Number of terminals	8
Maximum operating temperature	150 °C
Minimum operating temperature	-55 °C
Package shape	RECTANGULAR PACKAGE
method of packing	TR
Rated power dissipation(P)	0.5 W
Rated temperature	70 °C
Resistor type	ARRAY/NETWORK RESISTOR
surface mount	YES
technology	METAL GLAZE/THICK FILM
Temperature Coefficient	200 ppm/°C
Terminal surface	Matte Tin (Sn) - with Nickel (Ni) barrie
Terminal shape	WRAPAROUND
Tolerance	1%
Operating Voltage	50 V
Base Number Matches	1

Preview

Download Datasheet

View All

RAV Series — Convex Termination Chip Resistor Array

Features

• Thick film resistor element

• Multiple circuit types available

• Ideal SMD substitute for leaded networks

• Auto-placement capability

• Square corner construction standard

• Zero ohm jumper available

• RoHS compliant / lead-free available (RAVF) • RAV 324D is standard with scalloped

corner

Electrical Specifications

Type /

Code /

# of Elements /

Circuit Type

RAV 102D

RAV 104D

RAV 162D

RAV 164D

RAV 168D

RAV 324D

RAV 328N

RAV 328R

Power Rating

(per element)

@ 70°C

Power Rating

(Entire Array)

@ 70°C

Maximum

Working

Voltage*

Maximum

Overload

Voltage

Resistance

Temperature

Coefficient

±200 ppm/°C

±250 ppm/°C

±300 ppm/°C

±250 ppm/°C

±200 ppm/°C

±250 ppm/°C

±200 ppm/°C

Ohmic Range and Tolerance

1%

–

22Ω – 1MΩ

–

22Ω – 10KΩ

10Ω – 1MΩ

1.0Ω – 10MΩ

10Ω – 1MΩ

–

22Ω – 1MΩ

–

2%, 5%

10Ω – 1MΩ

–

1.0Ω – 9.9Ω

1.0Ω – 1MΩ

1.0Ω – 10MΩ

1.0Ω – 1MΩ

–

1.0Ω – 1MΩ

10Ω – 1MΩ

22Ω – 1MΩ

0.063W

0.125W

0.063W

0.125W

0.250W

0.125W

0.250W

0.500W

0.250W

0.500W

25V

50V

25V

200V

25V

50V

100V

50V

400V

50V

*Lesser of

√PR

or maximum working voltage.

Schematics

Isolated Circuit - 2D

Isolated Circuit - 4D

Isolated Circuit - 8D

Bussed Circuit - N

Bussed Circuit - R

4

3

8

5

16

9

10

6

10

6

1

2

1

4

1

8

1

5

1

5

How to Order

RAV

SEI Type

16

Code

4

# of Elements

D

Circuit Type

10K

Nominal Resistance

5%

Tolerance

R

Packaging

SEI Type

RAV

RAVF

Description

Convex

Convex RoHS

Code

10

16

32

Elements

2

4

8

Circuit Type

D = Isolated

N = Bussed

R = Bussed

Tolerance Values

1%

2%

5%

E24

SEI Types

102D, 104D

162D, 164D, 168D,

328N, 328R

324D

Pkg Qty Description Code

10,000

5,000

4,000

Reel

R

Toll Free: (888) SEI-SEIS

(888) 734-7347

www.seielect.com

27

email: marketing@seielect.com

Rev 09/08
