811-005-07_15 Overview

Mighty Mouse High Density

Series 811 Mighty Mouse High Density (HD)
Jam Nut PCB Receptacle Connectors
811-005-07 and 811-006-07 with PC Tails
Jam Nut PC Tail Receptacles
Series 811 Mighty Mouse High Density jam nut PCB
receptacles have straight PC tails for termination to flex circuits or rigid boards.
These receptacles are backpotted with epoxy. The TwistPin contact system meets
requirements of MIL-DTL-83513 and provides outstanding resistance to high
levels of shock and vibration. Choose solder-dipped or gold-plated tails. Select
811-006-07 with enhanced waterblocking for open face (unmated) immersion
requirements. Molded plastic endcap has standoffs. 3A current rating, 600 VAC
dielectric withstanding voltage.
How To Order
Sample Part Number
Series
Mighty Mouse
High Density
L
811-005-07
811-005-07
Series 811 rear panel mount jam nut receptacle, straight pc
tails, standard epoxy sealing
811-006-07
Series 811 rear panel mount jam nut receptacle, straight pc
tails, enhanced water blocking for open face (unmated) water immersion
ME
= Aluminum/Electroless Nickel
MT
= Aluminum/Nickel-PTFE
Z1
=
Stainless Steel/Passivated
5-7
= 7 Contacts
6-12
= 12 Contacts
P
= Pin Contacts
A
= Normal
MT
5-7
P
A
3
-.125
Material/Finish*
ZNU
= Aluminum/Black Zinc-Nickel
ZR
= Aluminum/Black Zinc-Nickel
9-42
= 42 Contacts
Shell Size - Insert Arr.
Contact Type
Key Position
PC Tail Finish
PC Tail Length
7-22
= 22 Contacts
8-30
= 30 Contacts
S
= Socket Contacts
Alternate Key Positions:
B, C, D, E, F
4
= Gold Plated
3
= Solder-Dipped in 63/37 Tin-Lead
.090, .125, .250
(Other lengths are readily available)
*
ZR
plating is RoHS compliat and non-reflective,
ZNU
plateing is non-reflective and passes 1,00 hours salt spray testing
C
CAVITY #1
PIN INSERT
MASTER KEYWAY
D THD
CAVITY #1
SOCKET INSERT
.870 (22.10)
.060 (1.52)
JAM NUT
.325
(8.26)
4X .020 (0.51)
Ø.018/.022
(0.46/0.56)
ØF
G
ØH
B
ØA
RED FULL MATE
INDICATOR STRIPE
E THD
O-RING
TAIL LENGTH
± .015 (0.38)
PLASTIC ENDCAP W/
MOLDED STANDOFFS
.100 (2.54) MAX PANEL THICKNESS
Dimensions
Shell
Size
5
6
7
8
9
ØA
In.
mm.
.575 14.61
.635
.755
.755
.830
16.13
19.18
19.18
21.08
B
In.
.350
.410
.536
.536
.596
mm.
8.89
10.41
13.61
13.61
15.14
In.
.545
.602
.723
.723
.791
C
mm.
13.84
D Thread
.3125-.05P-.1L-2A
E THD
UN-2A
.375-28
ØF
In. mm.
.350 8.89
.490
.600
.670
.770
12.45
15.24
17.02
19.56
Shell
Size
5
6
7
8
9
Panel Cutout
G
In.±.002 mm.±0.05
.356
9.04
.416
.542
.542
.602
10.57
13.77
13.77
15.29
In.±.002 mm.±0.05
.385
9.78
.447
.572
.572
.635
11.35
14.53
14.53
16.13
15.29 .3750-.05P-.1L-2A .4375-28
18.36 .4375-.05P-.1L-2A .5625-32
18.36 .5000-.05P-.1L-2A .5625-32
20.09 .5625-.05P-.1L-2A
.625-28
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
1211 AIR WAY
GLENDALE, CA 91201-2497
818-247-6000
FAX 818-500-9912
www.glenair.com
L-12
