Series 824
Locking Push-Pull Mighty Mouse Plug
824-001 and 824-003 Ordering Information
Series 824 Locking Push/Pull Connector
mates and locks with a straight push.
To de-mate connectors release locking mechanism by pulling back on release ring.
Rugged locking mechanism withstands 50 pound (223 N) pull force. Aluminum shell,
liquid crystal polymer insulators, gold-plated copper alloy contacts, copper alloy locking
mechanism, fluorosilicone O-ring and wire seal. The Series 824 is ideal for sensors,
chargers, vision systems and weaponry where accidental connector disengagement
is not an option. Supplied with contacts packaged separately. Contacts are crimp
type, snap-in, rear release. Series 824 connectors are compatible with standard Mighty
Mouse tools and accessories.
How To Order
Sample Part Number
Series
Shell Style
G
ØA
Series 824
New!
824-001
824-001
= Locking Push-Pull plug with shield termination platform
-06
= In-Line Cable Plug
ME
= Aluminum / Electroless Nickel; RoHS Compliant
MT
= Aluminum / Nickel-PTFE RoHS Compliant
C
= Aluminum / Electroless Nickel
NF
= Aluminum / Cadmium with Olive Drab Chromate
-06
M
6-7
P
A
Shell Material and Finish
ZN
= Aluminum / Zinc-Nickel with Olive Drab over Electroless Nickel
ZNU
= Aluminum / Zinc-Nickel with Black over Electroless Nickel
Shell Size - Insert Arrangement
See page G-3
Contact Type
Shell Key Positions
(See Table I)
Connector supplied
with Crimp contacts
P
= Pin
S
= Socket
Omit
= Single Master Key
Connector supplied
without contacts
A
= Pin Connector, less contacts
B
= Socket Connector, less contacts
A
= Normal
B
= Pos. B
C
= Pos. C
Connector Supplied
with 30 AWG Crimp Barrel
G
= #23 Pin
H
= #23 Socket
D
= Pos. D
E
= Pos. E
F
= Pos. F
Blue Alignment Stripe
.433
(11.00)
1.485 (37.72)
.479
(12.17)
ØB
ØC
Table I: Alternate Key Positions
Pos.
A
A° B°
Dimensions
Size 9 - 12
A°
140°
30°
30°
110°
140°
B°
220°
220°
250°
330°
330°
Shell Size
5
6
7
8
9
10
12
ØA
in
0.487
0.539
0.614
0.679
0.742
0.807
0.934
mm
12.37
13.69
15.60
17.25
18.85
20.50
23.72
in
0.609
0.661
0.736
0.801
0.864
0.929
1.056
ØB
mm
15.47
16.79
18.69
20.35
21.95
23.60
26.82
in
0.230
0.296
0.390
0.436
0.493
0.570
0.683
ØC
mm
5.84
7.52
9.91
11.07
12.52
14.48
17.35
Size 5 - 8
A°
150°
45°
45°
140°
150°
B°
210°
210°
230°
315°
315°
B
C
D
E
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
