ULTRAFAST, LOW SWITCHING LOSS RECTIFIER DIODE

Preview

Download Datasheet

View All

UNISONIC TECHNOLOGIES CO., LTD

BYC5

Preliminary

DIODE

ULTRAFAST, LOW SWITCHING

LOSS RECTIFIER DIODE



DESCRIPTION

The UTC

BYC5

is a rectifier diode. It provides the designers with

ultra-fast switching and low switching loss.

The UTC

BYC5

is suitable for half-bridge lighting ballasts,

half-bridge/full-bridge switched mode power supplies and active power

factor correction applications.



FEATURES

* Low Reverse Recovery Current

* Ultra-Fast Switching

* Low Switching Loss

* Low Thermal Resistance



SYMBOL

TO-220-2

TO-252



ORDERING INFORMATION

Pin Assignment

Packing

Tube

Tape Reel

Ordering Number

Package

Lead Free

Halogen Free

BYC5L-6-TA2-T

BYC5G-6-TA2-T

TO-220-2

BYC5L-6-TN3-T

BYC5G-6-TN3-T

TO-252

BYC5L-6-TN3-R

BYC5G-6-TN3-R

TO-252

Note: Pin Assignment: A: Anode K: Cathode Tab: Mounting Base



MARKING

www.unisonic.com.tw

1 of 3

QW-R601-024.d
