Mighty Mouse
High-Speed
Connector with Triple-Start ACME
Threads to Straight or 90° Industry Standard SATA Connector
805-118 Ordering Information
805-118: Series 805 Mighty Mouse
High-Speed
SATA Overmolded Cordset
"LENGTH" MIN (SEE P/N DEVELOPMENT)
P1
PROTECTIVE COVER,
667-261 OR 667-262
SHRINK BOOT,
809S060-2
"PART NUMBER"
GLENAIR YYWW 06324
BRADY LABEL,
LAT-18 OR EQ.
APPROX LOCATION:
CENTER OF CABLE
L-COM SATA
CABLE ASSY,
CASATA
P2
GLENAIR HIGH-SPEED CONNECTOR,
805-020-16 PLUG (REF) OR
805-022-01 RECEPTACLE (REF)
8-7 INSERT ARRANGEMENT
(GROMMET REMOVED)
L-COM R/A SATA
CABLE ASSY,
CASATAR
How To Order
Sample Part Number
Series
Table I: Shell Key Positions
-A
NF
N
A
S
-48
805-118
805-116
= Series 805 Mighty
Mouse to SATA Overmolded
cordset.
-A
= Plug with Pin Contacts
-B
= Plug with Socket Contacts
-C
= Receptacle with Pin Contacts
B°
A°
P1 Connector
Shell Material / Finish
Protective Cover
Shell Key Position (See Table I)
P2 Connector Configuration
Length
-D
= Receptacle with Socket Contacts
M
= Aluminum / Electroless Nickel RoHS
Compliant
NF
= Aluminum / Cadmium with Olive Drab
Chromate
ZNU
= Aluminum / Zinc-Nickel with Black
Chromate
MT
= Aluminum / Nickel-PTFE, RoHS
Compliant
Z1
= Stainless Steel / Passivated RoHS
Compliant
P
= Metal Protective Covers Included
N
= No Covers Supplied
A
(Normal),
B, C, D, E, F
R
= Right-Angle
S
= Straight
Overall Length In Inches
WIRING DIAGRAM
DRAIN
WHT 26 AWG
WHT 26 AWG
DRAIN
DRAIN
WHT 26 AWG
WHT 26 AWG
DRAIN
Key Position
Normal (A)
B
C
D
E
F
Key Rotation
A°
150°
75°
95°
140°
75°
95°
B°
210°
210°
230°
275°
275°
210°
P1
6
1
2
7
5
4
3
P2
1
2
3
4
5
6
7
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
R-17
E-Mail: sales@glenair.com
Series 805
High-Speed
Series 805 SATA Cordsets
