Transfer Terminated Electromechanical Relay
Switch DC to 18 GHz, SMA, 240 Watts, 28V Control,
30V Indicator with Indicators, Latching
TECHNICAL DATA SHEET
PE71S6061
The PE71S6061 is a DOUBLE POLE THREE THROW TERMINATED RF COAXIAL RELAY SWITCH that operates from DC
TO 18 GHz. The Switch has a 28 VDC LATCHING ACTUATOR and POSITION INDICATOR CIRCUITRY. The Switch has
SMA RF CONNECTORS and operates from -40 Deg C to +85 Deg C.
Features
•
•
•
•
Double Pole Three Throw Terminated Relay Switch
DC to 18 GHz Frequency Range
2M Operating Life
100 Watt Avg Power Min
• -40 to +85 Deg C Operating Temperature
• Insertion Loss 0.5 dB Max
• VSWR 1.5:1 Max
Applications
• High Performance Relay Switch
• Military Communications
• Communications Systems
• Test & Measurement
Electrical Specifications
Frequency Range
Impedance
Actuator
Actuating Current
Control Voltage
Indicator Rating
RF Characteristic
Description
Frequency Range
VSWR
Insertion Loss
Isolation
Average Power @25 °C
.
DC to 18 GHz
50 Ohms
Indicators, Latching
160 mA
28 Volts / Negative Common
1 Watts / 30 Volts / 100 mA
Band 1
DC to 3
1.2:1
0.2
80
240
Band 2
3 to 8
1.3:1
0.3
70
150
Band 3
8 to 12.4
1.4:1
0.4
60
120
Band 4
12.4 to 18
1.5:1
0.5
60
100
Band 5
Units
GHz
dB
dB
Watts
Mechanical Specifications
Connector Type
Operating Life
Terminals
Switching Time (nominal voltage, 25°C)
Construction
SMA Female
2,000,000
Solder Pins
<10 ms Typ
Splashproof
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications:
Transfer Terminated Electromechanical Relay Switch DC to 18 GHz, SMA, 240 Watts, 28V
Control, 30V Indicator with Indicators, Latching PE71S6061
PE71S6061 REV 1.0
1
Transfer Terminated Electromechanical Relay
Switch DC to 18 GHz, SMA, 240 Watts, 28V Control,
30V Indicator with Indicators, Latching
TECHNICAL DATA SHEET
Environmental Specifications
Temperature
Operating Range
Storage Range
.
PE71S6061
-40 to +85 deg C
-55 to +85 deg C
0.22 lbs [99.79 g]
Weight
Compliance Certifications
(visit www.Pasternack.com for current document)
RoHS Compliant
Plotted and Other Data
Notes:
• Values at +25 °C, sea level
• ESD Sensitive Material, Transport material in Approved ESD bags. Handle only in approved ESD Workstation
Transfer Terminated Electromechanical Relay Switch DC to 18 GHz, SMA, 240 Watts, 28V Control, 30V Indicator with
Indicators, Latching from Pasternack Enterprises has same day shipment for domestic and International orders. Our RF,
microwave and millimeter wave products maintain a 99% availability and are part of the broadest selection in the industry.
Click the following link (or enter part number in “SEARCH” on website) to obtain additional part information including price,
inventory and certifications:
Transfer Terminated Electromechanical Relay Switch DC to 18 GHz, SMA, 240 Watts, 28V Control,
30V Indicator with Indicators, Latching PE71S6061
URL:
http://www.pasternack.com/sma-transfer-terminated-electromechanical-relay-switch-18-ghz-indicators-pe71s6061-p.
aspx
PE71S6061 REV 1.0
2
PE71S6061
CAD Drawing
Transfer Terminated Electromechanical Relay Switch DC to 18 GHz, SMA,
240 Watts, 28V Control, 30V Indicator with Indicators, Latching
PE71S6061 REV 1.0
3
PE71S6061
CAD Drawing
Transfer Terminated Electromechanical Relay Switch DC to 18 GHz, SMA,
240 Watts, 28V Control, 30V Indicator with Indicators, Latching
PE71S6061 REV 1.0
4
