o-Ring Panel Sealing
Glass-Sealed D-Subminiature Connector
O-Ring Material
See Table III
(Omit for Viton
®
)
280-014
MIL-DTL-24308/9 Type Hermetic
MIL-DTL-24308
Type
Connector
Style
Shell Size
280
-
014
MIL-DTL-24308/9
D-Subminiature
Hermetic
H
1
P
-
1
Contact Style
(Pin Only)
P
= Solder Cup
X
= Eyelet
Class
H
= Carbon Steel/
Tin Plated
K
= Z16 - Stainless
Steel/Nickel
Plated, Dull Finish
J
R.062
Typ
TERMINATION
VIEW
4-40 UNC-2B
X .100 DP
(Typ 2 Pl)
O-Ring
.238 Max
H
ENGAGEMENT
VIEW
10°
D
Typ
Ø.040 ±.001
F
25° Typ
Eyelets
Mounting
Holes
(See Table II)
.161 Max
K
C
B
A
G
#4-40 UNC-2B
X .125 Min
Full Thread
E
Insert Arrangements Shown
Are For Reference Only
APPLICATION NOTES
1.
2.
3.
To be identified with manufacturer’s name, part number and date
code, space permitting.
Contact Style: Eyelet or solder cup (see part development).
Material/Finish:
Shell: H = FT - Carbon steel/tin plated
.
4.
Performance:
DWV - 500 VAC Pin-to-Shell
I.R. - 5,000 MegOhms Min @ 500 VDC
Hermeticity - <1 x 10
-7
scc He/sec @1
atmosphere differential
Glenair 280-014 will mate with any QPL MIL-DTL-24308/1, /2
and /23 receptacle of the same size and arrangement.
Metric dimensions (mm) are indicated in parentheses.
K = Z16 - Stainless steel/nickel plated dull finish.
Insulators: Glass bead/N.A.
Contacts: Alloy 52/gold plated
O-Ring: Specify (see Table III)/N.A.
5.
6.
Dimensions in Inches (millimeters) are subject to change without notice.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
J-18
E-Mail: sales@glenair.com
o-Ring Panel Sealing
Glass-Sealed D-Subminiature Connector
TABLE III: O-RING
MATERIAL
Dash
Number
None
-1
-2
-3
Material
Viton
®
Nitrile
Fluorosilicone
Silicone
1
1 2 3 4 5
6 7 8 9
1 2 3 4 5 6 7 8
9 10 11 12 13 14 15
2
1 2 3 4 5 6 7 8 9 10 11 12 13
14 15 16 17 18 19 20 21 22 23 24 25
3
9 CONTACTS
15 CONTACTS
25 CONTACTS
SOLDER CUP ORIENTATION
4
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19
20 21 22 23 24 25 26 27 28 29 30 31 32 33 34 35 36 37
5
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17
18
33
34 35 36 37 38 39 40 41 42 43 44 45 46 47 48 49 50
37 CONTACTS
50 CONTACTS
SIZES 1-4
SIZE 5
TABLE I: CONNECTOR DIMENSIONS
Shell
Size
1
2
3
4
5
Dim
A
± .015
(± 0.4)
1.213 (30.8)
1.541 (39.1)
2.088 (53.0)
2.729 (69.3)
2.635 (66.9)
Dim
B
± .004
(± 0.1)
.667 (16.9)
.993 (25.2)
1.535 (39.0)
2.183 (55.4)
2.079 (52.8)
Dim
C
± .005
(± 0.1)
.984 (25.0)
1.312 (33.3)
1.852 (47.0)
2.500 (63.5)
2.406 (61.1)
Dim
D
± .004
(± 0.1)
.330 (8.4)
.330 (8.4)
.330 (8.4)
.330 (8.4)
.441 (11.2)
Dim
E
± .010
(± 0.3)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.600 (15.2)
.610 (15.5)
Dim
F
± .010
(± 0.3)
.874 (22.2)
1.270 (32.3)
1.760 (44.7)
2.418 (61.4)
2.418 (61.4)
Dim
G
± .010
(± 0.3)
.272 (6.9)
.372 (9.5)
.372 (9.5)
.372 (9.5)
.372 (9.5)
Dim
H
± .006
(± 0.2)
.155 (3.9)
.155 (3.9)
.160 (4.1)
.160 (4.1)
.160 (4.1)
Dim
K
± .010
(± 0.3)
.235 (6.0)
.235 (6.0)
.230 (5.8)
.230 (5.8)
.230 (5.8)
O-Ring
2-
-017
-022
-027
-031
-031
RECOMMENDED PANEL CUTOUT
SEE TABLE II
C
XA
Ø.120/.115
Typ 2 Pl
YA
R.062 Max
Typ
FRONT MOUNT
TABLE II: PANEL CUT-OUT
Shell
Size
1
2
3
4
5
Dim
XA
.520 (13.2)
.850 (21.6)
1.380 (35.1)
2.035 (51.7)
1.850 (47.0)
Dim
YA
.220 (5.6)
.300 (7.6)
.300 (7.6)
.300 (7.6)
.320 (8.1)
Dim
C
.674 (17.1)
1.070 (27.2)
1.560 (39.6)
2.200 (55.9)
2.200 (55.9)
HERMETIC LEAK RATE MOD CODES
Designator
–585A
–585B
–585C
Required Leak Rate
1 x 10
-10
cc Helium per second
1 x 10
-9
cc Helium per second
1 x 10
-8
cc Helium per second
Dimensions in Inches (millimeters) are subject to change without notice.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
J-19
E-Mail: sales@glenair.com
MIL-DTL-24308
MIL-DTL-24308
Type
280-014
MIL-DTL-24308/9 Type Hermetic
J
