USB 2.0 Type A Receptacle
to Size 22D Crimp Removable Contacts • Size 15
Basic
Number
Connector
Style
(See Below)
USB 2.0
USB
Orientation
H
= Horizontal
V
= Vertical
Shrink Boot
Part No. 770-028
(Omit for None)
233-341
NF 00 15
Shell Size
15
2
A
N
H
T
Finish
NF
= Cadmium Olive Drab
M
= Electroless Nickel
MT
= Nickel PTFE
USB Type A
Front Interface
Alternate Key Position
Per MIL-DTL-38999
A, B, C, D, E
N
= Normal
Connector Styles
00
= Receptacle, Wall Mount
with Slotted Holes
07
= Receptacle, Jam Nut Mount
G6
= Plug
Jam Nut Receptacle
Front View
Square Flange Receptacle
Rear View
1.300 (33.02) Max
.823 (20.90)
.768 (19.51)
USB 2. 0
Special Arrangement
4 x Size 23 Cavities
(Type A)
3
2
Plug
Front View
4
USB Orientation Options
(Partial Views Shown)
4
1
Receptacle
Plug
Square Flange Receptacle
1.300 (33.02) Max
.890 (22.61) Max
.579 (14.71)
.555 (14.10)
1
4
1.300 (33.0) Max
Horizontal
Horizontal
Ø1.280 (32.51)
Max
.085 (2.16)
Max
Gromme t
Ø .803 (20.40)
.797 (20.24)
Vertical
Vertical
All External Dimensions,
Features, etc. compliant with
D38999/20, /24 & /26.
Consult Factory for Additional Information
© 2013 Glenair, Inc.
Jam Nut
U.S. CAGE Code 06324
Rev. 01.13.15
Plug
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
C-7
E-Mail: sales@glenair.com
D38999 Type
USB Connectors
233-341
USB SuperSeal™ D38999 Series III Type Connectors
C
1
4
4
1
