Remarks: 1. The asterisk in the part number WD1811∗ for the silicon rubber type rubber cap is where the letter representing the color should be inserted.
(B: black; R: red; Z: grey; Y: yellow; G: green.)
2. EP rubber cap is available in black only.
3. Letters on the display panel are aluminum colored and the area surrounding the letters is black.
4. Indication plate and rubber cap are compatible with the T-15 series switch, T-10 series switch, and T-03/T-06 series switches
(when plate thickness is 2.7 mm or less).
ROCKER PRODUCT TYPES
1. Standard type
1) Solder terminal, without indication on actuator
Number of poles
Kind of operation
< >: Momentary position
ON-OFF
ON-ON
ON-OFF-ON
ON-<ON>
<ON>-OFF-<ON>
ON-OFF-<ON>
ON-OFF
ON-ON
2-pole
ON-OFF-ON
ON-<ON>
<ON>-OFF-<ON>
ON-OFF-<ON>
Solder terminal
Product No.
TR115A-∗F
TR115D-∗F
TR115E-∗F
TR115F-∗F
TR115G-∗F
TR115H-∗F
TR215K-∗F
TR215N-∗F
TR215P-∗F
TR215R-∗F
TR215S-∗F
TR215T-∗F
1-pole
2) Screw terminal, without indication on actuator
Number of poles
Kind of operation
< >: Momentary position
ON-OFF
ON-ON
ON-OFF-ON
ON-<ON>
<ON>-OFF-<ON>
ON-OFF-<ON>
ON-OFF
ON-ON
ON-OFF-ON
ON-<ON>
<ON>-OFF-<ON>
ON-OFF-<ON>
Screw terminal
Product No.
TR115A-S∗F
TR115D-S∗F
TR115E-S∗F
TR115F-S∗F
TR115G-S∗F
TR115H-S∗F
TR215K-S∗F
TR215N-S∗F
TR215P-S∗F
TR215R-S∗F
TR215S-S∗F
TR215T-S∗F
1-pole
2-pole
3) Solder terminal, with ON-OFF indication on actuator
Number of poles
1-pole
2-pole
Kind of operation
< >: Momentary position
ON-OFF
ON-OFF
Solder terminal
Product No.
TR115A-∗F
TR215K-∗F
Remark: Please specify the actuator color by replacing the asterisk in the product number with appropriate letter. (B: black; W: white; R: red; Z: dark grey)
