230-039
MIL-DTL-26500 Type Hermetic Class Receptacle
Single Hole Mount, Bayonet Coupling, MS24265H*B* Type
MIL-DTL-26500
Type
How To Order:
Commercial
Connector Material / Finish
FT
- Cold Rolled Steel - Fused Tin Finish
Z1
- Stainless Steel - Passivate Finish
ZL
- Stainless Steel - Nickel Plated
Insert Arrangement
Per MIL-STD-1554
See Pages F-2 – F-3
Alternate Key Position
6, 7, 8, 9, 10
(Omit for Normal)
230-039
FT
12
-
Shell Size
See Table I
3
P
6
F
Basic Series
Contact Termination
P
- Pin, Solder Cup
X
- Pin, Eyelet
A
ØA
FF
.376
(9.6)
.366
(9.3)
90°
ØD
Shell I.D.
1
3
2
1
JJ
Mounting
Flat
B
2
3
.125 (3.2)Max
Thick Panel
Jam Nut
Per Table
A
Ø CØCC
Min
ØBB
ØF
ØCC
EE
AA
Thickness
W Flange
Thickness
N Thread
ØG
Max
.781 (19.8)
.761 (19.3)
.481
(12.2)
.461
(11.7)
Ø E Max
Resilient
Insert
Section A - A
Painted Bayonet
Pin Ends
Marking Location
Optional
Dimensions in Inches (millimeters) are subject to change without notice.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
F-12
E-Mail: sales@glenair.com
Single Hole Mount, Bayonet Coupling, MS24265H*B* Type
TABLE I: Shell Size, Connector Dimensions and Panel Cut-Out
Shell
Size
8
10
12
14
16
18
20
22
24
ØA
Max
B
ØC
Min
.493 (12.5)
ØD
Shell I.D.
.433/.428
(11.0/10.9)
.535/.530
(13.6/13.5)
.705/.700
(17.9/17.8)
.774/.769
(19.7/19.5)
.901/.896
(22.9/22.8)
1.007/1.002
(25.6/25.5)
1.132/1.125
(28.8/28.6)
ØE
Resilient
Insert
.312 (7.9)
.388 (9.9)
.558 (14.2)
.627 (15.9)
.772 (19.6)
.860 (21.8)
.985 (25.0)
ØF
.536/.531
(13.6/13.5)
.659/.654
(16.7/16.6)
.829/.824
(21.1/20.9)
.898/.893
(22.8/22.7)
ØG
Max
.561 (14.2)
.696 (17.7)
.875 (22.2)
N
Thread
.625-20 UN-2A
.750-20 UNEF 2A
.937-20 UNEF-2A
JJ
Mounting
Flat
.596/.590
(15.1/15.0)
.721/.715
(18.3/18.2)
.908/.902
(23.1/22.9)
.971/.965
(24.7/24.5)
Flange
Thickness
W ± .020 (0.5)
.117 (3.0)
.117 (3.0)
.117 (3.0)
.117 (3.0)
.117 (3.0)
.117 (3.0)
.117 (3.0)
.148 (3.8)
.148 (3.8)
Panel
Cut-Out
EE
Panel
Cut-Out
FF
Jam
Nut
MS3186
-105
-107
-110
-111
-112
-116
-117
-120
-121
1.068 (27.1) .979 (24.9)
.605 (15.4) .635 (16.1)
.730 (18.5) .760 (19.3)
.917 (23.3) .947 (24.1)
.980 (24.9) 1.010 (25.7)
1.105 (28.1) 1.135 (28.8)
1.229 (31.2) 1.260 (32.0)
1.354 (34.4) 1.385 (35.2)
1.497 (38.0) 1.510 (38.4)
1.604 (40.7) 1.635 (41.5)
1.192 (30.3) 1.104 (28.0) .555 (14.1)
1.380 (35.1) 1.291 (32.8) .743 (18.9)
1.505 (28.2) 1.391 (35.3) .805 (20.4)
1.630 (41.4) 1.516 (38.5) .931 (23.6)
1.765 (44.8) 1.641 (41.7) 1.055 (26.8)
1.860 (47.2) 1.766 (44.9) 1.243 (31.6)
2.068 (52.5) 1.954 (49.6) 1.305 (33.1)
2.160 (54.9) 2.079 (52.8) 1.493 (37.9)
.935 (23.7) 1.000-20 UNEF-2A
1.096/1.090
1.025/1.020
1.062 (27.0) 1.125-20 UNEF-2A
(27.8/27.7)
(26.0/25.9)
1.220/1.214
1.131/1.126
1.187 (30.1) 1.250-18 UNEF-2A
(31.0/30.8)
(28.7/28.6)
1.345/1.339
1.256/1.251
1.312 (33.3) 1.375-18 UNEF-2A
(34.2/34.0)
(31.9/31.8)
1.470/1.464
1.381/1.376
1.257/1.252
1.437 (36.5) 1.500-18 UNEF-2A
1.110 (28.2)
(37.3/37.2)
(35.1/35.0)
(31.9/31.8)
1.595/1.589
1.506/1.501
1.382/1.377
1.562 (39.7) 1.625-18 UNEF-2A
1.235 (31.4)
(40.5/40.4)
(38.3/38.1)
(35.1/35.0)
TABLE II: Contacts
Con-
tact
Size
12
12
16
16
20
20
Contact
Type
Cup
Eyelet
Cup
Eyelet
Cup
Eyelet
AA
--
.035 (0.9)
--
.025 (0.6)
--
.015 (0.4)
ØØ BB
.150 (3.8)
--
.103 (2.6)
--
.077 (2.0)
--
ØØ CC
Min
.112 (2.8)
--
.069 (1.8)
--
.042 (1.1)
--
DD
--
.200 (5.1)
--
.125 (3.2)
--
.080 (2.0)
FF
Max
.235 (6.0)
.235 (6.0)
.235 (6.0)
.235 (6.0)
.165 (4.2)
.165 (4.2)
EE
FF
APPLICATION NOTES
1.
2.
3.
Assembly identified with manufacturer’s name and part number, space
permitting.
Glenair 230-039 will mate with any QPL MIL-DTL-MS24266 type
bayonet coupling plug of same size, keyway and insert polarization.
Performance:
Hermeticity - <x10
-7
ccHe/sec @ 1 atmosphere differential
Dielectric withstanding voltage - consult factory or MIL-STD-1554
Insulation resistance - 5000 megohms min @ 500VDC
4.
Material/ Finish:
Shell and Jam Nut––specified by class
Pin contacts—nickel-iron alloy 52/gold
Bayonets––Cres/Passivated
Contacts—52 Nickel alloy/Gold plated
Insulators—Glass/NA
Seals—fluorosilicone elastomer N.A.
Metric Dimensions (mm) are indicated in parentheses.
5.
Dimensions in Inches (millimeters) are subject to change without notice.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
F-13
E-Mail: sales@glenair.com
MIL-DTL-26500
Type
230-039
MIL-DTL-26500 Type Hermetic Class Receptacle
