82D
Vishay Sprague
Aluminum Capacitors
+ 85 °C, Snap-In, General Purpose
FEATURES
•
Economical
•
General purpose design
•
Wide voltage range
Fig.1 Component Outlines
QUICK REFERENCE DATA
DESCRIPTION
Nominal case size
Ø D x L in inches (mm)
Operating temperature
Rated capacitance
range, C
R
Tolerance on C
R
Rated voltage range,
U
R
Termination
Life validation test
at 85 °C
VALUE
1.38 x 3.15 (35.0 x 80.0)
- 40 °C to + 85 °C
39 µF to 180 000 µF
± 20 %
6.3 WVDC to 450 WVDC
Snap-in
2000 h:
ΔCAP ≤
15 % from initial
measurement.
ΔESR ≤
1.5 x initial
specified limit.
ΔDCL ≤
initial specified
limit
500 h:
ΔCAP ≤
15 % from initial
measurement.
ΔESR ≤
1.3 x initial
specified limit.
ΔDCL ≤
2 x initial
specified limit
I = K CV
DC leakage current
K = 4.0 at + 25 °C
I in µA, C in µF, V in Volts
RIPPLE CURRENT MULTIPLIERS
TEMPERATURE
AMBIENT TEMPERATURE
- 55 °C
- 65 °C
- 75 °C
- 85 °C
FREQUENCY (Hz)
WVDC
16 to 49
50 to 199
200 to 400
50 TO 60
0.85
0.83
0.80
300 TO 1000
1.10
1.15
1.30
1000 AND UP
1.15
1.20
1.40
MULTIPLIERS
2.0
1.7
1.4
1.0
Shelf life at 85 °C
ESL (TYPICAL VALUES AT 1 MHz TO 10 MHz)
Nominal
Diameter
Typical
ESL (nH)
0.98
(25.0)
8.0
1.18
(30.0)
10.0
1.38
(35.0)
12.0
DIMENSIONS
in inches (millimeters)
CASE
CODE
JA
JB
JC
JD
JE
KA
KB
KC
DIAMETER
D + 0.04 - 0 (+ 1.0 - 0)
1.00 (25.0)
1.00 (25.0)
1.00 (25.0)
1.00 (25.0)
1.00 (25.0)
1.18 (30.0)
1.18 (30.0)
1.18 (30.0)
LENGTH
L ± 0.08 (2.0)
1.00 (25.0)
1.18 (30.0)
1.38 (35.0)
1.57 (40.0)
2.00 (50.0)
1.00 (25.0)
1.18 (30.0)
1.38 (35.0)
CASE
CODE
KD
KE
MB
MC
MD
ME
MF
MG
DIAMETER
D + 0.04 - 0 (+ 1.0 - 0)
1.18 (30.0)
1.18 (30.0)
1.38 (35.0)
1.38 (35.0)
1.38 (35.0)
1.38 (35.0)
1.38 (35.0)
1.38 (35.0)
LENGTH
L ± 0.08 (2.0)
1.57 (40.0)
2.00 (50.0)
1.18 (30.0)
1.38 (35.0)
1.57 (40.0)
2.00 (50.0)
2.50 (63.0)
3.18 (80.0)
www.vishay.com
262
For technical questions, contact: aluminumcaps4@vishay.com
Document Number: 42062
Revision: 05-Feb-09
82D
Aluminum Capacitors
+ 85 °C, Snap-In, General Purpose
DIMENSIONS
in inches (millimeters)
CIRCUIT BOARD MOUNT TERMINAL DIMENSIONS
DIAMETER
D
1.00 (25.0)
1.18 (30.0)
1.38 (35.0)
CASE CODE
J
K
M
B
0.093 (2.4)
0.125 (3.2)
0.125 (3.2)
STYLE A
R
0.301 (7.6)
0.363 (9.2)
0.458 (11.6)
C
140°
120°
120°
STYLE B
R
N/A
0.391 (9.9)
0.458 (11.6)
Vishay Sprague
DIMENSIONS AND AVAILABLE FORMS
Style A
Style B
Style D
Document Number: 42062
Revision: 05-Feb-09
For technical questions, contact: aluminumcaps4@vishay.com
www.vishay.com
263
82D
Vishay Sprague
Aluminum Capacitors
+ 85 °C, Snap-In, General Purpose
TERMINAL CONFIGURATION
in inches (millimeters)
LEAD
CODE
OUTLINE DRAWINGS
DESCRIPTION
MOUNTING
CONFIGURATION
TERMINAL
CONFIGURATION
AVAILABLE
DIAMETERS
AVAILABLE
VOLTAGES AND
TYPES
D
Standard
2 pin snap-in
0.98 (25.0) - J
1.18 (30.0) - K
1.38 (35.0) - M
All voltages
81D, 81DA
82D, 82DA
A
2 straight wire lead
molded cover with
standoffs
+
0.98 (25.0) - J
1.18 (30.0) - K
1.38 (35.0) - M
All voltages
82D, 82DA
V
≤
250 V
DC
81D, 81DA
All voltages
82D, 82DA
B
3 straight wire lead
molded cover with
standoffs
+
1.18 (30.0) - K
1.38 (35.0) - M
V
≤
250 V
DC
81D, 81DA
ORDERING EXAMPLE
Electrolytic capacitor 82D series:
82D 122 M 050 HA 2 D E3
DESCRIPTION
CODE
82D
122
M
050
HA
2
D
E3
EXPLANATION
Product type
Capacitance value (1200 µF)
Tolerance (M = ± 20 %)
Voltage rating at 85 °C (50 V)
Can size (see dimensions table)
PVC insulating sleeve
Terminal style (D = 2 pin snap-in)
RoHS compliant
ELECTRICAL DATA AND ORDERING INFORMATION
CAPACITANCE
(µF)
PART NUMBER
NOMINAL CASE SIZE
DxL
MAX. ESR at 25 °C (mΩ)
120 H
Z
20 kH
Z
to 40 kH
Z
MAX. RIPPLE at + 85 °C (A)
120 H
Z
20 kH
Z
to 40 kH
Z
16 WVDC at + 85 °C, SURGE = 20 V
15 000.0
22 000.0
33 000.0
33 000.0
47 000.0
6800.0
10 000.0
15 000.0
82D153M016JC2DE3
82D223M016KB2DE3
82D333M016KD2DE3
82D333M016MC2DE3
82D473M016MD2DE3
82D682M025JB2DE3
82D103M025JD2DE3
82D153M025JE2DE3
0.984 x 1.378 (25.0 x 35.0)
1.181 x 1.181 (30.0 x 30.0)
1.181 x 1.575 (30.0 x 40.0)
1.378 x 1.378 (35.0 x 35.0)
1.378 x 1.575 (35.0 x 40.0)
0.984 x 1.181 (25.0 x 30.0)
0.984 x 1.545 (25.0 x 40.0)
0.984 x 1.969 (25.0 x 50.0)
58.0
53.7
35.3
28.0
23.0
67.0
43.4
33.9
43.0
41.0
27.0
21.0
17.0
47.0
31.0
24.0
3.33
3.70
5.00
5.96
6.86
2.94
4.22
4.97
3.87
4.20
5.77
6.87
6.65
3.49
4.96
5.96
25 WVDC at + 85 °C, SURGE = 30 V
www.vishay.com
264
For technical questions, contact: aluminumcaps4@vishay.com
Document Number: 42062
Revision: 05-Feb-09
82D
Aluminum Capacitors
+ 85 °C, Snap-In, General Purpose
ELECTRICAL DATA AND ORDERING INFORMATION
CAPACITANCE
(µF)
PART NUMBER
NOMINAL CASE SIZE
DxL
MAX. ESR at 25 °C (mΩ)
120 H
Z
71.0
54.0
36.4
23.0
72.0
46.6
36.3
75.0
37.7
36.0
25.0
85.0
53.6
85.0
43.0
28.0
22.0
121.0
72.0
57.0
68.0
34.0
36.0
188.0
136.0
106.0
66.0
625.0
271.0
498.0
294.0
221.0
142.0
189.0
149.0
20 kH
Z
to 40 kH
Z
54.0
41.0
27.0
17.0
47.0
30.0
24.0
54.0
27.0
24.0
16.3
48.0
31.0
54.0
24.0
16.0
13.0
63.0
38.0
30.0
41.0
22.0
20.0
86.0
66.0
52.0
33.0
272.0
121.0
192.0
136.0
87.0
67.0
93.0
74.0
MAX. RIPPLE at + 85 °C (A)
120 H
Z
3.00
3.70
5.00
6.84
2.82
4.08
4.87
2.92
4.89
4.97
6.57
2.61
3.79
2.73
4.56
6.21
7.60
2.05
2.97
3.69
3.28
5.56
5.24
1.75
2.31
2.75
4.02
0.967
1.79
1.21
1.64
2.14
2.89
2.46
2.88
20 kH
Z
to 40 kH
Z
3.47
4.20
5.77
7.96
3.49
5.08
5.96
3.42
5.77
6.10
8.13
3.49
4.96
3.42
6.10
8.21
9.87
2.86
4.09
5.08
4.20
6.89
7.04
2.59
3.31
3.95
5.69
1.46
2.68
1.96
2.48
3.41
4.22
3.51
3.41
Vishay Sprague
25 WVDC at + 85 °C, SURGE = 30 V
6800.0
10 000.0
15 000.0
22 000.0
4700.0
6800.0
10000.0
4700.0
12 000.0
10 000.0
15 000.0
2200.0
3900.0
2700.0
4700.0
6800.0
10 000.0
1500.0
2200.0
3300.0
3300.0
6800.0
4700.0
680.0
1000.0
1500.0
2200.0
220.0
470.0
330.0
470.0
680.0
1000.0
820.0
1000.0
82D682M025KA2DE3
82D103M025KB2DE3
82D153M025KD2DE3
82D223M025MD2DE3
82D472M035JB2DE3
82D682M035JD2DE3
82D103M035JE2DE3
82D472M035KA2DE3
82D123M035KD2DE3
82D103M035MB2DE3
82D153M035MD2DE3
82D222M050JB2DE3
82D392M050JD2DE3
82D272M050KA2DE3
82D472M050MB2DE3
82D682M050MD2DE3
82D103M050ME2DE3
82D152M063JA2DE3
82D222M063JC2DE3
82D332M063JD2DE3
82D332M063KB2DE3
82D682M063KE2DE3
82D472M063MC2DE3
82D681M100JB2DE3
82D102M100KB2DE3
82D152M100KC2DE3
82D222M100KE2DE3
82D221M200JA2DE3
82D471M200JD2DE3
82D331M200KA2DE3
82D471M200KB2DE3
82D681M200KD2DE3
82D102M200KE2DE3
82D821M200MC2DE3
82D102M200MD2DE3
1.181 x 0.984 (30.0 x 25.0)
1.181 x 1.181 (30.0 x 30.0)
1.181 x 1.575 (30.0 x 40.0)
1.378 x 1.575 (35.0 x 40.0)
0.984 x 1.181 (25.0 x 30.0)
0.984 x 1.575 (25.0 x 40.0)
0.984 x 1.969 (25.0 x 50.0)
1.181 x 0.984 (30.0 x 25.0)
1.181 x 1.575 (30.0 x 40.0)
1.378 x 1.181 (35.0 x 30.0)
1.378 x 1.575 (35.0 x 40.0)
0.984 x 1.181 (25.0 x 30.0)
0.984 x 1.575 (25.0 x 40.0)
1.181 x 0.984 (30.0 x 25.0)
1.378 x 1.181 (35.0 x 30.0)
1.378 x 1.575 (35.0 x 40.0)
1.378 x 1.969 (35.0 x 50.0)
0.984 x 0.984 (25.0 x 25.0)
0.984 x 1.378 (25.0 x 35.0)
0.984 x 1.575 (25.0 x 40.0)
1.181 x 1.181 (30.0 x 30.0)
1.181 x 1.969 (30.0 x 50.0)
1.378 x 1.378 (35.0 x 35.0)
0.984 x 1.181 (25.0 x 30.0)
1.181 x 1.181 (30.0 x 30.0)
1.181 x 1.378 (30.0 x 35.0)
1.181 x 1.969 (30.0 x 50.0)
0.984 x 0.984 (25.0 x 25.0)
0.984 x 1.575 (25.0 x 40.0)
1.181 x 0.984 (30.0 x 25.0)
1.181 x 1.181 (30.0 x 30.0)
1.181 x 1.575 (30.0 x 40.0)
1.181 x 1.969 (30.0 x 50.0)
1.378 x 1.378 (35.0 x 35.0)
1.378 x 1.575 (35.0 x 40.0)
35 WVDC at + 85 °C, SURGE = 40 V
50 WVDC at + 85 °C, SURGE = 63 V
63 WVDC at + 85 °C, SURGE = 79 V
100 WVDC at + 85 °C, SURGE = 125 V
200 WVDC at + 85 °C, SURGE = 250 V
Document Number: 42062
Revision: 05-Feb-09
For technical questions, contact: aluminumcaps4@vishay.com
www.vishay.com
265
82D
Vishay Sprague
Aluminum Capacitors
+ 85 °C, Snap-In, General Purpose
ELECTRICAL DATA AND ORDERING INFORMATION
CAPACITANCE
(µF)
PART NUMBER
NOMINAL CASE SIZE
DxL
MAX. ESR at 25 °C (mΩ)
120 H
Z
513.0
382.0
281.0
209.0
132.0
3020.0
2060.0
1430.0
820.0
630.0
3280.0
1730.0
1150.0
870.0
510.0
20 kH
Z
to 40 kH
Z
189.0
121.0
117.0
74.0
58.0
1720.0
1176.0
820.0
470.0
360.0
1730.0
915.0
610.0
460.0
274.0
MAX. RIPPLE at + 85 °C (A)
120 H
Z
1.13
1.51
1.92
2.43
3.32
0.44
0.56
0.76
1.10
1.39
0.42
0.65
0.89
1.14
1.68
20 kH
Z
to 40 kH
Z
1.94
2.79
3.07
4.26
5.21
0.58
0.74
1.00
1.46
1.85
0.58
0.89
1.22
1.56
2.29
250 WVDC at + 85 °C, SURGE = 300 V
220.0
330.0
470.0
680.0
1000.0
68.0
100.0
150.0
220.0
330.0
56.0
100.0
150.0
220.0
330.0
Note
• Additional Part Numbers in stock include 82D472M050JE2DE3 and 82D681M250MD2DE3. Many other capacitance ratings and voltages are
available upon request. Please call for a quotation.
82D221M250JB2DE3
82D331M250JD2DE3
82D471M250MB2DE3
82D681M250MD2DE3
82D102M250ME2DE3
82D680M400JA2DE3
82D101M400JB2DE3
82D151M400KB2DE3
82D221M400KD2DE3
82D331M400MD2DE3
82D560M450JA2DE3
82D101M450JC2DE3
82D151M450KC2DE3
82D221M450MC2DE3
82D331M450ME2DE3
0.984 x 1.181 (25.0 x 30.0)
0.984 x 1.575 (25.0 x 40.0)
1.378 x 1.181 (35.0 x 30.0)
1.378 x 1.575 (35.0 x 40.0)
1.378 x 1.969 (35.0 x 50.0)
0.984 x 0.984 (25.0 x 25.0)
0.984 x 1.181 (25.0 x 30.0)
1.181 x 1.181 (30.0 x 30.0)
1.181 x 1.575 (30.0 x 40.0)
1.378 x 1.575 (35.0 x 40.0)
0.984 x 0.984 (25.0 x 25.0)
0.984 x 1.378 (25.0 x 35.0)
1.181 x 1.378 (30.0 x 35.0)
1.378 x 1.378 (35.0 x 35.0)
1.378 x 1.969 (35.0 x 50.0)
400 WVDC at + 85°C, SURGE = 450 V
450 WVDC at + 85°C, SURGE = 500 V
www.vishay.com
266
For technical questions, contact: aluminumcaps4@vishay.com
Document Number: 42062
Revision: 05-Feb-09
京公网安备 11010802033920号
EEWORLD
