BC807 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > semiconductor> Discrete semiconductor> BC807

BC807: Description800 mA, 45 V, PNP, Si, SMALL SIGNAL TRANSISTOR; Categorysemiconductor Discrete semiconductor; File Size293KB，2 Pages; ManufacturerKingtronics; Websitehttp://www.kingtronics.com

Download Datasheet Parametric View All

BC807 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	BC807	-	-	View	Buy Now

BC807 Overview

800 mA, 45 V, PNP, Si, SMALL SIGNAL TRANSISTOR

BC807 Parametric

Parameter Name	Attribute value
Number of terminals	3
Transistor polarity	PNP
Maximum collector current	0.8000 A
Maximum Collector-Emitter Voltage	45 V
Processing package description	SOT-23, 3 PIN
state	DISCONTINUED
packaging shape	Rectangle
Package Size	SMALL OUTLINE
surface mount	Yes
Terminal form	GULL WING
Terminal location	pair
Packaging Materials	Plastic/Epoxy
structure	single
Number of components	1
transistor applications	switch
Transistor component materials	silicon
Maximum ambient power consumption	0.3100 W
Transistor type	Universal small signal
Minimum DC amplification factor	60
Rated crossover frequency	100 MHz

Preview

Download Datasheet

View All

BC807

PNP Silicon Epitaxial Planar

Transistors

For switching, AF driver and amplifier applications

These transistors are subdivided into three groups

-16, -25 and -40, according to their current gain.

As complementary types the NPN transistors BC817

and BC818 are recommended.

1.Base 2.Emitter

3.Collector

SOT-23 Plastic Package

Absolute Maximum Ratings (T

= 25℃)

PARAMETER

Collector Base Voltage

Collector Emitter Voltage

Emitter Base Voltage

Collector Current

Power Dissipation

Thermal Resistance Junction to Ambient Air

Junction Temperature

Storage Temperature Range

SYMBOL

-V

CBO

-V

CEO

-V

EBO

-I

tot

ØJA

VALUE

500

200

500

150

- 55 to + 150

UNIT

K/W

℃

Electrical Characteristics at T

= 25℃

PARAMETER

DC Current Gain

at -V

= 1 V, - I

= 100 mA

Current Gain Group

-16

-25

-40

SYMBOL

MIN.

100

160

250

TYP.

MAX.

250

400

600

100

0.7

1.2

UNIT

at -V

= 1 V, - I

= 500 mA

Collector Base Cutoff Current

at -V

= 20 V

Emitter-Base Cutoff Current

at -V

= 5 V

Collector Saturation Voltage

at -I

= 500 mA, -I

= 50 mA

Base-Emitter Voltage

at -I

= 500 mA, -V

= 1 V

Gain-Bandwidth Product

at -V

= 5 V, - I

= 10 mA, f = 50 MHz

Collector-Base Capacitance

at -V

= 10 V, f = 1 MHz

-I

CBO

-I

EBO

-V

CEsat

-V

BE(on)

CBO

MHz

Website: www.kingtronics.com

Email: info@kingtronics.com

Tel: (852) 8106 7033

Fax: (852) 8106 7099
