PRODUCT SUMMARY
SKY77629-51 Multimode Multiband Power Amplifier Module
for Quad-Band GSM/EDGE – Hepta-Band (I, II, III, IV, V, VIII,
and 20) WCDMA / HSDPA / HSUPA / HSPA+ / LTE
Applications
•
Quad-band cellular handsets:
-
Class 4 GSM850 / EGSM900
-
Class 1 DCS1800 / PCS1900
-
Class E2 GSM850 / EGSM900 / DCS1800 / PCS1900
-
Class 12 multi-slot EGPRS
•
Multiband 3G handsets
•
CDMA/ WCDMA/ HSDPA/ HSUPA/ LTE -modulated handsets for
Bands I, II, III, IV, V, VIII
Description
The SKY77629-51 is a hybrid, multimode multiband (MMMB)
Power Amplifier Module (PAM) that supports 2.5G and 3G/4G
handsets and operates efficiently in GSM, EGPRS, EDGE, CDMA,
WCDMA, and LTE modes. The PAM consists of a GSM 800 / EGSM
900 PA block, a DCS1800 / PCS1900 PA block, separate WCDMA
blocks operating in low and high bands, a logic control block for
multiple power control levels, and band enable functions in both
cellular and UMTS. RF I/O ports are internally matched to 50
Ω
to
minimize the number of external components. Extremely low
leakage current maximizes handset standby time. The
InGaP/GaAs die and passive components are mounted on a multi-
layer laminate substrate and the assembly encapsulated in plastic
overmold.
GSM/ EDGE:
The SKY77629-51 uses a new compact architecture
supporting the GSM850, EGSM900, DCS1800 and PCS1900
bands. The PAM also supports 2.5G Class 12 Enhanced General
Packet Radio Service (EGPRS) multi-slot operation and EDGE
linear modulation.
WCDMA:
The SKY77629-51 uses an enhanced architecture to:
support WCDMA, High-Speed Downlink Packet Access (HSDPA),
High-Speed Uplink Packet Access (HSUPA), and LTE modulations;
cover multiple bands for 3GPP, including bands I, II, IV, V, and VIII;
operate at different power modes. The module is fully controllable
via MIPI interface.
LTE:
The SKY77629-51 meets spectral linearity requirements of
LTE modulation with QPSK/16QAM up to 20 MHz bandwidth,
including various resource block allocations, with good power-
added efficiency
Figure 1 is a functional block diagram of the SKY77629-51
module.
Features
•
Hybrid architecture: separate GSM, WCDMA paths
•
50 ohm input and output impedances, integrated DC blocking
on all ports
•
Separate single-ended GSM and WCDMA inputs and outputs
•
CMOS-compatible, two-wire MIPI logic inputs (SCLK, SDATA)
•
VCC stages for 2.5G can attach to battery or buck DC/DC
•
Low capacitance VCC interface for 3G/4G supports Envelope
Tracking compatibility
•
Optimized Low Power Mode for ultra-low quiescent current
•
Small, low profile package:
-
7 mm x 5 mm x 0.9 mm
-
42-pad configuration
2.5G FEATURES:
-
EGPRS Class 12 multi-slot operation
-
Four RF POUT control levels using RFFE interface
-
Linear PA with bias optimization for efficiency/linearity trade-
off in 8-PSK mode
3G FEATURES:
-
WCDMA mode supports output power, bandwidth for
bands I, II, III, IV, V, VIII (and sub-bands IX, X, XVIII, IXX, XX,
XXVI) through an integrated band-select switch
-
Digital bias optimization through RFFE interface for best
efficiency/linearity tradeoff
-
Optimized for envelope tracking system
4G FEATURES:
-
Optimized for Envelope Tracking system
-
LTE supports output power bandwidth bands 1, 2, 3, 4, 5, 8
(and sub-bands 9, 10, 18, 19, 20, 26)
Skyworks Solutions, Inc. Phone [781] 376-3000 Fax [781] 376-3100 sales@skyworksinc.com www.skyworksinc.com
203079A • Skyworks Proprietary and Confidential information • Products and Product Information are Subject to Change Without Notice • January 8, 2014
1
Ordering Information
Product Name
SKY77629-51 Multimode Multiband Power Amplifier Module
Order Number
SKY77629-51
Evaluation Board Part Number
EN40-D695-002
