Silicon NPN Power Transistors

JMnic
Product Specification
Silicon NPN Power Transistors
2SC3151
DESCRIPTION
・With
TO-3PN package
・High
breakdown voltage (V
CBO
≥900V)
・Fast
switching speed
・Wide
ASO(Safe Operating Area)
APPLICATIONS
・800V/1.5A
Switching Regulator Applications
PINNING
PIN
1
2
3
Base
Collector;connected to
mounting base
Emitter
Fig.1 simplified outline (TO-3PN) and symbol
DESCRIPTION
Absolute maximum ratings (Ta=25
)
SYMBOL
V
CBO
V
CEO
V
EBO
I
C
I
CM
I
B
P
C
T
j
T
stg
PARAMETER
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Collector current-peak
Base current
Collector power dissipation
Junction temperature
Storage temperature
T
C
=25℃
Open emitter
Open base
Open collector
CONDITIONS
VALUE
900
800
7
1.5
5
0.8
60
150
-55~150
UNIT
V
V
V
A
A
A
W
