CMPT930
SURFACE MOUNT
NPN SILICON TRANSISTOR
w w w. c e n t r a l s e m i . c o m
DESCRIPTION:
The CENTRAL SEMICONDUCTOR CMPT930 type is
an NPN silicon transistor manufactured by the epitaxial
planar process, epoxy molded in a surface mount
package, designed for small signal general purpose
and switching applications.
MARKING CODE: C1X
SOT-23 CASE
MAXIMUM RATINGS:
(TA=25°C)
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Continuous Collector Current
Power Dissipation
Operating and Storage Junction Temperature
Thermal Resistance
SYMBOL
VCBO
VCEO
VEBO
IC
PD
TJ, Tstg
Θ
JA
UNITS
V
V
V
mA
mW
°C
°C/W
45
45
5.0
30
350
-65 to +150
357
ELECTRICAL CHARACTERISTICS:
(TA=25°C unless otherwise noted)
SYMBOL
TEST CONDITIONS
MIN
ICBO
VCB=45V
ICEO
ICES
IEBO
BVCBO
BVCEO
BVEBO
VCE(SAT)
VBE(SAT)
hFE
hFE
hFE
fT
Cob
NF
VCE=5.0V
VCE=45V
VEB=5.0V
IC=10μA
IC=10mA
IE=10μA
IC=10mA, IB=0.5mA
IC=10mA, IB=0.5mA
VCE=5.0V, IC=10μA
VCE=5.0V, IC=500μA
VCE=5.0V,
VCE=5.0V,
VCB=5.0V,
IC=10mA
IC=500mA, f=30MHz
IE=0, f=1.0MHz
MAX
10
10
10
10
UNITS
nA
nA
nA
nA
V
V
V
V
V
45
45
5.0
1.0
0.6
100
150
30
8.0
3.0
1.0
300
600
MHz
pF
dB
VCE=5.0V, IC=10mA, RS=10kΩ,
f=10Hz to 15.7kHz
R5 (27-January 2010)
