V637ME02-LF

PHASE NOISE (1 Hz BW, typical)

14118 Stowe Drive, Suite B

Poway, CA 92064

TEL: (858) 621-2700 | FAX: (858) 486-1927

URL: www.zcomm.com

EMAIL: applications@zcomm.com

Rev D5

-70

-80

-90

£(f) (dBc/Hz)

Voltage-Controlled Oscillator

Surface Mount Module

Applications

• CATV

• Portable Communications

• RF Modems

-100

-110

-120

-130

-140

Application Notes

• AN-101: Mounting and Grounding

• AN-102: Output Loading

• AN-107: Manual Soldering

-150

1 E+3

10 E+3

100 E+3

OFFSET (Hz)

Performance Specifications

Oscillation Frequency Range

Phase Noise @ 10 kHz offset (1 Hz BW)

Harmonic Suppression (2nd)

Tuning Voltage

Tuning Sensitivity (avg.)

Power Output

Load Impedance

Input Capacitance

Pushing

Pulling (14 dB Return Loss, Any Phase)

Operating Temperature Range

Package Style

Min

450

Typ

-104

-5

Max

900

Units

MHz

dBc/Hz

dBc

0.5

8.5

150

Vdc

MHz/V

dBm

MHz/V

MHz

°C

-40

MINI-14S

Power Supply Requirements

Supply Voltage (Vcc, nom.)

Supply Current (Icc)

Min

Typ

Max

Units

Vdc

Additional Notes

LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
