V585ME68-LF
PHASE NOISE (1 Hz BW, typical)
14118 Stowe Drive, Suite B
Poway, CA 92064
TEL: (858) 621-2700 | FAX: (858) 486-1927
URL: www.zcomm.com
EMAIL: applications@zcomm.com
Rev A1
Applications
• Digital Radios
• Earthstations
• Satellite Modems
Application Notes
• AN-101: Mounting and Grounding
• AN-102: Output Loading
• AN-107: Manual Soldering
OFFSET (Hz)
Performance Specifications
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW)
Harmonic Suppression (2nd)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance
Pushing
Pulling (12 dB Return Loss, Any Phase)
Operating Temperature Range
Package Style
£(f) (dBc/Hz)
Voltage-Controlled Oscillator
Surface Mount Module
Min
1625
Typ
-100
-15
Max
2325
Units
MHz
dBc/Hz
dBc
1
55
0
5
50
20
10
500
4
1
Vdc
MHz/V
dBm
pF
MHz/V
MHz
°C
-40
MINI-16-L
85
Power Supply Requirements
Supply Voltage (Vcc, nom.)
Supply Current (Icc)
Min
Typ
10
20
Max
24
Units
Vdc
mA
Additional Notes
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 1 of 2
FRM-S-002 B
Voltage-Controlled Oscillator
Surface Mount Module
Tuning Curve, typ.
2490
2430
2370
2310
2250
2190
2130
2070
2010
1950
1890
1830
1770
1710
1650
1590
1530
1470
1410
1350
0
1
2
3
4
5
6
7
8
9 10 11 12 13 14 15 16 17 18 19 20
V585ME68-LF
Rev A1
FREQUENCY (MHz)
85 °C
25 °C
-40 °C
TUNING VOLTAGE (Vdc)
Power Curve, typ.
POWER OUTPUT (dBm)
RECOMMENDED FOOTPRINT
10
Footprint
8
6
SEVERAL HOLES OF O 0.015 ON
GND. PLANE ARE RECOMMENDED
FOR GOOD GROUNDING.
4
2
0.030 MIN. CUTBACK
FROM LIVE PADS
0
1393
1583
1710
1829
1941
2051
2161
2264
2352
2420
2465
FREQUENCY (MHz)
85 °C
25 °C
-40 °C
Physical Dimensions
PIN CONFIGURATION
P1
P2
P3
REST
Vt
RF OUT
Vcc
GROUND
H
0.220
0.160
0.130
0.100
0.085
Z-COMM
XXXXXXXX-LF
W/O#
D/C
PACKAGE
MINI-16
MINI-16-LOW
MINI-16-L
MINI-16-UL
MINI-16-EL
NOTE: ALL DIMENSIONS ARE IN INCHES
TOL: XXX: +/- 0.010
LFSuffix = RoHS Compliant. All specifications are subject to change without notice.
© Z-Communications, Inc. All Rights Reserved.
Page 2 of 2
FRM-S-002 B
