AZ833
MICROMINIATURE
POLARIZED RELAY
FEATURES
•
Microminiature size: up to 50% less board area than
previous generation telecom relays
•
High dielectric and surge voltage:
2.5 KV surge (per Bellcore TA–NWT–001089)
1.5 KV surge (per FCC Part 68)
1,000 Vrms, open contacts
•
Low power consumption: 79 mW pickup
•
Stable contact resistance for low level signal switching
•
Epoxy sealed
•
UL, CUR file E43203
•
All plastics meet UL94 V–O, 30 min. oxygen index
CONTACTS
Arrangement
Ratings
Discontinuation date:
Date of last order:
Recommended replacement:
31.12.2012
30.06.2012
AZ8462
DPDT (2 Form C)
Bifurcated crossbar contacts
Resistive load:
Max. switched power: 60 W or 62.5 VA
Max. switched current: 2.0 A
Max. switched voltage: 220 VDC or 250 VAC
Rated Load
UL/CSA
0.25 A at 240 VAC
0.5 A at 125 VAC
2.0 A at 30 VDC
0.3 A at 110 VDC
on
t
Silver nickel gold plated
Silver palladium available upon request
79 mW
1.0 W at 20°C (68°F)
At nominal coil voltage
18°C (32°F)
Max. 110°C (230°F)
Shock
Weight
Material
COIL (Polarized)
Power
At Pickup Voltage
(typical)
Max. Continuous
Dissipation
sc
Temperature Rise
Temperature
Di
NOTES
1. All values at 20°C (68°F).
2. Relay may pull in with less than “Must Operate” value.
3. Relay has fixed coil polarity.
4. Specifications subject to change without notice.
ZET
TLER
electronics GmbH
Tel. +49 89 800 97 0
Fax +49 89 800 97 200
office@ZETTLERelectronics.com
www.ZETTLERelectronics.com
2005-08-04
Junkersstrasse 3, D-82178 Puchheim, Germany
in
u
GENERAL DATA
Life Expectancy
Mechanical
Electrical
Operate Time
(typical)
Release Time (typical)
Bounce (typical)
Dielectric Strength
(at sea level)
Dropout
Insulation Resistance
Ambient Temperature
Operating
Storage
Vibration
Max. Solder Temp.
Max. Solder Time
Max. Solvent Temp.
Max. Immersion Time
Enclosure
Terminals
Packing unit in pcs
THT
SMT
ed
!
Minimum operations
1 x 10
8
1 x 10
5
at 0.5 A, 125 VAC, resistive
2 x 10
5
at 1.0 A, 30 VDC, resistive
3 ms at nominal coil voltage
2 ms at nominal coil voltage
(with no coil suppression)
At 10 mA contact current
1 ms at operate or release
See table
Greater than 10% of nominal coil voltage
10
9
ohms min. at 25°C, 500 VDC,
50% RH
At nominal coil voltage
-40°C (-40°F) to 85°C (185°F)
-40°C (-40°F) to 105°C (221°F)
Operational, 35 g, 10–1000 Hz
Operational, 50 g min., 11 ms
Non-destructive, 150 g min., 11 ms
See soldering profile
See soldering profile
80°C (176°F)
30 seconds
2.3 grams
P.B.T. polyester
Tinned copper alloy, P.C.
50 per plastic tube / 1000 per carton box
400 per reel / 2000 per carton box
Discontinuation Notice
AZ833
RELAY ORDERING DATA
STANDARD RELAYS
Nominal Coil
VDC
3
4.5
5
6
9
12
24
Must Operate
VDC
2.25
3.38
3.75
4.50
6.75
9.00
18.00
Max. Continuous
VDC
6.5
9.8
10.9
13.0
19.6
26.2
52.3
Discontinuation date:
Date of last order:
Recommended replacement:
31.12.2012
30.06.2012
AZ8462
Coil Resistance
Ohm ± 10%
64.3
145
178
257
578
1,029
4,114
in
u
AZ833–24DE
INITIAL DIELECTRIC STRENGTH (minimum)
VRMS, 1 min.
Between open contacts
Between contact sets
Between coil and contacts
1,000
1,000
Peak (V)
1,500
1,500
1,800
2,500
LOAD LIMIT CURVE
V
Di
sc
ZET
TLER
electronics GmbH
Tel. +49 89 800 97 0
Fax +49 89 800 97 200
office@ZETTLERelectronics.com
www.ZETTLERelectronics.com
2005-08-04
Junkersstrasse 3, D-82178 Puchheim, Germany
on
t
RECOMMENDED SOLDERING PROFILE
Convection Soldering
ed
!
Order Number
THT
Through Hole
AZ833–3DE
AZ833–5DE
AZ833–6DE
AZ833–9DE
SMT
Long
AZ833S1–3DE
SMT
Short
AZ833S2–3DE
AZ833–4.5DE
AZ833S1–4.5DE
AZ833S1–5DE
AZ833S1–6DE
AZ833S1–9DE
AZ833S2–4.5DE
AZ833S2–5DE
AZ833S2–6DE
AZ833S2–9DE
AZ833–12DE
AZ833S1–12DE
AZ833S2–12DE
AZ833S1–24DE
AZ833S2–24DE
SURGE
Rise Time (µS)
10
2
2
Decay Time* (9µS) (1/2 peak)
160
160
10
* Decay time measured from beginning of surge.
