DNLS320E
LOW V
CE(SAT)
NPN SURFACE MOUNT TRANSISTOR
Please click here to visit our online spice models database.
Features
•
•
•
•
•
•
•
•
Epitaxial Planar Die Construction
Low Collector-Emitter Saturation Resistance R
CE(SAT)
= 80mΩ at 3A
High DC Current Gain h
FE
> 400 at I
C
= 2A
Complementary PNP Type Available (DPLS325E)
Ideally Suited for Automated Assembly Processes
Ideal for Medium Power Switching or Amplification Applications
Lead Free By Design/RoHS Compliant (Note 1)
"Green" Device (Note 2)
3
2
1
4
SOT-223
COLLECTOR
2,4
BASE 1
3
EMITTER
NEW PR ODUC T
EW P R ODUCT
3 E
C 4
2 C
1 B
Mechanical Data
•
•
•
•
•
•
•
Case: SOT-223
Case Material: Molded Plastic, "Green" Molding Compound.
UL Flammability Classification Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020D
Terminals: Finish — Matte Tin annealed over Copper Leadframe
(Lead Free Plating). Solderable per MIL-STD-202, Method 208
Marking Information: See Page 3
Ordering Information: See Page 3
Weight: 0.112 grams (approximate)
TOP VIEW
Schematic and Pin Configuration
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Symbol
V
CBO
V
CEO
V
EBO
I
C
I
CM
Value
20
20
5
3
8
Unit
V
V
V
A
A
Characteristic
Collector-Base Voltage
Collector-Emitter Voltage
Emitter-Base Voltage
Continuous Collector Current
Peak Pulse Current
Thermal Characteristics
Characteristic
Power Dissipation @T
A
= 25°C (Note 3)
Thermal Resistance, Junction to Ambient Air (Note 3) @T
A
= 25°C
Operating and Storage Temperature Range
Notes:
Symbol
P
D
R
θ
JA
T
J
, T
STG
Value
1
125
-55 to +150
Unit
W
°C/W
°C
1. No purposefully added lead.
2. Diodes Inc.'s "Green" policy can be found on our website at http://www.diodes.com/products/lead_free/index.php.
3. Device mounted on FR-4 PCB, pad layout as shown on page 4 or in Diodes Inc. suggested pad layout document AP02001, which can be found on our
website at http://www.diodes.com/datasheets/ap02001.pdf.
DS31326 Rev. 3 - 2
1 of 4
www.diodes.com
DNLS320E
© Diodes Incorporated
Electrical Characteristics
Characteristic
Off Characteristics
Collector-Base Breakdown Voltage
Collector-Emitter Breakdown Voltage
Emitter-Base Breakdown Voltage
Collector Cutoff Current
Emitter Cutoff Current
On Characteristics (Note 4)
Collector-Emitter Saturation Voltage
Base-Emitter Saturation Voltage
Base-Emitter Turn-On Voltage
DC Current Gain
AC Characteristics
Transition Frequency
Input Capacitance
Output Capacitance
Switching Times
Notes:
@T
A
= 25°C unless otherwise specified
Symbol
V
(BR)CBO
V
(BR)CEO
V
(BR)EBO
I
CBO
I
EBO
Min
20
20
5
⎯
⎯
⎯
⎯
⎯
⎯
⎯
500
400
150
150
⎯
⎯
⎯
⎯
Typ
⎯
⎯
⎯
⎯
⎯
0.04
0.18
0.24
⎯
⎯
⎯
⎯
⎯
⎯
230
23
26
220
Max
⎯
⎯
⎯
100
100
0.10
0.50
0.45
0.9
0.9
⎯
⎯
⎯
⎯
⎯
⎯
⎯
⎯
Unit
V
V
V
nA
nA
Test Condition
I
C
= 100μA, I
E
= 0
I
C
= 10mA, I
B
= 0
I
E
= 100μA, I
C
= 0
V
CB
= 16V, I
E
= 0
V
EB
= 4V, I
C
= 0
I
C
= 0.1A, I
B
= 0.5mA
I
C
= 2A, I
B
= 10mA
I
C
= 3A, I
B
= 20mA
I
C
= 1A, I
B
= 10mA
V
CE
= 2V, I
C
= 1A
V
CE
= 2V, I
C
= 0.1A
V
CE
= 2V, I
C
= 2A
V
CE
= 2V, I
C
= 6A
V
CE
= 5V, I
C
= 50mA, f = 50MHz
V
EB
= 0.5V, f = 1MHz
V
CB
= 10V, f = 1MHz
V
CC
= 10V, I
C
= 500mA
I
B1
= -I
B2
= 50mA
NEW PRODUCT
V
CE(SAT)
V
BE(SAT)
V
BE(ON)
h
FE
V
V
V
⎯
f
T
C
ibo
C
obo
t
on
t
off
MHz
pF
pF
ns
ns
4. Pulse Test: Pulse width
≤300μs.
Duty cycle
≤2.0%.
1.0
P
D
, POWER DISSIPATION (mW)
3.5
3.0
I
C
, COLLECTOR CURRENT (A)
0.8
I
B
= 5mA
2.5
2.0
1.5
I
B
= 4mA
0.6
I
B
= 3mA
0.4
I
B
= 2mA
1.0
I
B
= 1mA
0.2
0.5
0
25
50
150
100
125
75
T
A
, AMBIENT TEMPERATURE (°C)
Fig. 1 Max Power Dissipation vs. Ambient Temperature
0
0
1
2
3
4
5
V
CE
, COLLECTOR-EMITTER VOLTAGE (V)
Fig. 2 Typical Collector Current vs. Collector-Emitter Voltage
0
DS31326 Rev. 3 - 2
2 of 4
www.diodes.com
DNLS320E
© Diodes Incorporated
2,000
0.5
V
CE(SAT)
, COLLECTOR-EMITTER
SATURATION VOLTAGE (V)
0.01
0.1
1
10
V
BE(SAT)
, BASE-EMITTER SATURATION VOLTAGE (V)
0.4
1,500
NEW PRODUCT
0.3
1,000
0.2
500
0.1
0
0.001
0
0.001
0.01
0.1
1
10
I
C
, COLLECTOR CURRENT (A)
Fig. 4 Typical Collector-Emitter Saturation Voltage
vs. Collector Current
V
BE(ON)
, BASE-EMITTER TURN-ON VOLTAGE (V)
1.2
1.2
1.0
1.0
0.8
0.8
0.6
0.6
0.4
0.4
0.2
0.2
0
0.001
0.01
0.1
1
10
I
C
, COLLECTOR CURRENT (A)
Fig. 5 Typical Base-Emitter Turn-On Voltage
vs. Collector Current
0
0.001
0.01
0.1
1
10
I
C
, COLLECTOR CURRENT (A)
Fig. 6 Typical Base-Emitter Saturation Voltage
vs. Collector Current
Ordering Information
(Note 5)
Device
DNLS320E-13
Notes:
Packaging
SOT-223
Shipping
2500/Tape & Reel
5. For packaging details, go to our website at http://www.diodes.com/ap2007.pdf.
Marking Information
(Top View)
YWW
N320
N320 = Product Type Marking Code
YWW = Date Code Marking
Y = Last digit of year ex: 7 = 2007
WW = Week code 01 - 52
DS31326 Rev. 3 - 2
3 of 4
www.diodes.com
DNLS320E
© Diodes Incorporated
Package Outline Dimensions
SOT-223
Dim Min Max Typ
A
1.55 1.65 1.60
A1
0.010 0.15 0.05
b1
2.90 3.10 3.00
b2
0.60 0.80 0.70
C
0.20 0.30 0.25
D
6.45 6.55 6.50
E
3.45 3.55 3.50
E1
6.90 7.10 7.00
e
—
—
4.60
e1
—
—
2.30
L
0.85 1.05 0.95
Q
0.84 0.94 0.89
All Dimensions in mm
NEW PRODUCT
Suggested Pad Layout:
DS31326 Rev. 3 - 2
