DPC-F-S-RA

Description
DISPLAYPORT RECEPTACLE R-A DIP TYPE 20 PIN
CategoryThe connector    The connector
File Size85KB,1 Pages
ManufacturerAdam Tech
Download Datasheet Parametric View All

DPC-F-S-RA Overview

DISPLAYPORT RECEPTACLE R-A DIP TYPE 20 PIN

DPC-F-S-RA Parametric

Parameter NameAttribute value
MakerAdam Tech
Reach Compliance Codecompli
Other featuresROHS COMPLIANT
Board mount optionsSPLIT BOARD LOCK
body width0.26 inch
subject depth0.498 inch
body length0.705 inch
Body/casing typeRECEPTACLE
Connector typeUSB CONNECTOR
Contact to complete cooperationAU ON NI
Contact point genderFEMALE
Contact materialCOPPER ALLOY
Contact resistance30 mΩ
Dielectric withstand voltage500VAC V
Insulation resistance100000000 Ω
insulator materialLIQUID CRYSTAL POLYMER (LCP)
Installation option 1LOCKING
Installation option 2MOUNTING FLANGE
Installation methodRIGHT ANGLE
Installation typeBOARD
Number of connectorsONE
PCB row number2
Number of ports1
Maximum operating temperature85 °C
Minimum operating temperature-25 °C
PCB contact patternSTAGGERED
PCB contact row spacing.9906 mm
Plating thickness15u inch
polarization keyPOLARIZED HOUSING
Rated current (signal)0.5 A
GuidelineUL
reliabilityCOMMERCIAL
Shell surfaceNICKEL
Shell materialBRASS
Terminal length0.079 inch
Termination typeSOLDER
Total number of contacts20
