PRELIMINARY
STX7905
SOLID STATE DEVICES, INC.
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
DESIGNER'S DATA SHEET
FEATURES:
•
•
•
•
•
•
BV
CBO
600V.
Fast Switching.
Low Leakage.
Low Saturation Voltage.
200
o
C Operating, Gold Eutectic Die Attach.
Designed for Complementary Use with STX6905.
1 AMP
600 VOLTS
NPN TRANSISTOR
TO-59
MAXIMUM RATINGS
Collector-Emitter Voltage
R
BE
= 1 kOhms
Collector-Base Voltage
Emitter-Base Voltage
Collector Current
Base Current
Total Device Dessipation
@ T
C
= 25
o
C
Derate above 25
o
C
Operating and Storage Temperature
Thermal Resistance, Junction to Case
CASE OUTLINE: TO-59
Pin Out:
1 - Collector
2 - Base
3 - Emmiter
SYMBOL
V
CEO
V
CER
V
CBO
V
EBO
I
C
I
B
P
D
T
J,
T
STG
R
1JC
VALUE
450
600
600
6
1
0.5
20
133
-65 to +200
7.5
UNITS
Volts
Volts
Volts
Amps
Amps
Watts
mW/
o
C
o
C
o
C/W
NOTE:
All specifications are subject to change without notification.
SCD's for these devices should be reviewed by SSDI prior to release.
DATA SHEET #: TR0006A
PRELIMINARY
STX7905
SOLID STATE DEVICES, INC.
14005 Stage Road * Santa Fe Springs, Ca 90670
Phone: (562) 404-4474 * Fax: (562) 404-1773
ELECTRICAL CHARACTERISTICS
Collector-Emitter Breakdown Voltage*
( I
C
= 1 mA
DC)
(I
C
= 100:A
DC
; R
BE
= 1kS)
Collector-Base Breakdown Voltage
(I
C
= 100uA
DC
)
Emitter-Base Breakdown Voltage
(I
E
= 20uA
DC
)
Collector Cutoff Current
(V
CB
= 600V
DC
)
Emmiter Cutoff Current
(V
EB
= 6V
DC
)
DC Current Gain*
(I
C
= 1mA
DC;
V
CE
= 10V
DC
)
(I
C
= 25mA
DC;
V
CE
= 10V
DC
)
(I
C
= 100mA
DC;
V
CE
= 15V
DC
)
SYMBOL
BV
CEO
BV
CER
BV
CBO
BV
EBO
I
CBO
I
EBO
MIN
450
600
600
6
-
-
40
40
30
-
-
25
-
MAX
-
-
-
1
1
200
200
-
0.5
1.0
-
15
UNITS
V
DC
V
V
:A
:A
H
FE
Collector-Emitter Saturation Voltage*
(I
C
= 25mA
DC,
I
B
= 2.5mA
DC
)
Base-Emitter Saturation Voltage*
(I
C
= 25mA
DC,
I
B
= 2.5mA
DC
)
Current Gain Bandwidth Product
(I
C
= 50mA
DC ,
V
CE
= 10V
DC,
f = 1MHz)
Output Capacitance
(V
CB
= 30V
DC ,
I
E
= 0A
DC,
f = 1.0MHz)
*Pulse Test: Pulse Width = 300us, Duty Cycle = 2%
V
CE(SAT)
V
BE(SAT)
fT
C
ob
V
DC
V
DC
MHz
pf
