BZT52B2V4-G ~ BZT52B43-G
Taiwan Semiconductor
Small Signal Product
2% Zener Voltage Tolerance Zener Diode
FEATURES
- Wide zener voltage range selection: 2.4V to 43V
- Surface Mount Device Type
- Moisture sensitivity level 1
- Pb free and RoHS compliant
- Green compound (Halogen free) with suffix "G" on
packing code and prefix "G" on date code
- Ideal for Surface Mounted Applications
SOD-123
MECHANICAL DATA
- Case: Bend lead SOD-123 small outline plastic package
- Terminal: Matte tin plated, lead free, solderable
per MIL-STD-202, Method 208 guaranteed
- High temperature soldering guaranteed: 260°C/10s
- Polarity: Indicated by cathode band
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
Forward Voltage (Note2)
Power Dissipation (Note1)
Thermal Resistance from Junction to Ambient
Junction Temperature
Storage Temperature
@ I
F
= 10mA
SYMBOL
V
F
P
D
R
θJA
T
J
T
STG
2
VALUE
0.9
410
357
150
- 55 to + 150
UNIT
V
mW
o
C/W
o
o
C
C
Notes: 1. Device mounted on ceramic PCB: 7.6mm X 9.4mm X 0.87mm with pad areas 25mm
2. Short duration test pulse used to minimize self-heating effect
Document Number: DS_S1405027
Version: D14
BZT52B2V4-G ~ BZT52B43-G
Taiwan Semiconductor
Small Signal Product
Electrical Characteristics
(Ratings at TA=25 C ambient temperature unless otherwise specified)
Maximun Zener
Impedance
Z
ZT
@ I
ZT
100
100
95
95
90
90
90
80
60
40
10
15
15
15
15
20
20
25
30
30
40
45
55
55
70
80
80
80
90
130
130
Z
Zk
@ I
zk
600
600
600
600
600
600
600
500
480
400
150
80
80
80
100
150
150
150
170
200
200
225
225
250
250
300
300
325
350
350
350
I
ZT
mA
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.5
0.5
0.5
Maximun
Reverse
Current
I
R
uA
50
20
10
5
5
3
3
3
2
1
3
2
1
0.7
0.5
0.2
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
0.1
V
R
V
1.0
1.0
1.0
1.0
1.0
1.0
1.0
2.0
2.0
2.0
4.0
4.0
5.0
5.0
6.0
7.0
8.0
8.0
8.0
10.5
11.2
12.6
14.0
15.4
16.8
18.9
21.0
23.1
25.2
27.3
29.4
Typical
Temperature
Coefficent @
I
ZTC
mV/
o
C
Min
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-3.5
-2.7
-2.0
0.4
1.2
2.5
3.2
3.8
4.5
5.4
6.0
7.0
9.2
10.4
12.4
14.4
16.4
18.4
21.4
24.4
27.4
30.4
33.4
36.4
Max
0
0
0
0
0
0
0
0.2
1.2
2.5
3.7
4.5
5.3
6.2
7.0
8.0
9.0
10.0
11.0
13.0
14.0
16.0
18.0
20.0
22.0
25.3
29.4
33.4
37.4
41.2
45.2
I
ZTC
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
2
Test
Current
o
Device
Type
Marking
code
Zener Voltage Range
V
Z
@ I
ZT
Nom(V) Min(V) Max(V)
BZT52B2V4-G
BZT52B2V7-G
BZT52B3V0-G
BZT52B3V3-G
BZT52B3V6-G
BZT52B3V9-G
BZT52B4V3-G
BZT52B4V7-G
BZT52B5V1-G
BZT52B5V6-G
BZT52B6V2-G
BZT52B6V8-G
BZT52B7V5-G
BZT52B8V2-G
BZT52B9V1-G
BZT52B10-G
BZT52B11-G
BZT52B12-G
BZT52B13-G
BZT52B15-G
BZT52B16-G
BZT52B18-G
BZT52B20-G
BZT52B22-G
BZT52B24-G
BZT52B27-G
BZT52B30-G
BZT52B33-G
BZT52B36-G
BZT52B39-G
BZT52B43-G
2WX
2W1
2W2
2W3
2W4
2W5
2W6
2W7
2W8
2W9
2WA
2WB
2WC
2WD
2WE
2WF
2WG
2WH
2WI
2WJ
2WK
2WL
2WM
2WN
2WO
2WP
2WQ
2WR
2WS
2WT
2WU
2.4
2.7
3
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
2.35
2.65
2.94
3.23
3.53
3.82
4.21
4.61
5.00
5.49
6.08
6.66
7.35
8.04
8.92
9.80
10.78
11.76
12.74
14.70
15.68
17.64
19.60
21.56
23.52
26.46
29.40
32.34
35.28
38.22
41.46
2.45
2.75
3.06
3.37
3.67
3.98
4.39
4.79
5.20
5.71
6.32
6.94
7.65
8.36
9.28
10.20
11.22
12.24
13.26
15.30
16.32
18.36
20.40
22.44
24.48
27.54
30.60
33.66
36.72
0.50
42.84
I
ZT
mA
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
5
2
2
2
2
2
2
Ohm
Document Number: DS_S1405027
Version: D14
BZT52B2V4-G ~ BZT52B43-G
Taiwan Semiconductor
Small Signal Product
RATINGS AND CHARACTERISTICS CURVES
(TA=25℃ unless otherwise noted)
Fig. 1 Admissible Power Dissipation curve
Fig. 2 Forward Characteristics
50
Ta=25°C
2V7
40
3V3
30
3V9
4V7
8V2
Iz (mA)
30
5V6
6V8
Ta=25°C
Fig. 3 Admissible power dissipation VS.
ambient temperature
10
12
15
20
Iz (mA)
18
22
Test currect
Iz 5mA
27
33
20
Test currect
Iz 5mA
10
10
0
0
1
2
3
4
5
6
7
8
9
10
0
0
10
20
Vz (V)
30
40
Vz (V)
Document Number: DS_S1405027
Version: D14
BZT52B2V4-G ~ BZT52B43-G
Taiwan Semiconductor
Small Signal Product
ORDERING INFORMATION
PART NO.
BZT52Bxxx-G
(Note2)
MANUFACTURE
CODE (Note1)
PACKING CODE
RB
GREEN COMPOUND
CODE
G
PACKAGE
SOD-123
PACKING
3K / 7" Reel
Note1: Manufacture special control, if empty means no special control requirement.
Note2: "xxx" is Device Code from "2V4" thru "43", detail could follow the previous page
EXAMPLE
PREFERRED P/N
BZT52B2V4-G RBG
PART NO.
BZT52B2V4-G
N0
MANUFACTURE
CODE
PACKING CODE
RB
RB
GREEN COMPOUND
CODE
G
G
DESCRIPTION
Green compound
Green compound
BZT52B2V4-G-N0 RBG BZT52B2V4-G
Document Number: DS_S1405027
Version: D14
