SBR20A200CTB
20A SBR
®
SUPER BARRIER RECTIFIER
Features
•
•
•
•
•
•
•
•
Low Forward Voltage Drop
Low Leakage Current
Excellent High Temperature Stability
Patented Super Barrier Rectifier Technology
Soft, Fast Switching Capability
175ºC Operating Junction Temperature
Lead Free Finish, RoHS Compliant (Note 1)
Also Available in Green Molding Compound (Note 2)
Mechanical Data
•
•
•
•
•
Case: D Pak
Case Material: Molded Plastic, UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 1.6 grams (approximate)
2
t
Common
Anode Cathode Anode
Top View
Package Pin Out
Configuration
Ordering Information
(Notes 2 & 3)
Part Number
SBR20A200CTB
SBR20A200CTB-G
SBR20A200CTB-13
SBR20A200CTB-13-G
Notes:
Case
2
D Pak
2
D Pak
2
D Pak
2
D Pak
Packaging
50 pieces/tube
50 pieces/tube
800/Tape & Reel
800/Tape & Reel
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes
2. For Green Molding Compound version part numbers, add "-G" suffix to part number above. Examples: SBR20A200CTB-G.
3. For packaging details, go to our website at http://www.diodes.com.
Marking Information
SBR
20A200CTB
YYWW AB
SBR20A200CTB = Product Type Marking Code
AB = Foundry and Assembly Code
YYWW = Date Code Marking
YY = Last two digits of year (ex: 07 = 2007)
WW = Week (01 - 53)
SBR20A200CTB
Document number: DS31076 Rev. 7 - 2
1 of 4
www.diodes.com
July 2011
© Diodes Incorporated
SBR is a registered trademark of Diodes Incorporated.
SBR20A200CTB
Maximum Ratings
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Average Rectified Output Current @ T
C
= 150ºC
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
Symbol
V
RRM
V
RWM
V
RM
I
O
I
FSM
Value
200
20
180
Unit
V
A
A
Thermal Characteristics
Characteristic
Maximum Thermal Resistance (per leg)
Thermal Resistance Junction to Case (Note 4)
Thermal Resistance, Junction to Ambient (Note 4)
Operating and Storage Temperature Range
Symbol
R
θJC
R
θJA
T
J
, T
STG
Value
4
43
-65 to +175
Unit
ºC/W
ºC
Electrical Characteristics
@T
A
= 25°C unless otherwise specified
Characteristic
Forward Voltage Drop
Leakage Current (Note 5)
Reverse Recovery Time
Notes:
Symbol
V
F
I
R
t
rr
Min
-
-
-
-
Typ
-
-
0.66
0.003
0.51
24
20
Max
0.86
0.96
0.72
0.1
10
30
25
Unit
V
mA
ns
Test Condition
I
F
= 10A, T
J
= 25ºC
I
F
= 20A, T
J
= 25ºC
I
F
= 10A, T
J
= 125ºC
V
R
= 200V, T
J
= 25ºC
V
R
= 200V, T
J
= 125ºC
I
F
= 0.5A, I
R
= 1A, I
RR
= 0.25A
I
F
= 1A, V
R
= 30V,
di/dt = 100A/μs, T
J
= 25ºC
4. FR-4 PCB, 2 oz. Copper, minimum recommended pad layout per http://www.diodes.com/datasheets/ap02001.pdf
5. Short duration pulse test used to minimize self-heating effect.
T
J
= 175°C
T
J
= 150°C
T
J
= 125°C
T
J
= 175°C
T
J
= 150°C
T
J
= 75°C
T
J
= 125°C
T
J
= 75°C
T
J
= 25°C
T
J
= -65°C
T
J
= 25°C
SBR20A200CTB
Document number: DS31076 Rev. 7 - 2
2 of 4
www.diodes.com
July 2011
© Diodes Incorporated
SBR is a registered trademark of Diodes Incorporated.
SBR20A200CTB
