BAT43X
Taiwan Semiconductor
Small Signal Product
SOD-523F I
FSM
=4A 30V/200mA Schottky Diode
FEATURES
- Low Forward Voltage Drop
- Fast Switching Time
- Surface Mounted Device
- Moisture sensitivity level 1
- Pb free and RoHS compliant
- Halogen-free according to IEC 61249-2-21 definition
MECHANICAL DATA
- Case: Flat lead SOD-523F package
- High temperature soldering guaranteed: 260℃/10s
- Weight: 9.9mg (approximately)
SOD-523F
APPLICATION
- Portable consumer electronic devices
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
(T
A
=25℃ unless otherwise noted)
PARAMETER
Working Peak Reverse Voltage
DC Blocking Voltage
RMS Reverse Voltage
Forward Continuous Currect
Peak Forward Surge Current @t< 10ms
Repetitive Peak Forward Current @t< 1.0s
Power Dissipation
Thermal Resistance form Junction to Ambient
Junction Temperature
Storage Temperature Range
PARAMETER
Reverse Breakdown Voltage
Reverse Current
Forward Voltage
Capacitance Between Terminals
Reverse Recovery Time
TEST CONDITION
at I
R
= 10
μA
at V
R
= 25 V
at I
F
= 2mA
at I
F
= 15mA
at I
F
= 200mA
V
R
=1V, f=1.0MHz
I
F
=I
R
=10mA
I
rr
=0.1XI
R
, R
L
=100Ω
C
T
t
rr
--
--
V
F
SYMBOL
V
RWM
V
R
V
R(RMS)
I
FM
I
FSM
I
FRM
P
D
R
thjA
T
J
T
STG
SYMBOL
V
(BR)
I
R
0.26
MIN
30
0.5
0.33
0.45
1
10
5
VALUE
30
30
21
200
4
500
200
500
125
- 55 to + 150
MAX
o
UNIT
V
V
V
mA
A
mA
mW
C/W
o
o
C
C
UNIT
V
µA
V
V
pF
ns
Document Number: DS_S1405008
Version: A14
BAT43X
Taiwan Semiconductor
Small Signal Product
RATINGS AND CHARACTERISTICS CURVES
(T
A
=25℃ unless otherwise noted)
Fig.1 Typical Forward Characteristics
1000
200
Reverse Current (mA)
100
Forward Current (mA)
Ta=100°C
10
100
Fig. 2 Typical Reverse Characteristics
Ta=100°C
10
Ta=25°C
1
Ta=25°C
1
0.1
0.1
0
100
200
300
400
500
600
700
Forward Voltage (mV)
0.01
0
10
Reverse Voltage (V)
20
Fig. 3 Power Derating Curve
200
Capacitance Between Terminals (pF)
20
Fig. 4
Typical Capacitance Characteristics
Power Dissipation (mW)
150
15
100
10
50
5
0
0
25
50
75
100
125
0
0
5
10
Reverse Voltage (V)
15
20
Ambient Temperature (°C)
Document Number: DS_S1405008
Version: A14
BAT43X
Taiwan Semiconductor
Small Signal Product
ORDERING INFORMATION
GREEN
MANUFACTURE
PART NO.
CODE
BAT43X
(Note)
CODE
RS
CODE
G
SOD-523F
8K / 7" Reel
S8
PACKING
COMPOUND
PACKAGE
PACKING
MARKING
Note: Indicator of manufacturing site for manufacture special control, if empty means no special control requirement
EXAMPLE
MANUFACTURE
PREFERRED P/N PART NO.
CODE
BAT43X RSG
BAT43X-M0 RSG
BAT43X
BAT43X
M0
RS
RS
PACKING CODE
GREEN COMPOUND
CODE
G
G
DESCRIPTION
Green compound
Green compound
Document Number: DS_S1405008
Version: A14
BAT43X
Taiwan Semiconductor
Small Signal Product
PACKAGE OUTLINE DIMENSIONS
SOD-523F
DIM.
A
B
C
D
E
F
Unit (mm)
Min.
0.70
1.50
0.25
1.10
0.50
0.07
Max.
0.90
1.70
0.40
1.30
0.77
0.20
Unit (inch)
Min.
0.028
0.059
0.010
0.043
0.020
0.003
Max.
0.035
0.067
0.016
0.051
0.030
0.008
SUGGEST PAD LAYOUT
Unit (mm)
Typ.
0.60
2.30
0.80
Unit (inch)
Typ.
0.024
0.091
0.031
DIM.
X
X1
Y
Document Number: DS_S1405008
Version: A14
BAT43X
Taiwan Semiconductor
Small Signal Product
Notice
Specifications of the products displayed herein are subject to change without notice. TSC or anyone on its behalf, assumes no
responsibility or liability for any errors inaccuracies.
Information contained herein is intended to provide a product description only. No license, express or implied, to any intellectual property
rights is granted by this document. Except as provided in TSC's terms and conditions of sale for such products, TSC assumes no liability
whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of TSC products including liability or warranties
relating to fitness for a particular purpose, merchantability, or infringement of any patent, copyright, or other intellectual property right.
The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications. Customers using or seling these
products for use in such applications do so at their own risk and agree to fully indemnify TSC for any damages resulting from such
improper use or sale.
Document Number: DS_S1405008
Version: A14
