Product Data Sheet
SMJQ-XCA5W4PX - Acrich3 105W
Integrated AC LED Solution
Acrich3 – 105W
SMJQ-XCA5W4PX
SMJQ-2CA5W4PA
SMJQ-3CA5W4P7
RoHS
Product Brief
Description
•
The Acrich3 series of products are
designed to be driven directly off of AC
line voltage, therefore they do not need
the standard converter essential for
conventional general lighting products.
The converter or driver found in most
general lighting products can limit the
overall life of the product, but with the
Acrich3 series of products the life of the
product can more closely be estimated
from the LED itself. This will also allow
for a much smaller form factor from an
overall fixture design allowing for higher
creativity in the fixture.
The modules have a high power factor
which can contribute to a higher energy
savings in the end application.
Features and Benefits
•
•
•
•
•
•
•
•
Connects directly to AC line voltage
High Power Efficiency & Factor
Low THD
Long Life Time
Simple BOM
Miniaturization
Lead Free Product
RoHS Compliant
•
Key Applications
•
•
•
•
Factory Ceiling Light
Industrial Light
High-bay
Low-bay
•
Table 1. Product Selection
Flux [lm]
Part No.
Vin [Vac]
P [W]
CCT [K]
Min.
SMJQ-2CA5W4PA
120
105
SMJQ-3CA5W4P7
220
3700 - 6000
10,500
11,500
70
Typ.
Min.
CRI
Rev1.0
1
www.seoulsemicon.com
Product Data Sheet
SMJQ-XCA5W4PX - Acrich3 105W
Table of Contents
Index
•
•
•
•
•
•
•
•
•
•
•
•
•
Product Brief
Table of Contents
Performance Characteristics
Characteristic Graph
Color Bin Structure
Part List
Mechanical Dimensions
Circuit Drawing
Marking Information
Packing & Label Information
Handling of Silicone Resin for LEDs
Precaution for Use
Company Information
1
2
3
4
8
10
12
13
14
15
17
18
20
Rev1.0
2
www.seoulsemicon.com
Product Data Sheet
SMJQ-XCA5W4PX - Acrich3 105W
Performance Characteristics
Table 2. Electro Optical Characteristics, T
a
= 25ºC
Value
Parameter
Luminous Flux
[1]
Symbol
Min.
Ф
V
5300
Correlated Color
Temperature
[2]
4700
CCT
4200
3700
CRI
Input Voltage
[3]
Power Consumption
Operating Frequency
Power Factor
Viewing Angle
Tolerance of Surge
[4]
Unit
Typ.
11500
5600
5000
4500
4000
-
120
6000
5300
K
4700
4200
-
-
Max.
lm
Mark
B,C,D,E
B
C
D
E
Ra
V
in
70
2C
Vac
3C
W
Hz
-
deg.
-
V
A5W
220
P
f
PF
2Θ
1/2
V
s
500
105
50 / 60
Over 0.97
120
-
Notes :
(1) Ф
V
is the total luminous flux output measured with an integrated sphere.
(2) Correlated Color Temperature is derived from the CIE 1931 Chromaticity diagram.
(3) Operating Voltage doesn't indicate the maximum voltage which customers use but means
tolerable voltage according to each country’s voltage variation rate. It is recommended that the
solder pad temperature should be below 70℃.
(4) Surge withstand in accordance with IEC61000-4-5.(Line to Line)
Rev1.0
3
www.seoulsemicon.com
Product Data Sheet
SMJQ-XCA5W4PX - Acrich3 105W
Performance Characteristics
Table 3. Absolute Maximum Ratings, T
a
= 25ºC
Parameter
Symbol
Unit
Value
144 (@120VAC)
Maximum Input Voltage
V
in
VAC
264 (@220VAC)
Power Consumption
Operating Temperature
Storage Temperature
ESD Sensitivity
P
T
opr
T
stg
-
W
ºC
ºC
-
126
-30 ~ 85
-40 ~ 100
±4,000V
HBM
Rev1.0
4
www.seoulsemicon.com
Product Data Sheet
SMJQ-XCA5W4PX - Acrich3 105W
Characteristic Graph
Fig 1. Relative Spectral Distribution vs. Wavelength Characteristic – B,C
1.2
1
0.8
0.6
0.4
0.2
0
380
430
480
530
580
630
680
730
780
Relative Spectral Power
Distribution
Wavelength[nm]
Fig 2. Relative Spectral Distribution vs. Wavelength Characteristic – D,E
1.2
Relative Spectral Power
Distribution
1
0.8
0.6
0.4
0.2
0
380
430
480
530
580
630
680
730
780
Wavelength[nm]
Rev1.0
5
www.seoulsemicon.com
