SBR1040CTB
10A SBR
®
SUPER BARRIER RECTIFIER
Features
•
•
•
•
•
Excellent High Temperature Stability
Patented Super Barrier Rectifier Technology
Soft, Fast Switching Capability
Lead Free Finish, RoHS Compliant (Note 1)
Also Available in Green Molding Compound (Note 2)
Mechanical Data
•
•
•
•
•
Case: D PAK
Case Material: Molded Plastic, UL Flammability Classification
Rating 94V-0
Moisture Sensitivity: Level 1 per J-STD-020
Terminals: Matte Tin Finish annealed over Copper leadframe.
Solderable per MIL-STD-202, Method 208
Weight: 1.6 grams (approximate)
2
D
2
PAK
Package Pin Out
Configuration
Ordering Information
(Notes 2 & 3)
Part Number
SBR1040CTB
SBR1040CTB-G
SBR1040CTB-13
SBR1040CTB-13-G
Notes:
Case
D Pak (TO-263)
2
D Pak (TO-263)
2
D Pak (TO-263)
2
D Pak (TO-263)
2
Packaging
50 pieces/tube
50 pieces/tube
800 / Tape & Reel
800 / Tape & Reel
1. EU Directive 2002/95/EC (RoHS). All applicable RoHS exemptions applied, see EU Directive 2002/95/EC Annex Notes
2. For Green Molding Compound version part numbers, add "-G" suffix to part number above. Examples: SBR1040CTB-G.
3. For packaging details, go to our website at http://www.diodes.com.
Marking Information
SBR1040CTB = Product Type Marking Code
AB = Foundry and Assembly Code
YYWW = Date Code Marking
YY = Last two digits of year (ex: 08 = 2008)
WW = Week (01 - 53)
SBR1040CTB
Document number: DS31552 Rev. 5 - 2
1 of 4
www.diodes.com
July 2011
© Diodes Incorporated
SBR is a registered trademark of Diodes Incorporated.
SBR1040CTB
Maximum Ratings (Per Leg)
@T
A
= 25°C unless otherwise specified
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitance load, derate current by 20%.
Characteristic
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Per Leg
Average Rectified Output Current
Total
Non-Repetitive Peak Forward Surge Current 8.3ms
Single Half Sine-Wave Superimposed on Rated Load
Symbol
V
RRM
V
RWM
V
RM
I
O
I
FSM
Value
40
5
10
85
Unit
V
A
A
Thermal Characteristics (Per Leg)
Characteristic
Maximum Thermal Resistance (Note 4)
Operating and Storage Temperature Range
Symbol
R
θ
JC
T
J
, T
STG
Value
6
-65 to +175
Unit
ºC/W
ºC
Electrical Characteristics (Per Leg)
@T
A
= 25°C unless otherwise specified
Characteristic
Forward Voltage Drop (Per leg)
Leakage Current (Note 5)
Notes:
Symbol
V
F
I
R
Min
-
-
Typ
0.53
-
Max
0.60
0.5
Unit
V
mA
Test Condition
I
F
= 5A, T
J
= 25ºC
V
R
= 40V, T
J
= 25ºC
4. Polymide PCB, 2oz. Copper, minimum recommended pad layout per http://www.diodes.com/datasheet/ap2001.pdf
5. Short duration pulse test used to minimize self-heating effect.
10
I
R
, INSTANTANEOUS REVERSE CURRENT (mA)
I
F
, INSTANTANEOUS FORWARD CURRENT (A)
100
100,000
10,000
1
1,000
0.1
100
0.01
0.001
10
0.0001
0
200
400
600
800
V
F
, INSTANTANEOUS FORWARD VOLTAGE (mV)
Fig. 1 Typical Forward Characteristics
1
0
5
10 15 20 25 30 35 40 45
V
R
, INSTANTANEOUS REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
SBR1040CTB
Document number: DS31552 Rev. 5 - 2
2 of 4
www.diodes.com
July 2011
© Diodes Incorporated
SBR is a registered trademark of Diodes Incorporated.
SBR1040CTB
10
I
F(AV),
AVERAGE FORWARD CURRENT (A)
R
θ
JA
= R
θ
JC
Total Device
5
R
θ
JA
= R
θ
JC
Per Element
0
R
θ
JA
= 30°C/W
Per Element
Note 3
0
25
50
75
100
125
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 3 Forward Current Derating Curve
150
Package Outline Dimensions
L1
D1
E
E1
D
H
1
K
2
L2
e
b
b1
c
A
a
L
c1
D PAK
Dim
Min
Max
A
4.07
4.82
b
0.51
0.99
b1
1.15
1.77
c
0.356
0.58
c1
1.143
1.65
D
8.39
9.65
D1
6.55
⎯
E
9.66
10.66
E1
6.23
⎯
e
2.54 Typ
H
14.61 15.87
L
1.78
2.79
L1
1.67
⎯
L2
1.77
⎯
a
0°
8°
All Dimensions in mm
2
Suggested Pad Layout
X2
Y2
Z
Y1
Dimensions
Z
X1
X2
Y1
Y2
E1
Value (in mm)
16.9
1.1
10.8
3.5
7.01
2.5
X1
E1
SBR1040CTB
Document number: DS31552 Rev. 5 - 2
3 of 4
www.diodes.com
July 2011
© Diodes Incorporated
SBR is a registered trademark of Diodes Incorporated.
