EGP30A thru EGP30M
Glass Passivated Junction High Efficiency Rectifiers
Reverse Voltage 50 to 1000V
FEATURES
* Plastic package has Underwriters Laboratory
Flammability Classification 94V-0
* High temperature metallurgically
bonded construction
* Cavity-free glass passivated junction
* Capable of meeting environmental standards
of MIL-S-19500
* For use in high frequency rectifier circuits
* Fast switching for high efficiency
* High temperature soldering guaranteed:
260°C/10 seconds
* 0.375" (9.5mm) lead length, 5 lbs. (2.3kg) tension
Mechanical Data
Case:
JEDEC DO-210AD
molded plastic over glass body
Terminals:
Plated axial leads, solderable per
MIL-STD-750, Method 2026
Polarity:
Color band denotes cathode end
Mounting Position:
Any
Weight:
0.038 oz., 1.03 g
Handling precautin:None
We declare that the material of product compliance
with ROHS requirements
1.Electrical Characteristic
Maximum & Thermal Characteristics Ratings
at 25°C ambient temperature unless otherwise specified.
Parameter Symbol
Making
Maximum repetitive peak reverse voltage
Maximum RSM voltage
Maximum DC blocking voltage
Maximum average forward rectified current
0.375" (9.5mm) lead length at TA = 75°C
Peak forward surge current 8.3ms single half sine-wave
superimposed on rated load (JEDEC Method)
Typical thermal resistance (Note 2)
Operating junction and storage temperature range
V
RRM
V
RSM
V
DC
IF(AV)
I
FSM
RθJA
TJ, TSTG
symbol
EGP
30A
EGP
30A
50
35
50
EGP
30B
EGP
30B
100
70
100
EGP
30C
EGP
30C
150
105
150
EGP
30D
EGP
30D
200
140
200
EGP
30F
EGP
30F
300
210
300
3.0
125
55
–50
to +150
EGP
30G
EGP
30G
400
280
400
EGP
30J
EGP
30J
600
420
600
EGP
30K
EGP
30K
800
560
800
EGP
30M
EGP
30M
1000
700
1000
Unit
V
V
V
A
A
°C/W
°C
Electrical Characteristics Ratings
at 25°C ambient temperature unless otherwise specified.
Parameter Symbol
Maximum Instantaneous Forward Voltage
(IF = 3.0 Amps, TJ = 25°C)
Maximum full load reverse current, full cycle
average,0.375"(9.5mm) lead lengths
(Rated dc Voltage, TJ = 25°C)
(Rated dc Voltage, TJ = 125°C)
symbol
V
F
EGP
30A
EGP
30B
EGP
30C
EGP
30D
EGP
30F
EGP
30G
EGP
30J
EGP
30K
1.70
EGP
30M
Unit
V
0.95
1.25
IR
10.0
200
50
50
75
40
µA
Typical reverse recovery time (Note 1)
trr
Typical junction capacitance at 4.0V, 1MHz
CJ
NOTES:
1. IF = 0.5A, IR = 1.0A, IRR = 0.25A
2. Thermal resistance from junction to ambient at 0.375" (9.5mm) lead length, P.C.B. mounted
ns
PF
EGP30A thru EGP30M
2.Ratings and Characteristic Curves
( TA = 25°C unless otherwise noted )
Fig. 1
–
Forward Current Derating Curve
Average Forward Rectified Current (A)
60 Hz
Resistive or
Inductive Load
Average Forward Rectified Current (A)
200
Fig. 2
–
Maximum Non-repetitive Peak
Forward Surge Current
TJ = TJ max
8.3ms Single Half Sine-wave
(JEDEC Method)
4.0
100
2.0
0.375" (9.5mm) Lead Length
0
0
25
50 75 100 125 150 175
Ambient Temperature,
°C
10
0
10
Number of Cycles at 60Hz
100
10
Instantaneous Reverse Current (µA)
100
Instantaneous Forward Current (A)
Fig 3.
–
Typical Instantaneous Forward
Characteristics
Fig 4.
–
Typical Reverse Characteristics
100
10
Tj=125℃
1.0
1.0
0.1
TJ = 25°C
Pulse width = 300µs
1% Duty Cycle
0.10
Tj=25℃
0.01
0.4
0.8
1.2
1.6
2.0
2.4
Instantaneous Forward Voltage (V)
0.01
0
20
40
60
80
100
Percent of Rated Peak Reverse Voltage (%)
Fig 6.
–
Typical Junction Capacitance
Transient thermal impedance(°C/W)
100
Fig 5.
–typical
transient thermal
impedance
Junction Capacitance (pF)
100
10
10
1.0
1.0
TJ = 25°C
f = 1.0 MHz
Vsig = 50mVp-p
0.1
0.01
0.1
1.0
10
t,Pulse duration,sec
100
0.1
0.01
0.1
1.0
10
Reverse Voltage (V)
100
50
