YG902N2 thru YG902N6
YG902N2 thru YG902N6
ITO-220AB
®
Pb
Pb Free Plating Product
10 Ampere Dual Common Anode Ultra Fast Recovery Half Bridge Rectifiers
Features
Latest GPP technology with super fast recovery time
Low forward voltage drop
High current capability
Low reverse leakage current
High surge current capability
Application
Unit:mm
Automotive Inverters and Solar Inverters
Plating Power Supply,SMPS,EPS and UPS
Car Audio Amplifiers and Sound Device Systems
Mechanical Data
Case: Fully Insulated Molding TO-220F
Epoxy: UL 94V-0 rate flame retardant
Terminals: Solderable per MIL-STD-202
method 208
Polarity: As marked on diode body
Mounting position: Any
Weight: 2.0 gram approximately
Case
Case
Case
Case
Negative
Positive
Common Cathode Common Anode
Suffix "N2"
Suffix "C2"
Suffix "C4"
Suffix "N4"
Suffix "C6"
Suffix "N6"
Series Connection
Doubler
Tandem Polarity Tandem Polarity
Suffix "D2"
Suffix "S2"
Suffix "D4"
Suffix "S4"
Suffix "D6"
Suffix "S6"
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Rating at 25
C
ambient temperature unless otherwise specified.
Single phase, half wave, 60Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
o
SYMBOL
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified
Current T
C
=100
C
Peak Forward Surge Current, 8.3ms single
Half sine-wave superimposed on rated load
(JEDEC method)
Maximum Instantaneous Forward Voltage
@ 5.0 A
Maximum DC Reverse Current @T
J
=25
C
At Rated DC Blocking Voltage @T
J
=125
C
Maximum Reverse Recovery Time (Note 1)
Typical junction Capacitance (Note 2)
Typical Thermal Resistance (Note 3)
Operating Junction and Storage
Temperature Range
o
o
o
YG902N2
200
140
200
YG902N4
400
280
400
10.0
YG902N6
600
420
600
UNIT
V
V
V
A
V
RRM
V
RMS
V
DC
IF
(AV)
I
FSM
100
A
V
F
I
R
Trr
C
J
R
JC
T
J
, T
STG
0.98
1.3
5.0
100
35
65
2.2
-55 to +150
1.7
V
uA
uA
nS
pF
o
C/W
o
C
NOTES : (1) Reverse recovery test conditions I
F
= 0.5A, I
R
= 1.0A, Irr = 0.25A.
(2) Measured at 1.0 MHz and applied reverse voltage of 4.0 Volts DC.
(3) Thermal Resistance junction to case.
Rev.05
© 2006 Thinki Semiconductor Co., Ltd.
Page 1/2
http://www.thinkisemi.com/
YG902N2 thru YG902N6
®
FIG.1 - FORWARD CURRENT DERATING CURVE
10
100
FIG.2 - MAXIMUM NON-REPETITIVE
PEAK FORWARD SURGE CURRENT
PEAK FORWARD SURGE CURRENT,
AMPERES
Pulse Width 8.3ms
Single Half-Sire-Wave
(JEDEC Method)
AVERAGE FORWARD RECTIFIED
CURRENT, AMPERES
8
80
6
60
4
40
2
60 Hz Resistive or
Inductive load
0
0
50
100
o
20
0
150
1
10
100
CASE TEMPERATURE, C
NUMBER OF CYCLES AT 60Hz
FIG.3 - TYPICAL INSTANTANEOUS
FORWARD CHARACTERISTICS
IINSTANTANEOUS FORWARD CURRENT,
AMPERES
50
YG902N2
FIG.4 - TYPICAL REVERSE CHARACTERISTICS
1000
INSTANTANEOUS REVERSE CURRENT,
MICROAMPERES
5
YG902N4
YG902N6
100
T
J
=125 C
o
10
T
J
=25 C
1
o
1
0.1
0.2
0.4
0.6
0.8
T
J
=25 C
PULSE WIDTH=300uS
1% DUTY CYCLE
1.0
1.2
1.4
1.6
o
0.1
0
20
40
60
80
100
INSTANTANEOUS FORWARD VOLTAGE,
VOLTS
PERCENT OF RATED PEAK REVERSE VOLTAGE,%
FIG.5 - TYPICAL JUNCTION CAPACITANCE
1000
JUNCTION CAPACITANCE, pF
T
J
= 25 C
f = 1.0 MHZ
Vsig = 50mVp-p
o
100
10
0.1
1.0
4.0
10
100
REVERSE VOLTAGE, VOLTS
Rev.05
© 2006 Thinki Semiconductor Co., Ltd.
Page 2/2
http://www.thinkisemi.com/
