HDMI with Serial and IR Over Cat5/Cat6 Extender
Kit, Extended Range Transmitter and Receiver, 3840
x 2160 4Kx2K UHD 1080p up to 60Hz
MODEL NUMBER:
B126-1A1SR
Highlights
Supports Ultra High Definition
(UHD) 4Kx2K video resolutions
up to 3840 x 2160 @ 24Hz
Supports 7.1 channel surround
sound, DTS-HD, and Dolby
TrueHD audio
IR functionality allows you to use
your HDMI source's remote
control in the same location as
your extended monitor
Supports RS232 Serial baud
rates up to 115kbps full duplex,
for control of devices such as
touchscreens or scanners
HDCP and 3D compatible
Compliant with the Federal Trade
Agreements Act (TAA) for GSA
Schedule purchases
Description
The B126-1A1SR transmits HDMI, IR Remote, and Serial RS232 up to 328 ft. (100 m.) using a single
Cat5e/6/6a cable. It supports Ultra High Definition (UHD) 4Kx2K video resolutions up to 3840 x 2160 @ 24Hz,.
HDCP and 3D compliant, and supports 7.1 channel surround sound, DTS-HD, and Dolby TrueHD audio.RS232
connection allows for use with scanners and touch-screen monitors, supporting Baud rates up to 115kbps full
duplex. IR functionality allows you to use your HDMI source's remote control in the same location as your
extended monitor/TV. (IR frequency @ 39Khz) Kit includes mounting hardware to be wall mounted, rack
mounted, or pole mounted. Compliant with the Federal Trade Agreements Act (TAA) for GSA Schedule
purchases.
Package Includes
Local Transmitter and Remote
Receiver Units
Two sets of IR-IN Cables
Two sets of IR-OUT Cables
3.5 mm Male-to-DB9-Female
Adapter Cable
3.5 mm Male-to-DB9-Male
Adapter Cable
Cable Requirements
Two sets of External Power
Supplies (Input: 100-240V, 50/60
When extending a 3840 x 2160 @ 24Hz Ultra High Definition (UHD) 4Kx2K video signal, use the following cables
(sold separately):
Hz, 0.5A Output: 5V, 2A)
Two sets of Mounting Hardware
Kits
Cat6A (available from Tripp Lite as a custom order) for up to 328 ft. (100 m.)
Cat6 cable (24AWG, Solid Wire cable required, such as Tripp Lite's N202-Series) for up to 230 ft. (70 m.)
Owner’s Manual
Cat5e cable (26AWG, Solid Wire cable required, such as Tripp Lite's N001- and N002-Series) for up to 150 ft. (45.7 m.)
When extending computer video resolutions of 1920 x 1200 @ 60Hz, or HD video resolutions of 1080p @ 60Hz, use Cat5e/6 cable (24AWG, Solid Wire cable
required, such as Tripp Lite's N202-Series) to extend the signal up to 328 ft. (100 m.).
Features
Supports Ultra High Definition (UHD) 4Kx2K video resolutions up to 3840 x 2160 @ 24Hz
Extend a 3840 x 2160 @ 24Hz signal up to 328 ft. (100 m.) using Cat6a cable (available from Tripp Lite as a custom order)
1/3
Extend a 3840 x 2160 @ 24Hz signal up to 230 ft. (70 m.) using Cat6 cable (24AWG, Solid wire cable required, such as Tripp Lite's N202-Series)
Extend a 3840 x 2160 @ 24Hz signal up to 150 ft. (45.7 m.) using Cat5 cable (26AWG, Solid wire cable required, such as Tripp Lite's N001- and
N002-Series)
Extends a computer video signal of 1920 x 1200 @ 60Hz, or a HD signal of 1080p @ 60Hz, up to 328 ft. (100 m.) using Cat5e/6 patch cable (24AWG,
Solid wire cable required, such as Tripp Lite's N202-Series)
IR functionality allows you to use your HDMI source’s remote control in the same location as your extended monitor
Uses an IR frequency of 39 Khz
Extend a full duplex RS232 serial signal, such as from a touchscreen monitor, up to 328 ft. (100m) from the source
Supports RS232 serial baud rates up to 115kbps full duplex
Supports 7.1-channel surround sound, DTS-HD and Dolby True HD audio
HDCP and 3D compatible
Plug and play; no software or drivers required
Includes mounting hardware, allowing each unit to be wall mounted, rack mounted or pole mounted
Compliant with the Federal Trade Agreements Act ( TAA ) for GSA Schedule purchases
Specifications
General Info
RoHS
Y
OVERVIEW
Chromebook Compatible
Display Style
Model Type
Cable Types
Yes
Extender
HDMI
CAT5/CAT5E
PHYSICAL
Included Mounting Accessories
Color
Y
Black
ENVIRONMENTAL
Operating Temperature Range
Storage Temperature Range
Relative Humidity
0 to 40 C (32 to 104 F)
-20 to 60 C (-4 to 140 F)
20 to 90%
CONNECTIONS
Connector A
Connector B
HDMI (FEMALE)
RJ45 (FEMALE)
WARRANTY
2/3
