5962-8513102XA datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> 5962-8513102XA

5962-8513102XA: Description8-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP28, CERAMIC, DIP-28; CategoryAnalog mixed-signal IC The signal circuit; File Size524KB，24 Pages; ManufacturerIntersil ( Renesas ); Websitehttp://www.intersil.com/cda/home/

Download Datasheet Parametric Compare View All

5962-8513102XA Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	5962-8513102XA	-	-	View	Buy Now

5962-8513102XA Overview

8-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP28, CERAMIC, DIP-28

5962-8513102XA Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Parts packaging code	DIP
package instruction	DIP, DIP28,.6
Contacts	28
Reach Compliance Code	not_compliant
ECCN code	EAR99
Factory Lead Time	1 week
Other features	OVERVOLTAGE PROTECTION
Analog Integrated Circuits - Other Types	DIFFERENTIAL MULTIPLEXER
JESD-30 code	R-GDIP-T28
JESD-609 code	e0
length	36.957 mm
Nominal Negative Supply Voltage (Vsup)	-15 V
Number of channels	8
Number of functions	1
Number of terminals	28
On-state resistance matching specifications	105 Ω
Maximum on-state resistance (Ron)	1500 Ω
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Encapsulate equivalent code	DIP28,.6
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	NOT APPLICABLE
power supply	+-15 V
Certification status	Not Qualified
Filter level	MIL-STD-883
Maximum seat height	5.715 mm
Maximum signal current	0.02 A
Maximum supply current (Isup)	2 mA
Nominal supply voltage (Vsup)	15 V
surface mount	NO
Maximum disconnect time	500 ns
Maximum connection time	500 ns
switch	BREAK-BEFORE-MAKE
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb) - hot dipped
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE
width	15.24 mm

Preview

Download Datasheet

View All

HI-546, HI-547, HI-548, HI-549

Data Sheet

September 21, 2005

FN3150.5

Single 16 and 8, Differential 8-Channel

and 4-Channel CMOS Analog MUXs with

Active Overvoltage Protection

The HI-546, HI-547, HI-548 and HI-549 are analog

multiplexers with active overvoltage protection and

guaranteed r

matching. Analog input levels may greatly

exceed either power supply without damaging the device or

disturbing the signal path of other channels. Active

protection circuitry assures that signal fidelity is maintained

even under fault conditions that would destroy other

multiplexers.

Analog inputs can withstand constant 70V

P-P

levels with

±15V

supplies. Digital inputs will also sustain continuous

faults up to 4V greater than either supply. In addition, signal

sources are protected from short circuiting should

multiplexer supply loss occur. Each input presents 1kΩ of

resistance under this condition. These features make the

HI-546, HI-547, HI-548 and HI-549 ideal for use in systems

where the analog inputs originate from external equipment

or separately powered circuitry. All devices are fabricated

with 44V Dielectrically Isolated CMOS technology. The

HI-546 is a single 16-Channel, the HI-547 is an 8-Channel

differential, the HI-548 is a single 8-Channel and the HI-549

is a 4-Channel differential device. If input overvoltage

protection is not needed the HI-506/507/508/509

multiplexers are recommended. For further information see

Application Notes AN520 and AN521.

For MIL-STD-883 compliant parts, request the HI-546/883,

HI-547/883, HI-548/883 and HI-549/883 datasheets.

Features

• Analog Overvoltage Protection. . . . . . . . . . . . . . . . . . 70V

P-P

• No Channel Interaction During Overvoltage

• Guaranteed r

Matching

• Maximum Power Supply. . . . . . . . . . . . . . . . . . . . . . . 44V

• Break-Before-Make Switching

• Analog Signal Range . . . . . . . . . . . . . . . . . . . . . . . .

±15V

• Access Time (Typical) . . . . . . . . . . . . . . . . . . . . . . . 500ns

• Standby Power (Typical). . . . . . . . . . . . . . . . . . . . . 7.5mW

•

Pb-Free Plus Anneal Available (RoHS Compliant)

Applications

• Data Acquisition

• Industrial Controls

• Telemetry

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or 321-724-7143

Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.

5962-8513102XA Related Products

	5962-8513102XA	JM38510/19002BXA
Description	8-CHANNEL, DIFFERENTIAL MULTIPLEXER, CDIP28, CERAMIC, DIP-28	16-CHANNEL, SGL ENDED MULTIPLEXER, CDIP28, CERAMIC, DIP-28
Is it lead-free?	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible
Parts packaging code	DIP	DIP
package instruction	DIP, DIP28,.6	DIP,
Contacts	28	28
Reach Compliance Code	not_compliant	not_compliant
ECCN code	EAR99	EAR99
Factory Lead Time	1 week	19 weeks
Other features	OVERVOLTAGE PROTECTION	OVERVOLTAGE PROTECTION
Analog Integrated Circuits - Other Types	DIFFERENTIAL MULTIPLEXER	SINGLE-ENDED MULTIPLEXER
JESD-30 code	R-GDIP-T28	R-GDIP-T28
JESD-609 code	e0	e0
length	36.957 mm	36.957 mm
Nominal Negative Supply Voltage (Vsup)	-15 V	-15 V
Number of channels	8	16
Number of functions	1	1
Number of terminals	28	28
On-state resistance matching specifications	105 Ω	105 Ω
Maximum on-state resistance (Ron)	1500 Ω	1500 Ω
Maximum operating temperature	125 °C	125 °C
Minimum operating temperature	-55 °C	-55 °C
Package body material	CERAMIC, GLASS-SEALED	CERAMIC, GLASS-SEALED
encapsulated code	DIP	DIP
Package shape	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE
Peak Reflow Temperature (Celsius)	NOT APPLICABLE	NOT APPLICABLE
Certification status	Not Qualified	Not Qualified
Maximum seat height	5.715 mm	5.715 mm
Nominal supply voltage (Vsup)	15 V	15 V
surface mount	NO	NO
Maximum disconnect time	500 ns	500 ns
Maximum connection time	500 ns	500 ns
technology	CMOS	CMOS
Temperature level	MILITARY	MILITARY
Terminal surface	Tin/Lead (Sn/Pb) - hot dipped	TIN LEAD
Terminal form	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm
Terminal location	DUAL	DUAL
Maximum time at peak reflow temperature	NOT APPLICABLE	NOT APPLICABLE
width	15.24 mm	15.24 mm
