QG501C_15 Overview

General Purpose Rectifiers

QG501C ~ QG507C
Elektronische Bauelemente
RoHS Compliant Product
A suffix of “-C” specifies halogen-free and RoHS Compliant
50 ~ 1000 V
5.0 Amp Surface Mount Silicon
General Purpose Rectifiers
SMC(DO-214AB)
FEATURES
Glass passivated junction
High surge current capability
Low reverse current
Component in accordance to RoHS 2002/95/EC
B
A
C
MECHANICAL DATA
Cases:SMC(DO-214AB)
Case Material:Molded Plastic. UL Flammability
Classification Rating 94V-0
Terminals:Lead Free Plating(Tin Finish)
Solderable Per MIL-STD-202, Method 208
Polarity:Cathode Band
H
D
G
E
F
Millimeter
Min.
Max.
-
0.203
7.640
8.130
0.750
1.520
0.150
0.305
PACKAGE INFORMATION
Package
SMC
MPQ
3K
Leader Size
13 inch
REF.
A
B
C
D
Millimeter
Min.
Max.
2.750
3.250
6.520
7.110
5.50
6.220
1.980
2.620
REF.
E
F
G
H
MAXIMUM RATINGS
(T
A
=25℃ unless otherwise noted)
Part Number
Parameters
Maximum repetitive peak reverse voltage
Maximum RMS voltage
Maximum DC blocking voltage
Maximum average forward rectified current
Peak Forward Surge Current, 8.3ms single half
sine-wave superimposed on rated load
Maximum Instantaneous
Forward Voltage @ I
F
=5A
Maximum DC Reverse
TA=25°C
Current at Rated DC Blocking
TA=100°C
Voltage
Typical Junction Capacitance
1
Thermal Resistance Junction to Ambient
2
Thermal Resistance Junction to Lead
2
Storage and Operating Temperature Range
Symbol
V
RRM
V
RMS
V
DC
I
F
I
FSM
V
F
I
R
C
J
R
θJA
R
θJL
T
J
, T
STG
QG
501C
50
35
50
QG
502C
100
70
100
QG
503C
200
140
200
QG
504C
400
280
400
5.0
125
1.15
5
50
60
28
5
QG
505C
600
420
600
QG
506C
800
560
800
QG
507C
1000
700
1000
Units
V
V
V
A
A
V
A
pF
°C / W
°C / W
°C
-55 ~ 150, -55 ~ 150
Notes:
1. Measured at 1.0MHz and applied reverse voltage of 4.0V DC
2. FR4 Board Heat sink size: 30*30mm.
http://www.SeCoSGmbH.com/
Any changes of specification will not be informed individually.
16-May-2014 Rev.C
Page 1 of 2
