SMD Type
Schottky Diodes
SB520S30
SOD-523F
Cathode Band
Top View
Diodes
Unit:mm
●
Low Forward Voltage Drop
●
Flat Lead, Surface Mount Device at 0.60mm Height
●
Moisture Level Sensitivity 1
●
Pb-free Version and RoHS Compliant
0.8
0.7 (Max)
0.20
1.6
0.1
■
Absolute Maximum Ratings Ta = 25℃
Parameter
Reverse Voltage
Average Rectified Forward Current
Power Dissipation
Thermal Resistance Junction to Ambient
Junction Temperature
Storage Temperature range
Symbol
V
RM
I
FAV
P
d
R
θJA
T
J
T
stg
Rating
30
200
200
500
125
-55 to 125
Unit
V
mA
mW
℃/W
℃
■
Electrical Characteristics Ta = 25℃
Parameter
Reverse breakdown voltage
Forward voltage
Reverse voltage leakage current
Symbol
V
R
V
F
I
R
Test Conditions
I
R
= 500 uA
I
F
= 200 mA
V
R
= 10 V
Min
30
0.6
1
Typ
Max
Unit
V
uA
■
Marking
Marking
1B
0.20 (Max)
1.2
0.1
0.3
■
Features
0.1
0.05
www.kexin.com.cn
1
