ECX-UM-1
SMD QUARTZ CRYSTAL
ECS offers all characteristics of the UM-1
with a metal jacket for surface mount
applications. This crystal has a very wide
frequency range from 3.6864MHz to 225MHz
for use in wireless communication applica-
tions requiring tight tolerance specifications
such as ± 5 PPM over -10˚C to +60˚C.
FEATURES
• 3.6864MHz to 225MHz frequency range
• Very small foot print for critical space applications
• Resistance weld enclosure
•
RoHS Compliant
• Tape & Reel (1,000 pcs)
PART NUMBERING GUIDE
“EXAMPLE”
ECS
–
FREQUENCY (16.0000 MHz)
160
–
LOAD CAPACITANCE*
20
–
PACKAGE TYPE
22 SMJ
* Load capacitance (xx=xx pF, S= series resonance)
Note: See Product Selection Guide for additional options.
OPERATING CONDITIONS/ELECTRICAL CHARACTERISTICS
PARAMETERS
FREQUENCY RANGE
FREQUENCY TOLERANCE
FREQUENCY STABILITY REFERENCE @ +25˚C
SHUNT CAPACITANCE
LOAD CAPACITANCE
DRIVE LEVEL
AGING (@ +25˚C per year)
OPERATING TEMPERATURE
STORAGE TEMPERATURE
CONDITIONS
f
o
3.6864MHz ~ 9.99MHz
10.000MHz ~ 225MHz
3.6864MHz ~ 9.99MHz
10.000MHz ~ 225MHz
C
0
C
L
(Customer Specified)
3.6864MHz ~ 9.99MHz
10.000MHz ~ 225MHz
3.6864MHz ~ 9.99MHz
10.000MHz ~ 225MHz
T
OPR
T
STG
MINIMUM
3.6864
-50
-30
-100
-50
10.0
0.5
0.1
-5
-3
-10
-40
20.0 standard
TYPICAL
MAXIMUM
225.000
+50
+30
+100
+50
5.0
Series
1.0
0.5
+5
+3
+60
+85
UNITS
MHz
PPM
PPM
pF
pF
mW
PPM
˚C
˚C
EQUIVALENT SERIES RESISTANCE / MODE OF OSCILLATION
FREQUENCY RANGE (MHz)
3.686 ~ 3.999
4.000 ~ 4.999
5.000 ~ 5.999
6.000 ~ 6.999
7.000 ~ 7.999
MODE
Fundamental
Fundamental
Fundamental
Fundamental
Fundamental
MAX ESR
Ω
250
150
120
100
90
FREQUENCY RANGE (MHz)
8.000 ~ 9.999
10.000 ~ 10.999
11.000 ~ 45.000
30.000 ~ 135.000
100.000 ~ 225.000
MODE
Fundamental
Fundamental
Fundamental
3rd O/T
5th O/T
MAX ESR
Ω
80
60
40
40
80
PACKAGE DIMENSIONS (mm)
6.9
±
0.2
1.4~1.8
2.2
±
0.2
2.0
2.5
0
PPM
f/f
1.5~2.0
8.5 Max.
+ 30
- 10
25
60
TEMP.(˚C)
9.1
- 30
2.0
±
0.3
0.6
±
0.3
ø 0.40
±
0.05
8.0 Max.
Figure 3) Frequency vs Temperature Curve
1.5
3.8
2.0
1.6
±
0.3
3.5 Max.
Figure 1) ECX-UM-1 - Side and
Bottom views
Figure 2) ECX-UM-1 Land Pattern - Top view
3.75
±
0.3
ECS, INC. INTERNATIONAL
1105 S. RIDGEVIEW, OLATHE, KS 66062 • 913-782-7787 • 800-237-1041 • FAX 913-782-6991 • WWW.ECSXTAL.COM
