Gigabit Filter Port Jack
ELECTRONICS INC.
EPJ4032-S9 & EPJ4032-S9-LF
•
•
•
•
•
•
•
•
•
•
Designed for Gigabit Ethernet and 10/100Base-TX Transceiver ICs
Nylon GF (FR50) UL94V-0 Rated Connector Housing
Complete Bob Smith Termination Included
Add “-LF” after part number for Lead-Free
Metal Shield : Nickel Plated Brass C2680
Complies with IEEE 802.3ab Standards
Storage Temperature : -40°C to +125°C
Operating Temperature : 0°C to +70°C
Contact Pin : 6 u-inch Gold Plated
Space Saving RJ-45 Connector
Electrical Parameters @ 25° C
Turns
Ratio
Xmit/Rcv
1:1/1:1
OCL*
(uH Min.)
100 KHz/0.1V
350
DCR
(Ω Max.)
---
0.9
Insertion Loss
(dB Max.)
1-100 MHz
-1.0
100-125 MHz
-1.2
Return Loss
(dB Min.)
0.3-40 MHz
-18
@ 100 MHz
-12
CMRR
(dB Typ.)
0.3-100 MHz
-35
CDMR
(dB Min.)
0.3-100 MHz
-30
Crosstalk
(dB Typ.)
1-100 MHz
-33
• *OCL :
@ 8 mA DC Bias
• Isolation :
1500 Vrms
•
Package
Yellow
LED
.535
(13.60)
J1
.050
Typ.
(1.27)
.019
Typ.
(.500)
.429
(10.90)
.630 Typ.
(16.00)
Green
/Orange
LED
.846
(21.50)
.594
(15.09)
Marking :
PCA
EPJ4032-S9(-LF)
D.C.
Schematic
P1
75
Ω
P2
1CT:1CT
P3
75
Ω
.130 Typ.
(3.30)
Chip
Side
P4
P5
P6
P7
75
Ω
P8
1CT:1CT
P9
75
Ω
J5
J7
1CT:1CT
J6
Cable
Side
J4
J2
J3
J1
Recommended PCB Layout
(Component Side)
.067 (1.70) Ø (2 Plcs)
.035 (.900) Ø (10 Plcs)
.050
(1.27)
.100
(2.54)
P10
.100
(2.54)
.126 (3.20) Ø
(2 Plcs)
.180 (4.57)
P9
P1
.350
(8.89)
.120
(3.05)
.039 Ø
(1.00)
(4 Plcs)
P10
1CT:1CT
P13
Yellow LED
P14
P11
Green LED
P12
EPJ4032-S9
SnPb
225°C
(10 +2/-0) Seconds
7.56 grams
(Tray)
60 pcs / tray
EPJ4032-S9-LF
Hot Dipped Sn or SnCu
260°C
(10 +2/-0) Seconds
7.56 grams
60 pcs / tray
J8
1000 pF
2000V
Shield
P13
P14
P11
P12
.080
(2.03)
.450
(11.43)
.530
(13.45)
.620
(15.75)
Notes :
Orange LED
1. Assembly Process
(Solder Composition)
2. Peak Temperature Rating
3. Weight
4. Packaging Information
Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
Product performance is limited to specified parameters. Data is subject to change without prior notice.
CSJ4032-S9 & -LF
Rev. 4
6/9/08 JDG
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
