RJ-45 Filter Port Jacks
10/100Base-TX Voice Over IP
ELECTRONICS INC.
EPJ9301-F2
• Designed for IP Phone Applications
• Surface Mount Package
• Space Saving RJ-45 Connectors
• UL94V-0 Rated High Temp thermoplastic Housing
* Designed to meet 350 mA Balanced DC Line Current
Electrical Parameters @ 25° C
Turns Ratio
( ± 5% )
OCL
(µH Min.)
@ 100 KHz,
100m Vrms
Xmit/Rcv
1CT:1/1CT:1CT
8 mA DC Bias
350
-1.0
-1.5
-20
-15
-12
-30
-30
•
Isolation :
1500Vrms •
Cable Side Impedance :
100
Ω
•
Insertion Loss
(dB Max.)
1-80
MHz
@ 100
MHz
1-30
MHz
Return Loss
(dB
Min.)
@60
MHz
@80
MHz
CMRR
(dB Min.)
100 KHz-
100 MHz
CMD
(dB Min.)
100 KHz-
100 MHz
Crosstalk
(dB Min.)
100 KHz-
100 MHz
Xmit & Rcv
-35
Package
.756
(19.20)
.646
(16.40)
J1
.531
(13.49)
.012
(.305)
.582
(14.78)
.291
(7.39)
.949
(24.10)
P7
Marking :
PCA
EPJ9301F2
D.C.
.012
(.305)
P9
P8
P1
J7
J8
.061 .018
(1.55) (.457)
.047
(1.19)
.429
(10.90)
.122
(3.10)
.079
(2.00)
.100
(2.54)
.635
(16.13)
.050
(1.27)
J4
J5
75
Ω
75
Ω
Schematic
Transmit
J1
J2
J = Connector Side
P = Pin Side
1000 pF
2000V
Shield
Receive
P11
J3
PCB Layout
(Component)
.705
(17.91)
.500
(12.70)
.635
(16.13)
P12
.080 X .120 2 Plcs
[2.03 X 3.05 2 Plcs]
.128 [3.25] = Ø 2 plcs
P10
P6
J6
.535
(13.59)
1 23 456
.140 (3.56)
7 8 9 101112
.045 X .080 12 Plcs
[1.14 X 2.03 12 Plcs]
.080
(2.03)
.050
(1.27)
Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
Product performance is limited to specified parameters. Data is subject to change without prior notice.
CSJ9301-F2
Rev. -
11/6/02
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
