Power Choke

ELECTRONICS INC.

EPZ3005G

• Noise Suppression Choke

• 1.63 A Max. Rated Current

• 500 Vrms Isolation

Electrical Parameters @ 25° C

Inductance

(mH ± 25%)

@10 KHz, 0.1 Vrms

.884

Pins 1-2, 3-4

DCR

(mΩ Max.)

Matched with ± 5%

110

Pins 1-2, 3-4

1:1

Pins 1-2 : 3-4

4.0

Turns Ratio

SRF

(MHz Typ. )

Schematic

10KΩ

9KΩ

8KΩ

7KΩ

6KΩ

5KΩ

4KΩ

3KΩ

2KΩ

1KΩ

0.1

MHz

Impedance Curve

1.0

MHz

Frequency

MHz

Package

.500

Max.

(12.70)

PCA

EPZ3005G

D.C.

.175

(4.45)

.500

Max.

(12.70)

.410

(10.41)

.060

(1.52)

.330

(8.38)

.215 Max.

(5.46)

.330

(8.38)

.410

(10.41)

Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25

PCA ELECTRONICS, INC.

16799 SCHOENBORN ST.

NORTH HILLS, CA 91343

Product performance is limited to specified parameters. Data is subject to change without prior notice.

CSZ3005G

Rev. 1

3/25/03

TEL: (818) 892-0761

FAX: (818) 894-5791

http://www.pca.com
