Power Choke
ELECTRONICS INC.
EPZ3006G
• Noise Suppression Choke
• 2.80 A Max. Rated Current
• 500 Vrms Isolation
Electrical Parameters @ 25° C
Inductance
(mH ± 25%)
@10 KHz, 0.1 Vrms
1.47
Pins 1-2, 3-4
DCR
(mΩ Max.)
Matched with ± 5%
80
Pins 1-2, 3-4
1:1
Pins 1-2 : 3-4
2.0
Turns Ratio
SRF
(MHz Typ. )
Schematic
12KΩ
1
3
2
4
11KΩ
10KΩ
9KΩ
8KΩ
7KΩ
6KΩ
5KΩ
4KΩ
3KΩ
2KΩ
1KΩ
0
Impedance Curve
0.1
MHz
1.0
MHz
Frequency
10
MHz
20
MHz
Package
.670 Max.
(17.02)
1
3
.770
PCA
EPZ3006G
Max.
D.C.
2
4
(19.56)
.175
(4.45)
1
3
.060
(1.52)
.660
(116.7
6)
2
4
.330
(8.38)
.390 Max.
(59.91)
.650
(16.51)
Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
Product performance is limited to specified parameters. Data is subject to change without prior notice.
CSZ3006G
Rev. 1
3/25/03
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
