Power Choke

ELECTRONICS INC.

EPZ3007G & EPZ3007G-LF

• Used in DC/DC Converter

• UL94V-0 Recognized Materials

• UL1446 Class B Insulating System

• Add “-LF” after part number for Lead Free

• Operating Temperature : -40°C to +85°C

• Noise suppression Choke

• 3.30 A Rated Current

• 500 Vrms Isolation

Electrical Parameters @ 25° C

Inductance

(mH ± 25%)

@10 KHz, 0.1 Vrms

Pins 1-2, 3-4

1.32

DCR

(mΩ Max.)

Matched with ± 5%

Pins 1-2, 3-4

Turns Ratio

SRF

(MHz Typ. )

Pins 1-2 : 3-4

1:1

2.0

Notes :

1. Lead Finish

2. Peak Solder Rating

3. Moisture Sensitive Levels (MSL)

4. Weight

5. Packaging Information

(Tube)

EPZ3007G

SnPb

225°C

(Unlimited,

≤30°C/60%RH)

4.6 grams

TBD pcs / tube

EPZ3007G-LF

Hot Tin Dip (Sn)

260°C

(Unlimited,

≤30°C/60%RH)

4.6 grams

TBD pcs / tube

Schematic

Package

.670 Max.

(17.02)

PCA

EPZ3007G(-LF)

D.C.

Impedance Curve

.175

(4.45)

.060

(1.52)

.770

Max.

(19.56)

.660

(16.76)

.445

(11.30)

.390 Max.

(9.91)

.650

(16.51)

11KΩ

10KΩ

9KΩ

8KΩ

7KΩ

6KΩ

5KΩ

4KΩ

3KΩ

2KΩ

1KΩ

0.1 MHz

1 MHz

Frequency

10 MHz

20 MHz

Unless Otherwise Specified Dimensions are in Inches /mm ± .010 /.25

PCA ELECTRONICS, INC.

16799 SCHOENBORN ST.

NORTH HILLS, CA 91343

Product performance is limited to specified parameters. Data is subject to change without prior notice.

CSZ3007G & -LF

Rev. 5

7/10/06 FT

TEL: (818) 892-0761

FAX: (818) 894-5791

http://www.pca.com
