Dual USB / Gigabit Filter Port Jacks
ELECTRONICS INC.
EPJ4015
• Space saving RJ-45/USB Connectors •
• Thermo Plastic PBT UL94V-0 Rated Connector Housing •
• Metal Shield : Nickel Plated Copper Alloy •
• Pins : 0.018 Tin-Coated Copper Wire •
Electrical Parameters @ 25° C
OCL
(µH Min.)
@ 100 KHz,
100m Vrms
8 mA DC Bias
350
-1
-20
-18
-12
-30
-30
1CT:1CT
•
LEDs :
Vf=2.1V Typ. @ 20 mA •
Isolation :
1500 Vrms
•
Operating Temperature :
0°C to +70°C •
Insertion Loss
(dB Max.)
1-100
MHz
1-30
MHz
Return Loss
(dB Min.)
@ 60
MHz
@80
MHz
CMRR
(dB Min.)
100 KHz-
100 MHz
CMD
(dB Min.)
100 KHz-
100 MHz
Turns Ratio
( ± 5% )
Crosstalk
(dB Min.)
1-100 MHz
Xmit - Rcv
-30
Schematic
1
2
3
6
11
LED 1
Yellow
12
14
16
15
LED 2
Green
Orange
J1
J2
4
5
J3
J4
7
8
J5
J6
9
10
J7
J8
Recommended PCB Footprint
Component Side
.570
.400
Package
Pin Assignment
.433
16 15 14 13 12 11
6 5 4 3 2 1
10 9 8 7
.370
.240
.170
.096
.140
.080
Ø=.035 24 Plcs
.147 .242
.466
.565
LED 2
.673
Max.
.752
± .020
1.027
Max.
LED 1
.245
C
L
.360 .257
.377
1.15
.498
.125
.040
Min.
Marking :
PCA
EPJ4015
D.C.
.125
.305
.096
Ø=.091 4 Plcs
Ø =.062 4 Plcs
.276
.320
.517
.635
.079
PCA ELECTRONICS, INC.
16799 SCHOENBORN ST.
NORTH HILLS, CA 91343
CSJ4015
Rev. 1
1/29/03
Product performance is limited to specified parameters. Data is subject to change without prior notice.
TEL: (818) 892-0761
FAX: (818) 894-5791
http://www.pca.com
