LC717A10AJ
Capacitance‐Digital‐Converter
LSI for Electrostatic
Capacitive Touch Sensors
Overview
The LC717A10AJ is a high-performance and low-cost
capacitance-digital-converter LSI for electrostatic capacitive touch
sensor, especially focused on usability.
It has 16 channels capacitance-sensor input. This makes it ideal for
use in the products that need many switches. Since the calibration
function and the judgment of ON/OFF are automatically performed in
LSI internal, it can make development time more short. A detection
result (ON/OFF) for each input can be read out by the serial interface
(I
2
C compatible bus or SPI).
Also, measurement value of each input can be read out as 8-bit
digital data. Moreover, gain and other parameters can be adjusted
using serial interface.
Features
www.onsemi.com
SSOP30 (225 mil)
CASE 565AZ
MARKING DIAGRAM
•
Detection System: Differential Capacitance Detection
•
•
•
•
•
•
•
(Mutual Capacitance Type)
Input Capacitance Resolution: Can Detect Capacitance Changes in
the Femto Farad Order
Measurement Interval (16 Differential Inputs):
♦
30 ms (Typ) (at Initial Configuration)
♦
6 ms (Typ) (at Minimum Interval Configuration)
External Components for Measurement: Not Required
Current Consumption:
♦
570
mA
(Typ) (V
DD
= 2.8 V)
♦
1.3 mA (Typ) (V
DD
= 5.5 V)
Supply Voltage: 2.6 V to 5.5 V
Detection Operations: Switch
Interface: I
2
C Compatible Bus or SPI Selectable
XXXXXXXXXX
YMDDD
XXXXX = Specific Device Code
Y = Year
M = Month
DDD = Additional Traceability Data
ORDERING INFORMATION
See detailed ordering and shipping information on page 11 of
this data sheet.
©
Semiconductor Components Industries, LLC, 2013
August, 2018
−
Rev. 3
1
Publication Order Number:
LC717A10AJ/D
LC717A10AJ
Specifications
Table 1. ABSOLUTE MAXIMUM RATINGS
(T
A
= 25°C, V
SS
= 0 V)
Parameter
Supply Voltage
Input Voltage
Output Voltage
Power Dissipation
Storage Temperature
Symbol
V
DD
V
IN
V
OUT
P
d max
T
stg
Ratings
−0.3
to +6.5
−0.3
to V
DD
+ 0.3
−0.3
to V
DD
+ 0.3
160
−55
to +125
Unit
V
V
V
mW
_C
(Note 1)
(Note 2)
T
A
= +105_C, Mounted on a substrate (Note 3)
Remarks
Stresses exceeding those listed in the Maximum Ratings table may damage the device. If any of these limits are exceeded, device functionality
should not be assumed, damage may occur and reliability may be affected.
1. Apply to Cin0 to 15, Cref, CrefAdd, nRST, SCL, SDA, SA0, SA1, SCK, SI, nCS.
2. Apply to Cdrv, SDA, SO, INTOUT.
3. Single-layer glass epoxy board (76.1
×
114.3
×
1.6t mm).
Table 2. RECOMMENDED OPERATING CONDITIONS
Parameter
Operating Supply Voltage
Supply Ripple + Noise
Operating Temperature
Symbol
V
DD
V
PP
T
opr
Conditions
Min
2.6
−
−40
Typ
−
−
25
Max
5.5
±20
105
Unit
V
mV
_C
(Note 4)
Remarks
Functional operation above the stresses listed in the Recommended Operating Ranges is not implied. Extended exposure to stresses beyond
the Recommended Operating Ranges limits may affect device reliability.
4. Inserting a high-valued capacitor and a low-valued capacitor in parallel between V
DD
and V
SS
is recommended. In this case, the small-valued
capacitor should be at least 0.1
mF,
and is mounted near the LSI.
Table 3. ELECTRICAL CHARACTERISTICS
(V
SS
= 0 V, V
DD
= 2.6 to 5.5 V, T
A
=
−40
to +105°C, Unless otherwise specified, the Cdrv drive frequency is f
CDRV
= 143 kHz.
Not tested at low temperature before shipment.)
Parameter
Capacitance Detection Resolution
Output Noise RMS
Input Offset Capacitance
Adjustment Range
Input Offset Capacitance
Adjustment Resolution
Cin Offset Drift
Cin Detection Sensitivity
Cin Pin Leak Current
Cin Allowable Parasitic Input
Capacitance
Cdrv Drive Frequency
Cdrv Pin Leak Current
nRST Minimum Pulse Width
Power-on Reset Time
Power-on Reset Operation
Condition: Hold Time
Power-on Reset Operation
Condition: Input Voltage
Power-on Reset Operation
Condition: Power Supply Rise Rate
Symbol
N
N
RMS
Coff
RANGE
Coff
RESO
Cin
DRIFT
Cin
SENSE
I
Cin
Cin
SUB
f
CDRV
I
CDRV
t
NRST
t
POR
t
POROP
V
POROP
t
VDD
0 V to V
DD
Cdrv = Hi−Z
Minimum gain setting
Minimum gain setting
Cin = Hi−Z
Cin against V
SS
Minimum gain setting
Conditions
Min
−
−
−
−
−
0.04
−
−
100
−
1
−
10
−
1
Typ
−
−
±8.0
8
−
−
±25
−
143
±25
−
−
−
−
−
Max
8
±1.0
−
−
±8
0.12
±500
30
186
±500
−
20
−
0.1
−
Unit
bit
LSB
pF
bit
LSB
LSB/fF
nA
pF
kHz
nA
ms
ms
ms
V
V/ms
(Note 5)
(Note 5)
(Note 5)
(Notes 5, 7)
(Note 5)
(Note 6)
(Notes 5, 7)
(Notes 5, 7)
Remarks
www.onsemi.com
2
LC717A10AJ
Table 3. ELECTRICAL CHARACTERISTICS
(continued)
(V
SS
= 0 V, V
DD
= 2.6 to 5.5 V, T
A
=
−40
to +105°C, Unless otherwise specified, the Cdrv drive frequency is f
CDRV
= 143 kHz.
Not tested at low temperature before shipment.)
Parameter
Pin Input Voltage
Symbol
V
IH
V
IL
Pin Output Voltage
V
OH
V
OL
SDA Pin Output Voltage
Pin Leak Current
Current Consumption
V
OL I2C
I
LEAK
I
DD
When initial setting
and non-touch
V
DD
= 2.8 V
When initial setting
and non-touch
V
DD
= 5.5 V
I
STBY
During Sleep process
Conditions
High input
Low input
High output
(I
OH
= +3 mA)
Low output
(I
OL
=
−3
mA)
SDA Low output
(I
OL
=
−3
mA)
Min
0.8 V
DD
−
0.8 V
DD
−
−
−
−
Typ
−
−
−
−
−
−
570
Max
−
0.2 V
DD
−
0.2 V
DD
0.4
±1
700
V
mA
mA
(Note 10)
(Notes 5, 7)
V
(Note 9)
Unit
V
Remarks
(Notes 5, 8)
−
1.3
1.6
mA
−
−
1
mA
(Note 7)
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
5. Design-guaranteed values (not tested before shipment).
6. Measurements conducted using the test mode in the LSI.
7. T
A
= +25_C.
8. Apply to nRST, SCL, SDA, SA0, SA1, SCK, SI, nCS.
9. Apply to Cdrv, SO, INTOUT.
10. Apply to nRST, SCL, SDA, SA0, SA1, SCK, SI, nCS.
www.onsemi.com
3
LC717A10AJ
Table 4. I
2
C COMPATIBLE BUS TIMING CHARACTERISTICS
(V
SS
= 0 V, V
DD
= 2.6 to 5.5 V, T
A
=
−40
to +105°C, Not tested at low temperature before shipment.)
Parameter
SCL Clock Frequency
START Condition Hold Time
SCL Clock Low Period
SCL Clock High Period
Repeated START Condition
Setup Time
Data Hold Time
Data Setup Time
SDA, SCL Rise/Fall Time
STOP Condition Setup Time
STOP-to-START Bus Release Time
Symbol
f
SCL
t
HD;STA
t
LOW
t
HIGH
t
SU;STA
t
HD;DAT
t
SU;DAT
t
r
/ t
f
t
SU;STO
t
BUF
Pin Name
SCL
SCL, SDA
SCL
SCL
SCL, SDA
SCL, SDA
SCL, SDA
SCL, SDA
SCL, SDA
SCL, SDA
Conditions
Min
−
0.6
1.3
0.6
0.6
0
100
−
0.6
1.3
Typ
−
−
−
−
−
−
−
−
−
−
Max
400
−
−
−
−
0.9
−
300
−
−
Unit
kHz
ms
ms
ms
ms
ms
ns
ns
ms
ms
(Note 11)
(Note 11)
(Note 11)
(Note 11)
Remarks
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
11. Design-guaranteed values (not tested before shipment).
Table 5. SPI BUS TIMING CHARACTERISTICS
(V
SS
= 0 V, V
DD
= 2.6 to 5.5 V, T
A
=
−40
to +105°C, Not tested at low temperature before shipment.)
Parameter
SCK Clock Frequency
SCK Clock Low Time
SCK Clock High Time
Input Signal Rise/Fall Time
nCS Setup Time
SCK Clock Setup Time
Data Setup Time
Data Hold Time
nCS Hold Time
SCK Clock Hold Time
nCS Standby Pulse Width
Output High Impedance Time
from nCS
Output Data Determination Time
Output Data Hold Time
Output Low Impedance Time
from SCK Clock
Symbol
f
SCK
t
LOW
t
HIGH
t
r
/ t
f
t
SU;NCS
t
SU;SCK
t
SU;SI
t
HD;SI
t
HD;NCS
t
HD;SCK
t
CPH
t
CHZ
t
v
t
HD;SO
t
CLZ
Pin Name
SCK
SCK
SCK
nCS, SCK, SI
nCS, SCK
nCS, SCK
SCK, SI
SCK, SI
nCS, SCK
nCS, SCK
nCS
nCS, SO
SCK, SO
SCK, SO
SCK, SO
Conditions
Min
−
90
90
−
90
90
20
30
90
90
90
−
−
0
0
Typ
−
−
−
−
−
−
−
−
−
−
−
−
−
−
−
Max
5
−
−
300
−
−
−
−
−
−
−
80
80
−
−
Unit
MHz
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
ns
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
(Note 12)
Remarks
Product parametric performance is indicated in the Electrical Characteristics for the listed test conditions, unless otherwise noted. Product
performance may not be indicated by the Electrical Characteristics if operated under different conditions.
12. Design-guaranteed values (not tested before shipment).
www.onsemi.com
4
LC717A10AJ
Power-On Reset (POR)
When power is turned on, power-on reset is enabled inside
the LSI and its state is released after a certain power-on reset
time, t
POR.
Power-on reset operation condition: Power
supply rise rate t
VDD
must be at least 1 V/ms.
V
DD
Since INTOUT pin changes from “High” to “Low” at the
same time as the released of power-on reset, it is possible to
verify the timing of release of power-on reset externally.
During power-on reset, Cin, Cref and CrefAdd are
unknown.
tVDD
tPOR
VPOROP
tPOROP
RELEASE
UNKNOWN
tPOR
POR
(LSI Internal
Signal)
RESET
RESET
RELEASE
INTOUT
VALID
UNKNOWN
Cin,
Cref,
CrefAdd
UNKNOWN
VALID
UNKNOWN
Figure 1.
I
2
C Compatible Bus Data Timing
90%
90%
10%
tSU;STA
90%
10% 10%
tHD;STA
tHIGH
10%
10%
tHD;STA
90%
90%
10%
tSU;STO
90%
tBUF
90%
10%
SDA
10%
tLOW
90%
tHD;DAT
90% 90%
10%
tSU;DAT
SCL
tr
tf
Repeated START
condition
STOP
condition
START
condition
START
condition
Figure 2.
I
2
C Compatible Bus Communication Formats
•
Write format (data can be written into sequentially incremented addresses)
START
Slave Address
Write=L
ACK
Register Address (N)
ACK
Data written to Register Address (N)
ACK
Data written to Register Address (N+1) ACK
STOP
Slave
Slave
Slave
Slave
Figure 3.
•
Read format (data can be read from sequentially incremented addresses)
START
Slave Address
Write=L
ACK
Register Address (N)
ACK
Slave
RESTART
Slave Address
Read=H ACK
Data read from Register Address (N)
Slave
ACK
Data read from Register Address (N+1)
ACK Data read from Register Address (N+2) NACK STOP
Slave
Master
Master
Master
Figure 4.
www.onsemi.com
5
